5330-00-332-4773
Packing Assembly
5330003324773 003324773 ST7M254-214-3 7214MT160T
Any combination of items manufactured from PACKING MATERIAL to predetermined dimensions, or any combination of nonmetallic molded or formed shapes (other than solid rubber or synthetic rubber rings having a square or rectangular cross section) specifically designed and manufactured for use as a seal. The assembly may include metal lantern rings, metal separators, and/or end or adapter rings. View more Packing Assembly
November 2023
4
Marketplace 5330-00-332-4773
Request a Quotation from participating marketplace vendors
Related Documents 5330-00-332-4773 3+ Documents (More...)
ST7M254-214-3 PACKING ASSEMBLY RQST NS Request Quotation Updated Every Day 5330-00-332-4773 RQST NE Updated
Every Day 5330-00-332-4773 RQST Updated Every Day 5330-00-332-4773 RQST NE Related Documents 5330-00
Restrictions 5330-00-332-4773
5330-00-332-4773 is a Packing Assembly that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item may be hazardous as it is in a Federal Supply Class for potentially hazardous items. A MSDS should be available from the supplier for the end user to evaluate any hazards. The precious metals content of this item is unknown.
End Users 5330-00-332-4773
- US Air Force (FXGI)
- Effective Date:
- 1 Apr 2006
- Former MOE Rule:
- FXKZ
- Republic of Korea (ZH01)
- Effective Date:
- 1 Sep 2010
Approved Sources 5330-00-332-4773
- Part Number
- Manufacturer
- Status
- ST7M254-214-3
- Manufacturer
- 76301 - The Boeing Company (Active)
- Primary Buy
- Primary Buy
- 7214MT160T
- 5F573 - Greene Tweed & Co Inc (Active)
- Secondary Buy
- Secondary Buy
- 7214MT160T
- 72902 - Palmetto Inc (Replaced)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 5330-00-332-4773
- Characteristic
- Specifications
- FIIG
- Specifications
- A032A0
- Cross-Sectional Shape Style [AAGR]
- Angle Top Ring
- Cross-Sectional Shape Style [AAGR]
- Angle Bottom Ring
- Height [HGTH]
- 0.297 Inches Nominal
- Material Document And Classification [MDCL]
- Mil-R-8791 Mil Spec Single Material Response Bottom Ring
- Material Document And Classification [MDCL]
- Mil-R-8791 Mil Spec Single Material Response Top Ring
- Material [MATT]
- Plastic Polytetrafluoroethylene Top Ring
- Material [MATT]
- Plastic Polytetrafluoroethylene Bottom Ring
- Material [MATT]
- Rubber Butadiene-Acrylonitrile Class Nbr Intermediate Ring
- Outside Diameter [ABHE]
- 1.259 Inches Nominal
- Inside Diameter [AARX]
- 0.981 Inches Nominal
- Intermediate Ring Quantity [ADTH]
- 1
- Joint Type [AQNE]
- Scarf-Peripheral Bottom Ring
- Joint Type [AQNE]
- Scarf-Peripheral Top Ring
- Material Document And Classification [MDCL]
- Mil-P-25732 Mil Spec Single Material Response Intermediate Ring
- Specification/Standard Data [ZZZK]
- 76301-St7-254 Manufacturers Specification
- Temp Rating [ABJH]
- -65.0 Deg Fahrenheit And 275.0 Deg Fahrenheit
Weapon Systems (WSDC) 5330-00-332-4773
DLA Procurement Analysis 5330-00-332-4773
- Last Stock Position:
- 163 In Stock
- DLA Administrative Lead Time:
- Subscribe
- DLA Production Lead Time:
- Subscribe
Management Data 5330-00-332-4773
Similar Supply Items to 5330-00-332-4773
Freight Information 5330-00-332-4773
5330-00-332-4773 has freight characteristics managed by the Southwestern Power Administration.It has a National Motor Freight Classification (NMFC) of 194120. A Sub NMFC of Z. It has a NMFC Description of WASHERS/GASKETS/PCKG DVCS NOI. 5330-00-332-4773 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 95100 which rates the freight between FCL and LCL. 5330-00-332-4773 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 772 for ocean manifesting and military sealift. 5330-00-332-4773 is not classified as a special type of cargo when transported by water. 5330-00-332-4773 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 5330-00-332-4773
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- Non-Metallic Item
- 2lb or less, one dimension 2" or less, other dimensions less than 24"
- Above 110G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- --
- --
- --
- --
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- No Requirement
- No Requirement
- Not Applicable
- MIL-DTL-117, Type III, Class C, Style 1, Medium Duty, Waterproof, Greaseproof, Opaque Bag
- No special marking
- No Requirement
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- --
- No Requirement
Procurement History 5330-00-332-4773 1 Records
Contracting Technical Data File (CTDF) 5330-00-332-4773 October 2021
Criticality and Quality
- Critical Item Code:
- X
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- L
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- N
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
