5320-01-463-6407
Solid Rivet
5320014636407 014636407 NASM20426A06-12 MS20426A06-12
A headed fastening device having a smooth solid shank designed to have the shank end upset after insertion. View more Solid Rivet
May 2023
3
Marketplace 5320-01-463-6407
Request a Quotation from participating marketplace vendors
Related Documents 5320-01-463-6407 5+ Documents (More...)
Photo 1/3 NSN 5320-01-463-6407 (Identification) 2/3 NSN 5320-01-463-6407 (Identification) 3/3 -
MS20426A06-12 RIVET,SOLID 468 EA NS Request Quotation Updated Every Day 5320-01-463-6407 RQST NE Updated
Restrictions 5320-01-463-6407
5320-01-463-6407 is a Solid Rivet that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
Import and Export 5320-01-463-6407
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5320-01-463-6407
- Norway (ZT01)
- Effective Date:
- 1 Mar 1999
Approved Sources 5320-01-463-6407
- Part Number
- Manufacturer
- Status
- MS20426A06-12
- Manufacturer
- 80205 - National Aerospace Standards (Active)
- Primary Buy
- Primary Buy
- NASM20426A06-12
- 80205 - National Aerospace Standards (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- MS20426A06-12
- 96906 - Military Standards (Active)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 5320-01-463-6407
- Characteristic
- Specifications
- FIIG
- Specifications
- A040A0
- Countersink Angle [CRSQ]
- 100.0 Degrees Nominal
- Fastener Length [AASB]
- 18.8 Millimeters Minimum And 19.3 Millimeters Maximum
- Head Major Diameter [AAZG]
- 17.5 Millimeters Minimum And 17.7 Millimeters Maximum
- Head Style [AASK]
- Flush (Flat) Countersunk (Included Angle - Less Than 135 Deg W Or W/O Chamfer)
- Material [MATT]
- Aluminum Alloy 1100 Overall
- Shank Diameter [AAZE]
- 9.5 Millimeters Nominal
- Shank Style [AAZF]
- Straight W/Radius Chamfered Tip
Similar Supply Items to 5320-01-463-6407
Freight Information 5320-01-463-6407
5320-01-463-6407 has freight characteristics.. 5320-01-463-6407 has a variance between NMFC and UFC when transported by rail and the description should be consulted.
