5325-00-241-7292
Turnlock Fastener Receptacle
5325002417292 002417292 PAF50-4-5-3 C393-4-5-3 1950-4-5-3
A threaded or tempered item used to secure the STUD, TURNLOCK FASTENER or STUD ASSEMBLY, TURNLOCK FASTENER by engaging with the cross pin, cam lead threads, or eared nut of the STUD, TURNLOCK FASTENER and securing it by means of its thread locking or spring action. View more Turnlock Fastener Receptacle
May 2023
8
Marketplace 5325-00-241-7292
Request a Quotation from participating marketplace vendors
Related Documents 5325-00-241-7292 5+ Documents (More...)
Photo 1/5 5325-00-241-7292 Photo 2/5 5325-00-241-7292 Photo 3/5 NSN 5325-00-241-7292 (Identification
) https//www.nsnlookup.com /fsg-53/fsc-5325/us 5325-00-241-7292 Turnlock Fastener Receptacle 5325002417292
Turnlock Fastener Receptacle 5325002417292 Photo 1/5 5325-00-241-7292 Photo 2/5 5325-00-241-7292
Photo 3/5 NSN 5325-00-241-7292 (Identification Every Day 5325-00-241-7292 RQST NE Related Documents
Restrictions 5325-00-241-7292
5325-00-241-7292 is a Turnlock Fastener Receptacle that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. The precious metals content of this item is unknown.
End Users 5325-00-241-7292
- US Air Force (FXGI)
- Effective Date:
- 1 Aug 2005
- Former MOE Rule:
- FXKZ
Approved Sources 5325-00-241-7292
- Part Number
- Manufacturer
- Status
- PAF50-4-5-3
- Manufacturer
- 80539 - Sps Technologies, Llc (Active)
- Primary Buy
- Primary Buy
- PAF50-4-5-3
- 92215 - Howmet Global Fastening Systems Inc (Active)
- Primary Buy
- Primary Buy
- 1950-4-5-3
- 80539 - Sps Technologies, Llc (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- 1950-4-5-3
- 92215 - Howmet Global Fastening Systems Inc (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- C393-4-5-3
- 81755 - Lockheed Martin Corporation (Active)
- Vendor Drawing
- Vendor Drawing
Datasheet 5325-00-241-7292
- Characteristic
- Specifications
- FIIG
- Specifications
- A05400
- Center To Center Distance Between Mounting Holes [ABTH]
- 0.750 Inches Nominal
- Mounting Style [ADER]
- Plain W/Mounting Hole
- Material [MATT]
- Steel Comp 1050 Retainer
- Material [MATT]
- Steel Comp 8740 Barrel
- Material [MATT]
- Steel Comp 8740 Stud
- Receptacle Height [AGSA]
- 0.395 Inches Maximum
- Receptacle Overall Length [AGRZ]
- 1.012 Inches Maximum
- Receptacle Thread Size And Series/Type Designator [ALBK]
- 0.164-32 Unjc
- Receptacle Width [AGSB]
- 0.410 Inches Maximum
- Special Features [FEAT]
- Stud Protrudes 0.187In.
- Turnlock Mounting Hole Diameter [CSYB]
- 0.098 Inches Nominal
- Turnlock Receptacle Style [AGRY]
- Receptacle
- Surface Treatment Document And Classification [STDC]
- Qq-P-416,Type 2 Class 2 Fed Spec All Treatment Responses Overall
- Surface Treatment [SFTT]
- Cadmium Overall And Chromate Overall
DLA Procurement Analysis 5325-00-241-7292
Management Data 5325-00-241-7292
Similar Supply Items to 5325-00-241-7292
Freight Information 5325-00-241-7292
5325-00-241-7292 has freight characteristics managed by the Southwestern Power Administration.It has a National Motor Freight Classification (NMFC) of 066440. A Sub NMFC of Z. It has a NMFC Description of FASTENERS CURTAIN/SNAP METAL. 5325-00-241-7292 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 36960 which rates the freight between FCL and LCL. 5325-00-241-7292 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 713 for ocean manifesting and military sealift. 5325-00-241-7292 is not classified as a special type of cargo when transported by water. 5325-00-241-7292 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 5325-00-241-7292
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- Plated/Coated Item
- 2lb or less, one dimension 2" or less, other dimensions less than 24"
- Above 110G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- --
- --
- --
- --
- Physical Protection
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- No Requirement
- No Requirement
- Not Applicable
- PPP-B-566, PPP-B-676, or ASTM-D5118, Folding, Setup or Fiberboard Box
- No special marking
- No Requirement
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- --
- No Requirement
Contracting Technical Data File (CTDF) 5325-00-241-7292 August 2020
Criticality and Quality
- Critical Item Code:
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- N
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- N
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
