5320-01-339-4081
Blind Rivet
5320013394081 013394081 CR3552P-5-6
An item consisting of two or more of the following components: stem, rivet body, sleeve, expander, bolt, and collar. It is a headed fastening device with the shank designed to be expanded by means of a separate or integral stem or mandrel, or bolt and expander. It is designed to be installed or expanded from one side only. Excludes NUT, BLIND ASSEMBLY. View more Blind Rivet
May 2023
9
Marketplace 5320-01-339-4081
Request a Quotation from participating marketplace vendors
Related Documents 5320-01-339-4081 5+ Documents (More...)
5320-01-339-4081 1+ Documents ( More... ) https//www.nsnlookup.com /fsg-53/fsc-5320/us 5320-01-339-4081
: stem, rivet body, sleeve, Photo 1/3 NSN 5320-01-339-4081 (Identification) 2/3 NSN 5320-01-339-4081
Restrictions 5320-01-339-4081
5320-01-339-4081 is a Blind Rivet that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. The precious metals content of this item is unknown.
Import and Export 5320-01-339-4081
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5320-01-339-4081
- France (ZF01)
- Effective Date:
- 1 Apr 1991
- Germany (ZG01)
- Effective Date:
- 1 Apr 1991
Approved Sources 5320-01-339-4081
- Part Number
- Manufacturer
- Status
- CR3552P-5-6
- Manufacturer
- 11815 - Sps Technologies, Llc (Active)
- Primary Buy
- Primary Buy
- CR3552P-5-6
- FB009 - Boeing Distribution Services Inc (Active)
- Secondary Buy
- Secondary Buy
- CR3552P-5-6
- R1120 - Satair A/S (Active)
- Secondary Buy
- Secondary Buy
- CR3552P-5-6
- F7652 - Klx Aerospace Solutions Ii Sas (Replaced)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 5320-01-339-4081
- Characteristic
- Specifications
- FIIG
- Specifications
- A040A0
- Countersink Angle [CRSQ]
- 100.0 Degrees Nominal
- Fastener Length [AASB]
- 0.562 Inches Maximum
- Grip Length [ANEE]
- 0.172 Inches Minimum And 0.176 Inches Maximum
- Head Major Diameter [AAZG]
- 0.282 Inches Minimum And 0.290 Inches Maximum
- Head Style [AASK]
- Flush (Flat) Countersunk (Included Angle - Less Than 135 Deg W Or W/O Chamfer)
- Material [MATT]
- Iron Alloy 660 Locking Ringnickel Alloy R-405 Sleevesteel Comp 632 Stem
- Shank Style [AAZF]
- Self-Plugging Mechanically Locked Stem
Similar Supply Items to 5320-01-339-4081
Freight Information 5320-01-339-4081
5320-01-339-4081 has freight characteristics managed by Germany.. 5320-01-339-4081 has a variance between NMFC and UFC when transported by rail and the description should be consulted.
