5330-00-286-7191
Plain Encased Seal
5330002867191 002867191 3686537 31876
A pliable rubber, felt, leather, or composition ring-shaped element, split or solid; with or without spring or spreader, having a metal shell on all or a portion of at least two of the outer surfaces. It may be designed to be either bolt mounted or pressmounted between fixed and moveable parts to form a tight and effective seal by the pressure of the spring or spreader or the resiliency inherent in the element material. Excludes PACKING WITH RETAINER. View more Plain Encased Seal
May 2023
4
Marketplace 5330-00-286-7191
Request a Quotation from participating marketplace vendors
Related Documents 5330-00-286-7191 5+ Documents (More...)
Photo 1/4 5330-00-286-7191 Photo 2/4 NSN 5330-00-286-7191 (Identification) 3/4 NSN 5330-00-286-
Updated Every Day 5330-00-286-7191 RQST NE Updated Every Day 5330-00-286-7191 RQST Updated Every Day
RQST NE Updated Every Day 2590-01-560-6657 RQST https//www.nsnlookup.com /fsg-53/fsc-5330/us 5330-00-286-7191
Plain Encased Seal 5330002867191 002867191 for $1 a day Upgrade your Account Upgrade 5330-00-286
/fsg-61/fsc-6110/us
fsc-6110/us 6110-01-561-8753 Power Distribution Panel 6110015618753 Panel6110015618753 015618753 80-31876
//www.nsnlookup.com /fsg-61/fsc-6110/us 6110-01-561-8753 Power Panel6110015618753 015618753 80-31876
-1 15275 - Hexco International Approved Sources 5120-01-227-1645 Part NumberManufacturerStatusT-31876
T-31876 Approved Sources 5120-01-227-1645 Part NumberManufacturerStatusT-31876-1 15275 - Hexco International
to enable JavaScript in your web browser . 5925-14-482-0648Circuit Breaker5925144820648 144820648 31876
enable JavaScript in your web browser . 2590-14-211-1908Boite De Derivation2590142111908 142111908 31876
Restrictions 5330-00-286-7191
5330-00-286-7191 is a Plain Encased Seal that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item may be hazardous as it is in a Federal Supply Class for potentially hazardous items. A MSDS should be available from the supplier for the end user to evaluate any hazards. The precious metals content of this item is unknown.
Import and Export 5330-00-286-7191
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5330-00-286-7191
- US Navy (N9BZ)
- Effective Date:
- 1 Mar 2005
- Former MOE Rule:
- N9ZD
- Supplementary Collaborators:
- HD
Approved Sources 5330-00-286-7191
- Part Number
- Manufacturer
- Status
- 31876
- Manufacturer
- 80201 - Skf Usa Inc. (Active)
- Original Design
- Original Design
- 3686537
- 7X677 - General Motors Llc (Active)
- Secondary Buy
- Secondary Buy
- 3686537
- 24617 - General Motors Corp (Active)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 5330-00-286-7191
- Characteristic
- Specifications
- FIIG
- Specifications
- A032A0
- Material [MATT]
- Wool Sealing Element A
- Material [MATT]
- Leather Sealing Element B
- Case Style [BHHL]
- Shouldered
- Sealing Element Style [CTQC]
- Vertical-Angular
- Seal Width [ADUC]
- 0.562 Inches Nominal
- Accommodated Shaft Maximum Rated Speed [AEAT]
- 2000 Feet Per Minute
- Accommodated Shaft Diameter [ABVM]
- 3.188 Inches Nominal
- Housing Bore Diameter [CPCW]
- 4.625 Inches Nominal
DLA Procurement Analysis 5330-00-286-7191
Management Data 5330-00-286-7191
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
NATO Stock Numbers Related to 5330-00-286-7191
Freight Information 5330-00-286-7191
5330-00-286-7191 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 194120. A Sub NMFC of Z. It has a NMFC Description of WASHERS/GASKETS/PCKG DVCS NOI. 5330-00-286-7191 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 95100 which rates the freight between FCL and LCL. 5330-00-286-7191 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 713 for ocean manifesting and military sealift. 5330-00-286-7191 is not classified as a special type of cargo when transported by water. 5330-00-286-7191 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Contracting Technical Data File (CTDF) 5330-00-286-7191 October 2021
Criticality and Quality
- Critical Item Code:
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- N
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- N
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
