5325-00-298-7001
Turnlock Fastener Stud Assembly
5325002987001 002987001 0150-0147 8491113 2700-4 231313 NSA55131-104 971201-4 GB00581-4 G800581-4 457340-4
A STUD, TURNLOCK FASTENER over which may be assembled an EYELET, TURNLOCK FASTENER. Stud(s) without cam slots or cam lead threads are provided with a crosspin or eared nut for locking with the mating RECEPTACLE, TURNLOCK FASTENER. May be spring loaded. For like items having a threaded fastener, see SCREW ASSEMBLY, PANEL or SCREW, PANEL FASTENER. View more Turnlock Fastener Stud Assembly
November 2023
46
Marketplace 5325-00-298-7001
Request a Quotation from participating marketplace vendors
Related Documents 5325-00-298-7001 5+ Documents (More...)
Photo 1/3 NSN 5325-00-298-7001 (Identification) 2/3 NSN 5325-00-298-7001 (Identification) 3/3 -
-4457340-4 A STUD, TURNLOCK Photo 1/3 NSN 5325-00-298-7001 (Identification) 2/3 NSN 5325-00-298-7001
//www.nsnlookup.com /fsg-53/fsc-5325/us 5325-00-298-7001 Turnlock Fastener Stud Assembly 002987001 298
-7001Turnlock Fastener Stud Assembly5325002987001 002987001 2700-4 0150-0147 8491113 231313 NSA55131-
Turnlock Fastener Stud Assembly 002987001 Spacing Threaded Standoff 5340143927657 JavaScript in
298-7001Turnlock Fastener Stud Assembly5325002987001 002987001 2700-4 0150-0147 8491113 231313 NSA55131
2700-4 0150-0147 8491113 231313 NSA55131-104 DAC 3 231313 80045 - L3harris Cincinnati Electronics https
Turnlock Fastener Stud Assembly 002987001 298-7001Turnlock Fastener Stud Assembly5325002987001
www.nsnlookup.com /fsg-28/fsc-2815/uk 2815-99-009-7529 Piston Ring 2815990097529 990097529,231313-6 231313
how to enable JavaScript in your web browser . 2815 -99-009-7529Piston Ring2815990097529 990097529 231313
Restrictions 5325-00-298-7001
5325-00-298-7001 is a Turnlock Fastener Stud Assembly that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. The precious metals content of this item is unknown.
Import and Export 5325-00-298-7001
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5325-00-298-7001
- Austria (WB01)
- Effective Date:
- 1 Feb 2005
- Brazil (YA01)
- Effective Date:
- 1 Oct 2001
- Spain (YB01)
- Effective Date:
- 1 Apr 1991
- Kuwait (YK01)
- Effective Date:
- 1 Feb 2015
- Malaysia (YW01)
- Effective Date:
- 1 Aug 1997
- Australia (ZA01)
- Effective Date:
- 1 Apr 1991
- Canada (ZC01)
- Effective Date:
- 1 Apr 1991
- New Zealand (ZE01)
- Effective Date:
- 1 Apr 1991
- France (ZF01)
- Effective Date:
- 1 Apr 1991
- Germany (ZG01)
- Effective Date:
- 1 Apr 1991
- Republic of Korea (ZH01)
- Effective Date:
- 1 Apr 1991
- United Kingdom (ZK01)
- Effective Date:
- 1 Apr 1991
- Netherlands (ZN01)
- Effective Date:
- 1 Dec 1995
- Italy (ZR01)
- Effective Date:
- 1 Apr 1991
- Denmark (ZS01)
- Effective Date:
- 1 Apr 1991
- Greece (ZU01)
- Effective Date:
- 1 Apr 1991
- Turkey (ZW01)
- Effective Date:
- 1 Nov 1998
Approved Sources 5325-00-298-7001
- Part Number
- Manufacturer
- Status
- 2700-4
- Manufacturer
- 71286 - Howmet Global Fastening Systems Inc (Active)
- Primary Buy
- Primary Buy
- 0150-0147
- 1MY97 - Agilent Technologies, Inc. (Active)
- Secondary Buy
- Secondary Buy
- 8491113
- 18876 - Us Army Aviation And Missile Command (Active)
- Secondary Buy
- Secondary Buy
- 2700-4
- D0680 - Fairchild Fasteners Europe - Camloc (Active)
- Secondary Buy
- Secondary Buy
- 231313
- 80045 - L3harris Cincinnati Electronics (Active)
- Secondary Buy
- Secondary Buy
- NSA55131-104
- F5442 - Airbus Group Sas (Active)
- Secondary Buy
- Secondary Buy
- GB00581-4
- 01714 - Lucent Technologies Inc (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- 0150-0147
- 28480 - Hewlett-Packard Company (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- G800581-4
- 01714 - Lucent Technologies Inc (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- 457340-4
- 49671 - Lockheed Martin Corporation (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
- 971201-4
- 82577 - Raytheon Company (Active)
- Vendor Drawing
- Vendor Drawing
Datasheet 5325-00-298-7001
- Characteristic
- Specifications
- FIIG
- Specifications
- A05400
- Distance From Engaging Member To Largest Bearing Surface Of Head [AGRF]
- 0.560 Inches Minimum And 0.570 Inches Maximum
- Drive Type [AKCV]
- Slotted
- Diameter [ABMZ]
- 0.251 Inches Minimum And 0.256 Inches Maximum
- Eyelet Length [AGRK]
- 0.328 Inches Nominal
- Eyelet Outside Diameter [AGRH]
- 0.244 Inches Minimum And 0.250 Inches Maximum
- Material [MATT]
- Steel Overall
- Material Accommodated Thickness [AGSM]
- 0.120 Inches Minimum And 0.149 Inches Maximum
- Securing Device Type [ADQB]
- Washer
- Turnlock Stud Head Style [AGRD]
- Stud Head
- Stud Assembly Style [AGRE]
- Stud Assembly
- Stud Head Height [CQYY]
- 0.072 Inches Nominal
- Surface Treatment [SFTT]
- Cadmium Overall And Chromate Overall
NATO Stock Numbers Related to 5325-00-298-7001
Freight Information 5325-00-298-7001
5325-00-298-7001 has freight characteristics.. 5325-00-298-7001 has a variance between NMFC and UFC when transported by rail and the description should be consulted.
