5325-00-281-5060
Turnlock Fastener Stud
5325002815060 002815060 AW5T38 K55203-138 2501-W20-38-C3C AW5T37
A pinlike item designed to turn within and be held in place by an EYELET, TURNLOCK FASTENER; RING, RETAINING; or the surface of the item it fastens. It is provided with either a cam slot, cam lead threads, or a hold for accommodating a pin. Securing is accomplished by mating with a LOCKSPRING, TURNLOCK FASTENER or RECEPTACLE, TURNLOCK FASTENER. It has either provisions to accommodate a knob or extension or has a head which has provisions to facilitate turning. View more Turnlock Fastener Stud
May 2023
4
Marketplace 5325-00-281-5060
Request a Quotation from participating marketplace vendors
Related Documents 5325-00-281-5060 5+ Documents (More...)
Photo 1/3 NSN 5325-00-281-5060 (Identification) 2/3 NSN 5325-00-281-5060 (Identification) 3/3 -
AW5T38 STUD,TURNLOCK FASTENER 18 EA NS Request Quotation FedMall Updated Every 15 Minutes 5325-00-281
Restrictions 5325-00-281-5060
5325-00-281-5060 is a Turnlock Fastener Stud that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. The precious metals content of this item is unknown.
Import and Export 5325-00-281-5060
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5325-00-281-5060
- US Army (A919)
- Effective Date:
- 1 Mar 2006
- Former MOE Rule:
- A187
- Supplementary Receivers:
- CT
- US Navy (N9BZ)
- Effective Date:
- 1 Mar 2006
- Supplementary Collaborators:
- KE
Approved Sources 5325-00-281-5060
- Part Number
- Manufacturer
- Status
- AW5T38
- Manufacturer
- 72794 - Southco Inc (Active)
- Primary Buy
- Primary Buy
- K55203-138
- 88277 - The Boeing Company (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- 2501-W20-38-C3C
- 72794 - Southco Inc (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- AW5T37
- 72794 - Southco Inc (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- K55203-138
- 18355 - The Boeing Company (Active)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 5325-00-281-5060
- Characteristic
- Specifications
- FIIG
- Specifications
- A05400
- Grip Length [AATQ]
- 0.670 Inches Nominal
- Head Length [ABQW]
- 1.125 Inches Nominal
- Material [MATT]
- Steel Overall
- Nondefinitive Spec/Std Data [ZZZT]
- 3 Type And 1 Style And A Class And B Class And 5 Size
- Material Accommodated Thickness [AGSM]
- 0.361 Inches Minimum And 0.370 Inches Maximum
- Shank Neck Length [CQYN]
- 0.490 Inches Nominal
- Turnlock Stud Head Style [AGRD]
- Fillister Wing
- Turnlock Stud Shank Style [AGQY]
- Stud Shank
- Stud Head Height [CQYY]
- 0.438 Inches Nominal
- Stud Shank Major Diameter [CSGB]
- 0.306 Inches Minimum And 0.311 Inches Maximum
- Surface Treatment [SFTT]
- Cadmium Overall
DLA Procurement Analysis 5325-00-281-5060
Management Data 5325-00-281-5060
Army
- Materiel Category and Inventory Manager:
- T
- Industrial Supplies (DLA/GSA Items)
- Appropriation and Budget Activity:
- 2
- Stock Fund Secondary Items
- Management Inventory Segment:
- 2
- Non-Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify items, which are not reparable.
- Weapons System / End Item / Homogeneous Group:
- 00
- DLA/GSA Material
DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item
- Accounting Requirements:
- X
- Expendable item.An item of Army property coded with an ARC of X in the AMDF. Expendable items require no formal accountability after issue from a stock record account.Commercial and fabricated items similar to items coded X in the AMDF are considered expendable items.
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
Similar Supply Items to 5325-00-281-5060
Freight Information 5325-00-281-5060
5325-00-281-5060 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 066440. A Sub NMFC of Z. It has a NMFC Description of FASTENERS CURTAIN/SNAP METAL. 5325-00-281-5060 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 36960 which rates the freight between FCL and LCL. 5325-00-281-5060 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 713 for ocean manifesting and military sealift. 5325-00-281-5060 is not classified as a special type of cargo when transported by water. 5325-00-281-5060 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 5325-00-281-5060
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- Plated/Coated Item
- 2lb or less, one dimension 2" or less, other dimensions less than 24"
- Above 110G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- --
- --
- --
- --
- Physical Protection
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- No Requirement
- --
- Not Applicable
- PPP-B-566, PPP-B-676, or ASTM-D5118, Folding, Setup or Fiberboard Box
- No special marking
- No Requirement
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- --
- No Requirement
Procurement History 5325-00-281-5060 2 Records
Contracting Technical Data File (CTDF) 5325-00-281-5060 August 2020
Criticality and Quality
- Critical Item Code:
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- N
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
