5325-00-771-3340
Turnlock Fastener Receptacle
5325007713340 007713340 CA1787 GR520AS1 483648-1 25P-FS00-400-DOO
A threaded or tempered item used to secure the STUD, TURNLOCK FASTENER or STUD ASSEMBLY, TURNLOCK FASTENER by engaging with the cross pin, cam lead threads, or eared nut of the STUD, TURNLOCK FASTENER and securing it by means of its thread locking or spring action. View more Turnlock Fastener Receptacle
November 2023
22
Marketplace 5325-00-771-3340
Request a Quotation from participating marketplace vendors
Updated Every Day Updated Every Day
Updated Every Day Related Documents 5325-00-771-3340 3+ Documents (More...)
CA1787 RECEPTACLE,TURNLOCK FASTENER 2 EA NS Request Quotation 25P-FS00-400-DOO RECEPTACLE,TURNLOCK FASTENER
1 EA NS Request Quotation GR520AS1 RECEPTACLE,TURNLOCK FASTENER 1 EA NS Request Quotation 483648-1 RECEPTACLE
vendors Request Restrictions 5325-99-616-5001 DEMIL https//www.nsnlookup.com /fsg-53/fsc-5325/us 5325-00-771-3340
Turnlock Fastener Receptacle 5325007713340 5325007713340CA1787 RECEPTACLE,TURNLOCK FASTENER 8 EA
RECEPTACLE 6 EA NS Request Quotation CA1787 RECEPTACLE 4 EA NS Request Quotation Subscribe to https/
/www.nsnlookup.com /fsg-53/fsc-5325/us 5325-00-771-3340 Turnlock Fastener Receptacle 5325007713340 CA1787
Restrictions 5325-00-771-3340
5325-00-771-3340 is a Turnlock Fastener Receptacle that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. The precious metals content of this item is unknown.
End Users 5325-00-771-3340
- US Army (A919)
- Effective Date:
- 1 Jun 2005
- Former MOE Rule:
- A187
- Supplementary Receivers:
- CL
- US Air Force (FXGI)
- Effective Date:
- 1 Jun 2005
- Former MOE Rule:
- FXKZ
- US Navy (N9BZ)
- Effective Date:
- 1 Jun 2005
- Former MOE Rule:
- N9ZD
- Supplementary Collaborators:
- GTKEHD
- Poland (WP01)
- Effective Date:
- 1 Jul 2005
- Spain (YB01)
- Effective Date:
- 1 Apr 1991
- Israel (YD01)
- Effective Date:
- 1 Aug 2016
- Malaysia (YW01)
- Effective Date:
- 1 Jul 1994
- Australia (ZA01)
- Effective Date:
- 1 Apr 1991
- Republic of Korea (ZH01)
- Effective Date:
- 1 Apr 1991
- United Kingdom (ZK01)
- Effective Date:
- 1 Apr 1991
- Netherlands (ZN01)
- Effective Date:
- 1 Jul 2000
- Turkey (ZW01)
- Effective Date:
- 1 Dec 2005
Approved Sources 5325-00-771-3340
- Part Number
- Manufacturer
- Status
- CA1787
- Manufacturer
- 29372 - Howmet Global Fastening Systems Inc. (Active)
- Primary Buy
- Primary Buy
- CA1787
- K1678 - Fairchild Fasteners Uk Ltd (Active)
- Secondary Buy
- Secondary Buy
- 483648-1
- 49956 - Raytheon Company (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- 25P-FS00-400-DOO
- K2193 - S T C Telecommunications Ltd (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
- GR520AS1
- 26512 - Northrop Grumman Systems Corporation (Active)
- Vendor Drawing
- Vendor Drawing
- 483648-1
- 3B150 - Raytheon Company (Active)
- Advisory Reference
- Advisory Reference
Datasheet 5325-00-771-3340
- Characteristic
- Specifications
- FIIG
- Specifications
- A05400
- Center To Center Distance Between Mounting Holes [ABTH]
- 0.870 Inches Minimum And 0.880 Inches Maximum
- Mounting Style [ADER]
- Floating Nut
- Material [MATT]
- Steel Overall
- Receptacle Height [AGSA]
- 0.780 Inches Nominal
- Receptacle Overall Length [AGRZ]
- 1.125 Inches Nominal
- Receptacle Thread Size And Series/Type Designator [ALBK]
- 0.250-28 Unc
- Receptacle Width [AGSB]
- 0.560 Inches Nominal
- Turnlock Receptacle Style [AGRY]
- Nonfloating
- Surface Treatment [SFTT]
- Cadmium Overall
Weapon Systems (WSDC) 5325-00-771-3340
DLA Procurement Analysis 5325-00-771-3340
- Last Stock Position:
- 547 In Stock
- DLA Administrative Lead Time:
- Subscribe
- DLA Production Lead Time:
- Subscribe
Management Data 5325-00-771-3340
Army
- Materiel Category and Inventory Manager:
- T
- Industrial Supplies (DLA/GSA Items)
- Appropriation and Budget Activity:
- 2
- Stock Fund Secondary Items
- Management Inventory Segment:
- 2
- Non-Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify items, which are not reparable.
- Weapons System / End Item / Homogeneous Group:
- 00
- DLA/GSA Material
DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item
- Accounting Requirements:
- X
- Expendable item.An item of Army property coded with an ARC of X in the AMDF. Expendable items require no formal accountability after issue from a stock record account.Commercial and fabricated items similar to items coded X in the AMDF are considered expendable items.
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
Similar Supply Items to 5325-00-771-3340
Freight Information 5325-00-771-3340
5325-00-771-3340 has freight characteristics managed by the Southwestern Power Administration.It has a National Motor Freight Classification (NMFC) of 066440. A Sub NMFC of Z. It has a NMFC Description of FASTENERS CURTAIN/SNAP METAL. 5325-00-771-3340 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 36960 which rates the freight between FCL and LCL. 5325-00-771-3340 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 713 for ocean manifesting and military sealift. 5325-00-771-3340 is not classified as a special type of cargo when transported by water. 5325-00-771-3340 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 5325-00-771-3340
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- Plated/Coated Item
- 2lb or less, one dimension 2" or less, other dimensions less than 24"
- Above 110G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- --
- --
- --
- Physical Protection
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- --
- --
- --
- PPP-B-566, PPP-B-676, or ASTM-D5118, Folding, Setup or Fiberboard Box
- No special marking
- --
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- --
- No Requirement
Procurement History 5325-00-771-3340 6 Records
- Contract
- Date
- CAGE
- Quantity
- Net Price
- Std Price
- CAGE
- SPE4A623PV023
- 21 Jul 2023
- Subscribe
- 489
- Subscribe
- Subscribe
- Subscribe
- SPE5E717P5054P00001
- 13 Sep 2017
- Subscribe
- 914
- Subscribe
- Subscribe
- Subscribe
- SPE5E817P2257
- 21 Mar 2017
- Subscribe
- 225
- Subscribe
- Subscribe
- Subscribe
- SPE5E417V2220
- 06 Dec 2016
- Subscribe
- 214
- Subscribe
- Subscribe
- Subscribe
- SPE5E415V0759
- 05 Nov 2014
- Subscribe
- 215
- Subscribe
- Subscribe
- Subscribe
- SPE5E414M1903
- 08 Jul 2014
- Subscribe
- 374
- Subscribe
- Subscribe
- Subscribe
Contracting Technical Data File (CTDF) 5325-00-771-3340 August 2020
Criticality and Quality
- Critical Item Code:
- X
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- F
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- N
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
