5330-00-571-7052
Plain Encased Seal
5330005717052 005717052 10938287
A pliable rubber, felt, leather, or composition ring-shaped element, split or solid; with or without spring or spreader, having a metal shell on all or a portion of at least two of the outer surfaces. It may be designed to be either bolt mounted or pressmounted between fixed and moveable parts to form a tight and effective seal by the pressure of the spring or spreader or the resiliency inherent in the element material. Excludes PACKING WITH RETAINER. View more Plain Encased Seal
October 2025
9
Marketplace 5330-00-571-7052
Request a Quotation from participating marketplace vendors
Related Documents 5330-00-571-7052 1+ Documents (More...)
Updated 57 Days Ago 10938287 SEAL 11 EA NS Request Quotation 10938287 SEAL 3 EA NS Request Quotation
SEAL,PLAIN ENCASED 18 EA NS Request Quotation Updated Every Day 5330-00-571-7052 RQST NE Updated
Restrictions 5330-00-571-7052
5330-00-571-7052 is a Plain Encased Seal that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item may be hazardous as it is in a Federal Supply Class for potentially hazardous items. A MSDS should be available from the supplier for the end user to evaluate any hazards. This item does not contain a precious metal.
Import and Export 5330-00-571-7052
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5330-00-571-7052
- US Army (A919)
- Effective Date:
- 1 Apr 2006
- Former MOE Rule:
- A187
- Supplementary Receivers:
- AZBD
- US Air Force (FXGI)
- Effective Date:
- 1 Apr 2006
- Former MOE Rule:
- FXKZ
- US Marine Corps (MC47)
- Effective Date:
- 1 Apr 2006
- Former MOE Rule:
- MC10
- US Navy (N9BZ)
- Effective Date:
- 1 Apr 2006
- Former MOE Rule:
- N9ZD
- Supplementary Collaborators:
- GTHD
- Morocco (YP01)
- Effective Date:
- 1 Nov 2008
- Portugal (ZP01)
- Effective Date:
- 1 Apr 1991
Approved Sources 5330-00-571-7052
- Part Number
- Manufacturer
- Status
- 10938287
- Manufacturer
- 19207 - U S Army Tank Automotive Command (Active)
- Primary Buy
- Primary Buy
- 10938287
- 01212 - Federal-Mogul Corp Government Sales (Active)
- Secondary Buy
- Secondary Buy
- 10938287
- 71724 - John Crane, Inc (Active)
- Secondary Buy
- Secondary Buy
- 5330005717052
- SCY13 - E.C.A Etablissement (Replaced)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 5330-00-571-7052
- Characteristic
- Specifications
- FIIG
- Specifications
- A032A0
- Accommodated Shaft Diameter [ABVM]
- 1.000 Inches Nominal
- Accommodated Shaft Maximum Rated Speed [AEAT]
- 916 Feet Per Minute
- Case Style [BHHL]
- Square
- Housing Bore Diameter [CPCW]
- 1.501 Inches Minimum And 1.505 Inches Maximum
- Material Document And Classification [MDCL]
- Mil-S-45005,Cl 2 Mil Spec Single Material Response Sealing Element
- Material Document And Classification [MDCL]
- Qq-S-698 Fed Spec All Material Responses Case
- Material [MATT]
- Rubber Butadiene-Acrylonitrile Class Nbr Sealing Element And Steel Sealing Element
- Material [MATT]
- Steel Comp 1008 Case Or Steel Comp 1009 Case Or Steel Comp 1015 Case Or Steel Comp 1018 Case Or Steel Comp 1020 Case Or Steel Case
- Seal Width [ADUC]
- 0.234 Inches Minimum And 0.266 Inches Maximum
- Sealing Element Style [CTQC]
- Angular
- Surface Treatment [SFTT]
- Cadmium Case
Weapon Systems (WSDC) 5330-00-571-7052
DLA Procurement Analysis 5330-00-571-7052
- Last Stock Position:
- 134 In Stock
- DLA Administrative Lead Time:
- Subscribe
- DLA Production Lead Time:
- Subscribe
Management Data 5330-00-571-7052
Army
- Materiel Category and Inventory Manager:
- T
- Industrial Supplies (DLA/GSA Items)
- Appropriation and Budget Activity:
- 2
- Stock Fund Secondary Items
- Management Inventory Segment:
- 2
- Non-Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify items, which are not reparable.
- Weapons System / End Item / Homogeneous Group:
- 00
- DLA/GSA Material
DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item
- Accounting Requirements:
- X
- Expendable item.An item of Army property coded with an ARC of X in the AMDF. Expendable items require no formal accountability after issue from a stock record account.Commercial and fabricated items similar to items coded X in the AMDF are considered expendable items.
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
Marine Corps
- Stores Account:
- 1
- Stock Fund Account Item
- Combat Essentiality:
- 5
- Critical Repair Part to a Combat Essential End Item
- Echelon Management:
- B2
- Material Identification:
- T
- Maintenance Float Secondary Non-depot Reparables
- Operational Test:
- No Special Procedures
Similar Supply Items to 5330-00-571-7052
Freight Information 5330-00-571-7052
5330-00-571-7052 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 194120. A Sub NMFC of Z. It has a NMFC Description of WASHERS/GASKETS/PCKG DVCS NOI. 5330-00-571-7052 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 95100 which rates the freight between FCL and LCL. 5330-00-571-7052 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 713 for ocean manifesting and military sealift. 5330-00-571-7052 is not classified as a special type of cargo when transported by water. 5330-00-571-7052 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 5330-00-571-7052
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- Plated/Coated Item
- 2lb or less, one dimension 2" or less, other dimensions less than 24"
- Above 110G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- --
- --
- --
- --
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- No Requirement
- No Requirement
- Not Applicable
- MIL-DTL-117, Type III, Class C, Style 1, Medium Duty, Waterproof, Greaseproof, Opaque Bag
- No special marking
- No Requirement
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- 100
- PPP-B-566, PPP-B-676, or ASTM-D5118, Folding, Setup or Fiberboard Box
Contracting Technical Data File (CTDF) 5330-00-571-7052 October 2021
Criticality and Quality
- Critical Item Code:
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- T
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- N
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
