5330-00-632-0167
Plain Seal
5330006320167 006320167 104-16 7017925
A pliable rubber or composition ring-shaped element, split or jointless (solid) not encased in a metal shell, but having a spring, spreader and/or molded-in reinforcement. It is designed to be pressmounted between fixed and movable or moving parts to form a tight and effective seal. View more Plain Seal
January 2023
12
Marketplace 5330-00-632-0167
Request a Quotation from participating marketplace vendors
Related Documents 5330-00-632-0167 5+ Documents (More...)
RQST NE Updated Every Day 5330-00-632-0167 RQST Updated Every Day 5330-00-632-0167 RQST NE Related
Documents 5330-00-632-0167 5+ Documents ( More... ) https//www.nsnlookup.com /fsg-53/fsc-5330/us 5330
4910-27-019-8541 RQST NE Related Documents https https//www.nsnlookup.com /fsg-53/fsc-5330/us 5330-00-632-0167
Plain Seal 5330006320167 006320167,7017925 Updated Every Day 5330-00-632-0167 RQST NE Related https
Plain Seal 5330006320167 006320167,7017925 www.nsnlookup.com /fsg-53/fsc-5330/us 5330-00-632-0167
/fsg-53/fsc-5310/us
https//www.nsnlookup.com /fsg-53/fsc-5310/us 5310-00-370-3469 Special Washer 5310003703469003703469 7017925
Plain Seal 5330006320167 006320167,7017925 Vulcanizing Mold4910270198541 270198541 5330006320167
Plain Seal 5330006320167 006320167,7017925 -8541 Tire Vulcanizing Mold 5330006320167 https https
Restrictions 5330-00-632-0167
5330-00-632-0167 is a Plain Seal that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item may be hazardous as it is in a Federal Supply Class for potentially hazardous items. A MSDS should be available from the supplier for the end user to evaluate any hazards. The precious metals content of this item is unknown.
Import and Export 5330-00-632-0167
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5330-00-632-0167
- Greece (ZU01)
- Effective Date:
- 1 Aug 1995
- Turkey (ZW01)
- Effective Date:
- 1 Jan 2003
Approved Sources 5330-00-632-0167
- Part Number
- Manufacturer
- Status
- 104-16
- Manufacturer
- 70026 - Chicago Fittings (Active)
- Primary Buy
- Primary Buy
- 7017925
- 19207 - U S Army Tank Automotive Command (Active)
- Primary Buy
- Primary Buy
Datasheet 5330-00-632-0167
- Characteristic
- Specifications
- FIIG
- Specifications
- A032A0
- Accommodated Shaft Diameter [ABVM]
- 0.990 Inches Minimum And 1.016 Inches Maximum
- Construction [CQCF]
- Solid
- Cross-Sectional Shape Style [AAGR]
- Dual Lip
- Housing Bore Diameter [CPCW]
- 1.366 Inches Minimum And 1.398 Inches Maximum
- Material [MATT]
- Rubber Synthetic Sealing Element
- Material [MATT]
- Steel Internally Molded-In Reinforcement
- Seal Width [ADUC]
- 0.610 Inches Minimum And 0.640 Inches Maximum
Similar Supply Items to 5330-00-632-0167
Freight Information 5330-00-632-0167
5330-00-632-0167 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 194120. A Sub NMFC of Z. It has a NMFC Description of WASHERS/GASKETS/PCKG DVCS NOI. 5330-00-632-0167 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 95100 which rates the freight between FCL and LCL. 5330-00-632-0167 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 596 for ocean manifesting and military sealift. 5330-00-632-0167 is not classified as a special type of cargo when transported by water. 5330-00-632-0167 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 5330-00-632-0167
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- Plated/Coated Item
- 2lb or less, one dimension 2" or less, other dimensions less than 24"
- Above 110G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- --
- --
- --
- --
- --
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- No Requirement
- No Requirement
- Not Applicable
- --
- No special marking
- No Requirement
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- PPP-B-566, PPP-B-676, or ASTM-D5118, Folding, Setup or Fiberboard Box
