5320-01-497-7880
Blind Rivet
5320014977880 014977880 CR3242-5-11 3242-5-11
An item consisting of two or more of the following components: stem, rivet body, sleeve, expander, bolt, and collar. It is a headed fastening device with the shank designed to be expanded by means of a separate or integral stem or mandrel, or bolt and expander. It is designed to be installed or expanded from one side only. Excludes NUT, BLIND ASSEMBLY. View more Blind Rivet
November 2023
8
Marketplace 5320-01-497-7880
Request a Quotation from participating marketplace vendors
Related Documents 5320-01-497-7880 2+ Documents (More...)
Photo 1/3 NSN 5320-01-497-7880 (Identification) 2/3 NSN 5320-01-497-7880 (Identification) 3/3 -
CR3242-5-11 RIVET,BLIND 39 EA NS Request Quotation Updated Every Day 5320-01-497-7880 RQST NE Updated
https//www.nsnlookup.com /fsg-53/fsc-5320/ca 5320-21-895-0382 Blind Rivet 5320218950382218950382 CR3242-5-11
Blind Rivet 5320014977880 014977880 Upgrade for $1 a day Upgrade your Account Upgrade 5320-01-497
Restrictions 5320-01-497-7880
5320-01-497-7880 is a Blind Rivet that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. The DCMO has forced the Demilization requirements for this item as the ICP has not collaborated. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
Import and Export 5320-01-497-7880
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5320-01-497-7880
- US Air Force (FUGI)
- Effective Date:
- 1 Mar 2006
- Former MOE Rule:
- FUKZ
- US Navy (N9BZ)
- Effective Date:
- 1 Dec 2013
- Supplementary Collaborators:
- GGGT
- Columbia (YC01)
- Effective Date:
- 1 Jun 2015
Approved Sources 5320-01-497-7880
- Part Number
- Manufacturer
- Status
- CR3242-5-11
- Manufacturer
- 11815 - Sps Technologies, Llc (Active)
- Primary Buy
- Primary Buy
- 3242-5-11
- 11815 - Sps Technologies, Llc (Active)
- Original Design
- Original Design
Datasheet 5320-01-497-7880
- Characteristic
- Specifications
- FIIG
- Specifications
- A040A0
- Countersink Angle [CRSQ]
- 100.0 Degrees Nominal
- Expansion Device [ABAF]
- Serrated Stem-Type W
- Fastener Length [AASB]
- 0.809 Inches Nominal
- Grip Length [ANEE]
- 0.6405 Inches Nominal
- Head Major Diameter [AAZG]
- 0.282 Inches Minimum And 0.290 Inches Maximum
- Head Style [AASK]
- Flush (Flat) Countersunk (Included Angle - Less Than 135 Deg W Or W/O Chamfer)
- Material [MATT]
- Aluminum Alloy 1100 Sleeve
- Material [MATT]
- Iron Alloy 660 Collar
- Material [MATT]
- Steel Stem
- Shank Diameter [AAZE]
- 0.172 Inches Minimum And 0.176 Inches Maximum
- Shank Style [AAZF]
- Self-Plugging Mechanically Locked Stem
Weapon Systems (WSDC) 5320-01-497-7880
DLA Procurement Analysis 5320-01-497-7880
- Last Stock Position:
- 705 In Stock
- DLA Administrative Lead Time:
- Subscribe
- DLA Production Lead Time:
- Subscribe
Management Data 5320-01-497-7880
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
Similar Supply Items to 5320-01-497-7880
Freight Information 5320-01-497-7880
5320-01-497-7880 has freight characteristics managed by the Southwestern Power Administration.It has a National Motor Freight Classification (NMFC) of 096320. A Sub NMFC of X. It has a NMFC Description of RIVETS I/S NICKEL PLATED BUFFED. 5320-01-497-7880 is rated as class 77.5 when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 50430 which rates the freight between FCL and LCL. 5320-01-497-7880 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 713 for ocean manifesting and military sealift. 5320-01-497-7880 is not classified as a special type of cargo when transported by water. 5320-01-497-7880 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 5320-01-497-7880
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- Bare Metal Item
- 2lb or less, one dimension 2" or less, other dimensions less than 24"
- Above 110G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- --
- --
- --
- --
- Physical Protection
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- No Requirement
- No Requirement
- Not Applicable
- Any Suitable Container
- No special marking
- No Requirement
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- PPP-B-566, PPP-B-676, or ASTM-D5118, Folding, Setup or Fiberboard Box
Procurement History 5320-01-497-7880 1 Records
Contracting Technical Data File (CTDF) 5320-01-497-7880 August 2020
Criticality and Quality
- Critical Item Code:
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- F
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- N
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
