5325-01-195-7599
Screw Thread Insert
5325011957599 011957599 1191-12CN-.516 1191-12CN516 0-170-030 REV C PC005 1191-12CN0516 1191-12CN-516
A cylindrical item which may have wrenching and/or driving facilities and/or shoulders. It is designed to be inserted in a drilled, tapped or a pretapped hole, or molded or pressed into soft material to reduce the size of a tapped hole; to provide threads; to add strength, and/or to prevent stripping. It is one of the following: (1) a one-piece, flanged or unflanged, internally threaded item which may have external threads, and/or serrations around the periphery of the collar, designed to engage a serrated lock ring which is not included with the item; (2) a one-piece precision coiled wire; (3) a two-piece item consisting of an internally threaded cylinder and a mating externally threaded part; or (4) a one-piece internally threaded item whose outside diameter is tapered and/or knurled and/or with fin(s). The internal thread of the item may have a locking feature. Excludes items having a sleeve on on its under portion which can be clinched or crimped. Excludes BUSHING,MACHINE THREAD; NUT,PLAIN,KNURLED; NUT,PLAIN,ROUND; NUT,PLAIN,CLINCH and NUT,SELF-LOCKING,CLINCH. See also NUT,PLAIN,PLATE View more Screw Thread Insert
June 2023
8
Marketplace 5325-01-195-7599
Request a Quotation from participating marketplace vendors
Related Documents 5325-01-195-7599 5+ Documents (More...)
Updated Every Day 5325-01-195-7599 RQST NE Updated Every Day 5325-01-195-7599 RQST Updated Every Day
RQST NE Updated Every Day 5325-01-195-7599 RQST Updated Every Day 5325-01-195-7599 RQST NE Restrictions
Restrictions 5325-01-195-7599
5325-01-195-7599 is a Screw Thread Insert that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
Import and Export 5325-01-195-7599
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5325-01-195-7599
- US Coast Guard (C918)
- Effective Date:
- 1 Mar 2006
- Former MOE Rule:
- C004
- Supplementary Receivers:
- XH
- US Navy (N9BZ)
- Effective Date:
- 1 Mar 2006
- Supplementary Collaborators:
- GTHD
Approved Sources 5325-01-195-7599
- Part Number
- Manufacturer
- Status
- 1191-12CN516
- Manufacturer
- 01556 - Emhart Teknologies Llc (Active)
- Primary Buy
- Primary Buy
- 0-170-030 REV C PC005
- 99193 - Honeywell International Inc. (Active)
- Secondary Buy
- Secondary Buy
- 1191-12CN0516
- 01556 - Emhart Teknologies Llc (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- 1191-12CN-516
- 26344 - New Haven Mfg Corp (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
- 1191-12CN-.516
- D9182 - Zf Industrieantriebe Witten Gmbh (Active)
- Advisory Reference
- Advisory Reference
Datasheet 5325-01-195-7599
- Characteristic
- Specifications
- FIIG
- Specifications
- A03100
- Material [MATT]
- Steel Corrosion Resisting Overall
- Material Document And Classification [MDCL]
- Ams 7245 Assn Std Single Material Response Overall
- Style Designator [STYL]
- Coil
- Length [ABRY]
- 0.516 Inches Nominal
- Insert Size [BZGJ]
- 0.876 In. Min,0.901 In. Max Free Od
- Thread Series Designator [THSD]
- Unf
- Nominal Thread Size [CQJX]
- 0.750 Inches
- Thread Quantity Per Inch [CMLP]
- 16
- Thread Class [AAJD]
- 3B
Weapon Systems (WSDC) 5325-01-195-7599
DLA Procurement Analysis 5325-01-195-7599
Management Data 5325-01-195-7599
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
Similar Supply Items to 5325-01-195-7599
Freight Information 5325-01-195-7599
5325-01-195-7599 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 095190. A Sub NMFC of Z. It has a NMFC Description of HARDWARE, NOI. 5325-01-195-7599 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 49790 which rates the freight between FCL and LCL. 5325-01-195-7599 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 713 for ocean manifesting and military sealift. 5325-01-195-7599 is not classified as a special type of cargo when transported by water. 5325-01-195-7599 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 5325-01-195-7599
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- Plated/Coated Item
- 2lb or less, one dimension 2" or less, other dimensions less than 24"
- Above 110G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- --
- --
- --
- Physical Protection
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- No Requirement
- No Requirement
- Not Applicable
- Any Suitable Container
- No special marking
- No Requirement
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- PPP-B-566, PPP-B-676, or ASTM-D5118, Folding, Setup or Fiberboard Box
