5330-00-248-0214
Preformed Mechanical Felt
5330002480214 002480214 PGF4362 PGF4362A PGF4362C
An item manufactured to predetermined dimensions. It is either a precut strip or an item of various peripheral shapes and may contain bolt hole(s). It is used as a seal, wiper, mounting pad or for similar purposes. Excludes GASKET and PACKING PREFORMED. View more Preformed Mechanical Felt
May 2023
18
Marketplace 5330-00-248-0214
Request a Quotation from participating marketplace vendors
Related Documents 5330-00-248-0214 5+ Documents (More...)
Photo 1/4 5330-00-248-0214 Photo 2/4 NSN 5330-00-248-0214 (Identification) 3/4 NSN 5330-00-248-
5330-00-248-0214 1+ Documents ( More... ) https//www.nsnlookup.com /fsg-53/fsc-5330/us 5330-00-248-0214
Restrictions 5330-00-248-0214
5330-00-248-0214 is a Preformed Mechanical Felt that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item may be hazardous as it is in a Federal Supply Class for potentially hazardous items. A MSDS should be available from the supplier for the end user to evaluate any hazards. This item does not contain a precious metal.
Import and Export 5330-00-248-0214
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5330-00-248-0214
- Singapore (YJ01)
- Effective Date:
- 1 Apr 1991
- Malaysia (YW01)
- Effective Date:
- 1 Aug 2000
- Greece (ZU01)
- Effective Date:
- 1 Sep 1994
Approved Sources 5330-00-248-0214
- Part Number
- Manufacturer
- Status
- PGF4362
- Manufacturer
- 77237 - Dana Off Highway Products, Llc (Active)
- Primary Buy
- Primary Buy
- PGF4362A
- 77237 - Dana Off Highway Products, Llc (Active)
- Primary Buy
- Primary Buy
- PGF4362C
- 77237 - Dana Off Highway Products, Llc (Active)
- Primary Buy
- Primary Buy
- PGF4362
- 40152 - Vme Americas Inc Sub Of Vme Group N (Replaced)
- Canceled/Obsolete
- Canceled/Obsolete
- PGF4362A
- 40152 - Vme Americas Inc Sub Of Vme Group N (Replaced)
- Canceled/Obsolete
- Canceled/Obsolete
- PGF4362C
- 40152 - Vme Americas Inc Sub Of Vme Group N (Replaced)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 5330-00-248-0214
- Characteristic
- Specifications
- FIIG
- Specifications
- A032A0
- Material [MATT]
- Wool Overall
- Lubrication Method [AEAH]
- Impregnated
- Cross-Sectional Shape Style [AAGR]
- Rectangular
- Cross-Sectional Height [ADVN]
- 0.500 Inches Nominal
- Cross-Sectional Width [ADWH]
- 0.500 Inches Nominal
- Style Designator [STYL]
- Circular
- Outside Diameter [ABKV]
- 9.750 Inches Nominal
- Aperture Diameter [ABVL]
- 8.687 Inches Nominal
- Special Features [FEAT]
- Oil Lubrication
Similar Supply Items to 5330-00-248-0214
Freight Information 5330-00-248-0214
5330-00-248-0214 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 194020. A Sub NMFC of X. It has a NMFC Description of WASHERS/GASKETS/PCKG DVC ETC FELT. 5330-00-248-0214 is rated as class 100 when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 95050 which rates the freight between FCL and LCL. 5330-00-248-0214 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 596 for ocean manifesting and military sealift. 5330-00-248-0214 is not classified as a special type of cargo when transported by water. 5330-00-248-0214 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 5330-00-248-0214
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- Plated/Coated Item
- 2lb or less, one dimension 2" or less, other dimensions less than 24"
- Above 110G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- --
- --
- --
- --
- --
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- No Requirement
- No Requirement
- Not Applicable
- --
- No special marking
- No Requirement
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- PPP-B-566, PPP-B-676, or ASTM-D5118, Folding, Setup or Fiberboard Box
