5325-00-641-2798
Turnlock Fastener Stud
5325006412798 006412798 98-0W2-12
A pinlike item designed to turn within and be held in place by an EYELET, TURNLOCK FASTENER; RING, RETAINING; or the surface of the item it fastens. It is provided with either a cam slot, cam lead threads, or a hold for accommodating a pin. Securing is accomplished by mating with a LOCKSPRING, TURNLOCK FASTENER or RECEPTACLE, TURNLOCK FASTENER. It has either provisions to accommodate a knob or extension or has a head which has provisions to facilitate turning. View more Turnlock Fastener Stud
May 2023
7
Marketplace 5325-00-641-2798
Request a Quotation from participating marketplace vendors
Related Documents 5325-00-641-2798 5+ Documents (More...)
5325-00-641-2798 1+ Documents ( More... ) https//www.nsnlookup.com /fsg-53/fsc-5325/us 5325-00-641-2798
Turnlock Fastener Stud 5325006412798 98-0W2-12 A pinlike item designed to turn within and be held in
Restrictions 5325-00-641-2798
5325-00-641-2798 is a Turnlock Fastener Stud that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. The precious metals content of this item is unknown.
Import and Export 5325-00-641-2798
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5325-00-641-2798
- Greece (ZU01)
- Effective Date:
- 1 Apr 1991
Approved Sources 5325-00-641-2798
- Part Number
- Manufacturer
- Status
- 98-0W2-12
- Manufacturer
- 78189 - Itw Shakeproof Automotive Products (Obsolete)
- Original Design
- Original Design
Datasheet 5325-00-641-2798
- Characteristic
- Specifications
- FIIG
- Specifications
- A05400
- Head Length [ABQW]
- 0.750 Inches Nominal
- Material [MATT]
- Steel Stud
- Material Accommodated Thickness [AGSM]
- 0.115 Inches Minimum And 0.124 Inches Maximum
- Turnlock Stud Head Style [AGRD]
- Flat Fillister Wing
- Stud Head Height [CQYY]
- 0.344 Inches Nominal
- Surface Treatment [SFTT]
- Cadmium Stud
Similar Supply Items to 5325-00-641-2798
Freight Information 5325-00-641-2798
5325-00-641-2798 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 066440. A Sub NMFC of Z. It has a NMFC Description of FASTENERS CURTAIN/SNAP METAL. 5325-00-641-2798 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. 5325-00-641-2798 is rated as a variable freight class when transported by Less-Than Carload (LCL) rail or ocean freight. It has a Uniform Freight Classification (UFC) number of 36960 which rates the freight between FCL and LCL. 5325-00-641-2798 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 713 for ocean manifesting and military sealift. 5325-00-641-2798 is not classified as a special type of cargo when transported by water. 5325-00-641-2798 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
