5320-01-355-4797
Blind Rivet
5320013554797 013554797 CR3523-4-07 NAS9307M-4-07 AF3523-4-07 ASN-A0078E407 A0078E407 MIL-R-7885/4 CR3523-4-7 M7885/4-4-07
An item consisting of two or more of the following components: stem, rivet body, sleeve, expander, bolt, and collar. It is a headed fastening device with the shank designed to be expanded by means of a separate or integral stem or mandrel, or bolt and expander. It is designed to be installed or expanded from one side only. Excludes NUT, BLIND ASSEMBLY. View more Blind Rivet
Managed by United States
NSN Created on 19 Mar 1992
Data Last Changed
November 2023
November 2023
NATO Update Count
26
26
NATO Data Quality
Marketplace 5320-01-355-4797
Need Help?
Request a Quotation from participating marketplace vendors
Request a Quotation from participating marketplace vendors
Related Documents 5320-01-355-4797 5+ Documents (More...)
CR3523-4-07 NAS9307M-4-07 AF3523-4-07 ASN-A0078E407 A0078E407 MIL-R-7885/4 CR3523-4-7 M7885/4-4-07 An
CR3523-4-7 RIVET,BLIND 99 EA NS Request Quotation CR3523-4-07 RIVET,BLIND 99 EA NS Request Quotation
CR3523-4-07 RIVET,BLIND 8 EA NS Request Quotation Updated Every Day 5320-01-355-4797 RQST NE Updated
CR3523-4-7 RIVET,BLIND 99 EA NS Request Quotation CR3523-4-07 RIVET,BLIND 99 EA NS Request Quotation
CR3523-4-07 RIVET,BLIND 8 EA NS Request Quotation Updated Every Day 5320-01-355-4797 RQST NE Updated
CR3523-4-7 A0078E407 ASN-A0078E407 An item consisting of two or more of the following components
CR3523-4-7 RIVET,BLIND 99 EA NS Request Quotation CR3523-4-07 RIVET,BLIND 99 EA NS Request Quotation
Blind Rivet 5320013554797 013554797 NAS9307M-4-07 AF3523-4-07 ASN-A0078E407A0078E407 MIL-R-7885
CR3523-4-7 RIVET,BLIND 99 EA NS Request Quotation CR3523-4-07 RIVET,BLIND 99 EA NS Request Quotation
Blind Rivet 5320013554797 013554797 NAS9307M-4-07 AF3523-4-07 ASN-A0078E407A0078E407 MIL-R-7885
Upgrade 5320-01-388-3811Blind Rivet5320013883811 013883811 CR3523-6-10 NAS9307M-6-10 M7885/4-6-10 MIL-R-7885/4
Management CR3523-6-7 Blind Rivet 5320013737313013737313 Canceled/Obsolete RNCC 5 RNVC 9 DAC 4 MIL-R-7885/4
Upgrade 5320-01-152-8684Blind Rivet5320011528684 011528684 NAS9307M-6-05 AF3523-6-05 CR3523-6-05 MIL-R-7885/4
Management CR3523-6-7 Blind Rivet 5320013737313013737313 Canceled/Obsolete RNCC 5 RNVC 9 DAC 4 MIL-R-7885/4
Upgrade 5320-01-152-8684Blind Rivet5320011528684 011528684 NAS9307M-6-05 AF3523-6-05 CR3523-6-05 MIL-R-7885/4
01-388-3815Blind Rivet5320013883815 013883815 CR3523-4-5 CR3523-4-05 NAS9307M-4-05 M7885/4-4-05 MIL-R-7885/4
Management CR3523-6-7 Blind Rivet 5320013737313013737313 Canceled/Obsolete RNCC 5 RNVC 9 DAC 4 MIL-R-7885/4
Upgrade 5320-01-152-8684Blind Rivet5320011528684 011528684 NAS9307M-6-05 AF3523-6-05 CR3523-6-05 MIL-R-7885/4
Management CR3523-6-7 Blind Rivet 5320013737313013737313 Canceled/Obsolete RNCC 5 RNVC 9 DAC 4 MIL-R-7885/4
Upgrade 5320-01-152-8684Blind Rivet5320011528684 011528684 NAS9307M-6-05 AF3523-6-05 CR3523-6-05 MIL-R-7885/4
7313Blind Rivet5320013737313 013737313 NAS9307M-6-07 CR3523-6-7 AF3523-6-07 CR3523-6-07 M7885/4-6-07 MIL-R-7885/4
Management CR3523-6-7 Blind Rivet 5320013737313013737313 Canceled/Obsolete RNCC 5 RNVC 9 DAC 4 MIL-R-7885/4
Upgrade 5320-01-152-8684Blind Rivet5320011528684 011528684 NAS9307M-6-05 AF3523-6-05 CR3523-6-05 MIL-R-7885/4
Management CR3523-6-7 Blind Rivet 5320013737313013737313 Canceled/Obsolete RNCC 5 RNVC 9 DAC 4 MIL-R-7885/4
Upgrade 5320-01-152-8684Blind Rivet5320011528684 011528684 NAS9307M-6-05 AF3523-6-05 CR3523-6-05 MIL-R-7885/4
Restrictions 5320-01-355-4797
5320-01-355-4797 is a Blind Rivet that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
Import and Export 5320-01-355-4797
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5320-01-355-4797
- US Army (A919)
- Effective Date:
- 1 Apr 2006
- Former MOE Rule:
- A187
- Supplementary Receivers:
- CT
- US Coast Guard (C920)
- Effective Date:
- 1 Sep 2009
- US Air Force (FXGI)
- Effective Date:
- 1 Apr 2006
- Former MOE Rule:
- FXKZ
- US Navy (N9BZ)
- Effective Date:
- 1 Apr 2006
- Former MOE Rule:
- N9ZD
- Supplementary Collaborators:
- GTKE
- Brazil (YA01)
- Effective Date:
- 1 May 2008
- Spain (YB01)
- Effective Date:
- 1 May 2008
- Columbia (YC01)
- Effective Date:
- 1 Jun 2015
- Singapore (YJ01)
- Effective Date:
- 1 May 2008
- Australia (ZA01)
- Effective Date:
- 1 Apr 2012
- Belgium (ZB01)
- Effective Date:
- 1 May 2008
- Canada (ZC01)
- Effective Date:
- 1 May 2008
- New Zealand (ZE01)
- Effective Date:
- 1 May 2008
- France (ZF01)
- Effective Date:
- 1 May 2008
- Republic of Korea (ZH01)
- Effective Date:
- 1 May 2008
- United Kingdom (ZK01)
- Effective Date:
- 1 May 2008
- Netherlands (ZN01)
- Effective Date:
- 1 Oct 2008
- Italy (ZR01)
- Effective Date:
- 1 May 2008
- Denmark (ZS01)
- Effective Date:
- 1 May 2008
- Turkey (ZW01)
- Effective Date:
- 1 May 2008
Approved Sources 5320-01-355-4797
- Part Number
- Manufacturer
- Status
- CR3523-4-07
- Manufacturer
- 11815 - Sps Technologies, Llc (Active)
- Primary Buy
- Primary Buy
- NAS9307M-4-07
- 80205 - National Aerospace Standards (Active)
- Primary Buy
- Primary Buy
- AF3523-4-07
- 53551 - Allfast Fastening Systems, Llc (Active)
- Secondary Buy
- Secondary Buy
- ASN-A0078E407
- F5442 - Airbus Group Sas (Active)
- Secondary Buy
- Secondary Buy
- CR3523-4-7
- FB009 - Boeing Distribution Services Inc (Active)
- Secondary Buy
- Secondary Buy
- CR3523-4-7
- R1120 - Satair A/S (Active)
- Secondary Buy
- Secondary Buy
- A0078E407
- F5442 - Airbus Group Sas (Active)
- Secondary Buy
- Secondary Buy
- MIL-R-7885/4
- 81349 - Military Specifications (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- CR3523-4-7
- F7652 - Klx Aerospace Solutions Ii Sas (Replaced)
- Canceled/Obsolete
- Canceled/Obsolete
- M7885/4-4-07
- 81349 - Military Specifications (Active)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 5320-01-355-4797
- Characteristic
- Specifications
- FIIG
- Specifications
- A040A0
- Expansion Device [ABAF]
- Serrated Stem-Type W
- Fastener Length [AASB]
- 0.537 Inches Nominal
- Grip Length [ANEE]
- 0.376 Inches Minimum And 0.437 Inches Maximum
- Head Height [AASU]
- 0.054 Inches Minimum And 0.064 Inches Maximum
- Head Major Diameter [AAZG]
- 0.240 Inches Minimum And 0.260 Inches Maximum
- Head Style [AASK]
- Universal
- Material Document And Classification [MDCL]
- Qq-N-281 Fed Spec All Material Responses Sleeve
- Material [MATT]
- Nickel Alloy R-405 Or Nickel Alloy 400 Sleeve
- Material [MATT]
- Steel Comp 632 Stem
- Material Document And Classification [MDCL]
- Ams 5657 Assn Std Single Material Response Stem
- Shank Diameter [AAZE]
- 0.125 Inches Minimum And 0.129 Inches Maximum
- Shank Style [AAZF]
- Self-Plugging Mechanically Locked Stem
Weapon Systems (WSDC) 5320-01-355-4797
DLA Procurement Analysis 5320-01-355-4797
- Last Stock Position:
- 57 In Stock
- DLA Administrative Lead Time:
- Subscribe
- DLA Production Lead Time:
- Subscribe
Management Data 5320-01-355-4797
Army
- Materiel Category and Inventory Manager:
- T
- Industrial Supplies (DLA/GSA Items)
- Appropriation and Budget Activity:
- 2
- Stock Fund Secondary Items
- Management Inventory Segment:
- 2
- Non-Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify items, which are not reparable.
- Weapons System / End Item / Homogeneous Group:
- 00
- DLA/GSA Material
DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item
- Accounting Requirements:
- X
- Expendable item.An item of Army property coded with an ARC of X in the AMDF. Expendable items require no formal accountability after issue from a stock record account.Commercial and fabricated items similar to items coded X in the AMDF are considered expendable items.
Air Force
- Fund:
- SF
- Stock fund applicable to items managed for the Air Force by the respective Inventory Control Point
- Budget:
- 9
- 57X4921.070 - General Support DIV - Air Force decentralized managed expense items (ERRC XB3, XF3) with a unit cost of less than $250,000 that are requisitioned/procured at base (retail) level from DLA, GSA, Army, Navy, Depot Maintenance Service, Air Force Industrial Fund (AFMC), local manufacture and commercial vendors
- Aggregation Code:
- SX
- SICA RESIDUAL MMAC-OC-ALC
- Price Validation Code:
- N
- The current standard price in Catalog Management Data (CMD) has not analyzed or coded for LP/LM.
The price has not been analyzed or reviewed for accuracy.
ZOP or Standard price challenges are permissible but must be supported with adequate justification. However, if coded for Local Purchase (LP) or Fabrication/Manufacture as indicated with an (LM) Acquisition Advice Code of “L” or “F”, then it must be evaluated locally where purchased or fabricated.
- Expendability
Recoverability
Repairability: - N
- Expendable. Condemn at User. Stock Fund (except Munitions).
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
NATO Stock Numbers Related to 5320-01-355-4797
5320-12-379-7694 5320-12-375-6211 5320-34-036-5105 5320-99-737-6610 5320-99-737-6565 5320-99-738-0091 5320-99-737-6557 5320-21-077-0736 5320-99-737-6570 5320-12-351-6287 5320-99-737-7669 5320-99-741-1587 5320-99-471-4420 5320-12-303-0732 5320-99-737-6614 5320-17-706-8543 5320-99-737-7668 5320-12-353-7851
Freight Information 5320-01-355-4797
5320-01-355-4797 has freight characteristics managed by the Southwestern Power Administration.It has a National Motor Freight Classification (NMFC) of 139820. A Sub NMFC of X. It has a NMFC Description of NICKEL BOLTS/NAILS/NUTS/RIVETS ETC. 5320-01-355-4797 is rated as class 85 when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 70220 which rates the freight between FCL and LCL. 5320-01-355-4797 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 713 for ocean manifesting and military sealift. 5320-01-355-4797 is not classified as a special type of cargo when transported by water. 5320-01-355-4797 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 5320-01-355-4797
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- Plated/Coated Item
- 2lb or less, one dimension 2" or less, other dimensions less than 24"
- Above 110G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- --
- --
- --
- --
- Physical Protection
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- --
- --
- --
- Bags made of material conforming to MIL-P-130, MIL-DTL-17667, MIL-PRF-121, or any material authorized by MIL-DTL-117. Closure may be by staples, tape, adhesive or heat seal
- No special marking
- --
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- PPP-B-566, PPP-B-676, or ASTM-D5118, Folding, Setup or Fiberboard Box
Procurement History 5320-01-355-4797 4 Records
Contracting Technical Data File (CTDF) 5320-01-355-4797 August 2020
Criticality and Quality
- Critical Item Code:
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- F
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- N
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
