5320-01-334-3676
Blind Rivet
5320013343676 013343676 CR3523P-4-3 NAS9307M-4-03 CR3523P-4-03
An item consisting of two or more of the following components: stem, rivet body, sleeve, expander, bolt, and collar. It is a headed fastening device with the shank designed to be expanded by means of a separate or integral stem or mandrel, or bolt and expander. It is designed to be installed or expanded from one side only. Excludes NUT, BLIND ASSEMBLY. View more Blind Rivet
Managed by United States
NSN Created on 21 Feb 1991
Data Last Changed
November 2023
November 2023
NATO Update Count
39
39
NATO Data Quality
Marketplace 5320-01-334-3676
Need Help?
Request a Quotation from participating marketplace vendors
Request a Quotation from participating marketplace vendors
Related Documents 5320-01-334-3676 5+ Documents (More...)
CR3523P-4-3 NAS9307M-4-03 CR3523P-4-03 An item consisting of two or more of the following components
Photo 1/3 NSN 5320-01-334-3676 (Identification) 2/3 NSN 5320-01-334-3676 (Identification) 3/3 -
RQST NE Updated Every Day 5320-01-334-3676 RQST Updated Every Day 5320-01-334-3676 RQST NE Related
Photo 1/3 NSN 5320-01-334-3676 (Identification) 2/3 NSN 5320-01-334-3676 (Identification) 3/3 -
RQST NE Updated Every Day 5320-01-334-3676 RQST Updated Every Day 5320-01-334-3676 RQST NE Related
Upgrade for $1 a day Upgrade your Account Upgrade 5320-01-619-1591Solid Rivet5320016191591 016191591 CR3523P-4-03
https//www.nsnlookup.com /fsg-53/fsc-5320/us 5320-01-619-1591 Solid Rivet 5320016191591016191591 CR3523P-4-03
vendors Request Updated Every Day 5320-01-619-1591 https//www.nsnlookup.com /fsg-53/fsc-5320/us 5320-01-334-3676
https//www.nsnlookup.com /fsg-53/fsc-5320/us 5320-01-619-1591 Solid Rivet 5320016191591016191591 CR3523P-4-03
vendors Request Updated Every Day 5320-01-619-1591 https//www.nsnlookup.com /fsg-53/fsc-5320/us 5320-01-334-3676
Upgrade for $1 a day Upgrade your Account Upgrade 5320-01-156-0253Blind Rivet5320011560253 011560253 CR3523P-4-3
https//www.nsnlookup.com /fsg-53/fsc-5320/us 5320-01-156-0253 Blind Rivet 5320011560253011560253 CR3523P-4-3
Blind Rivet 5320013343676 013343676, Blind Rivet 5320011560253011560253 Upgrade for $1 a day Upgrade
https//www.nsnlookup.com /fsg-53/fsc-5320/us 5320-01-156-0253 Blind Rivet 5320011560253011560253 CR3523P-4-3
Blind Rivet 5320013343676 013343676, Blind Rivet 5320011560253011560253 Upgrade for $1 a day Upgrade
a day Upgrade your Account Upgrade 5320-01-144 https//www.nsnlookup.com /fsg-53/fsc-5320/us 5320-01-334-3676
Blind Rivet 5320013343676 013343676, Documents 5320-01-334-3676 2+ Documents ( More... ) https/
AssyUOMTechnical DocumentQuantative ExpressionDefense Logistics Agency (DS)IZDiscontinued-Use 5320-01-334-3676
Blind Rivet 5320013343676 013343676, Documents 5320-01-334-3676 2+ Documents ( More... ) https/
AssyUOMTechnical DocumentQuantative ExpressionDefense Logistics Agency (DS)IZDiscontinued-Use 5320-01-334-3676
Upgrade 5320-01-350-1860Blind Rivet5320013501860 https//www.nsnlookup.com /fsg-53/fsc-5320/us 5320-01-334-3676
Blind Rivet 5320013343676 013343676, CR3523-4-03 RIVET,BLIND 99 EA NS Request Quotation Subscribe
Blind Rivet 5320013343676 013343676, CR3523-4-03 RIVET,BLIND 99 EA NS Request Quotation Subscribe
Restrictions 5320-01-334-3676
5320-01-334-3676 is a Blind Rivet that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
Import and Export 5320-01-334-3676
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5320-01-334-3676
- US Army (A919)
- Effective Date:
- 1 Dec 2009
- Supplementary Receivers:
- CT
- US Air Force (FXGI)
- Effective Date:
- 1 Apr 2006
- Former MOE Rule:
- FXKZ
- US Navy (N9BZ)
- Effective Date:
- 1 Apr 2009
- Supplementary Collaborators:
- GTKE
- Slovenia (WL01)
- Effective Date:
- 1 Sep 2012
- Poland (WP01)
- Effective Date:
- 1 Jul 2011
- Brazil (YA01)
- Effective Date:
- 1 May 2012
- Spain (YB01)
- Effective Date:
- 1 May 2008
- Australia (ZA01)
- Effective Date:
- 1 Aug 2012
- Belgium (ZB01)
- Effective Date:
- 1 Jul 2014
- South Africa (ZD01)
- Effective Date:
- 1 Oct 2013
- France (ZF01)
- Effective Date:
- 1 May 2008
- Germany (ZG01)
- Effective Date:
- 1 May 2008
- Republic of Korea (ZH01)
- Effective Date:
- 1 Oct 2006
- United Kingdom (ZK01)
- Effective Date:
- 1 Nov 2010
- Netherlands (ZN01)
- Effective Date:
- 1 May 2008
- Italy (ZR01)
- Effective Date:
- 1 Jul 2012
- Greece (ZU01)
- Effective Date:
- 1 May 2006
- Turkey (ZW01)
- Effective Date:
- 1 Apr 2009
Approved Sources 5320-01-334-3676
- Part Number
- Manufacturer
- Status
- NAS9307M-4-03
- Manufacturer
- 80205 - National Aerospace Standards (Active)
- Primary Buy
- Primary Buy
- CR3523P-4-03
- 11815 - Sps Technologies, Llc (Active)
- Primary Buy
- Primary Buy
- CR3523P-4-3
- R1120 - Satair A/S (Active)
- Secondary Buy
- Secondary Buy
- CR3523P-4-03
- F7652 - Klx Aerospace Solutions Ii Sas (Replaced)
- Canceled/Obsolete
- Canceled/Obsolete
- CR3523P-4-3
- F7652 - Klx Aerospace Solutions Ii Sas (Replaced)
- Canceled/Obsolete
- Canceled/Obsolete
- CR3523P-4-3
- FB009 - Boeing Distribution Services Inc (Active)
- Advisory Reference
- Advisory Reference
- CR3523P-4-3
- 11815 - Sps Technologies, Llc (Active)
- Advisory Reference
- Advisory Reference
- CR3523P-4-03
- FB009 - Boeing Distribution Services Inc (Active)
- Advisory Reference
- Advisory Reference
Datasheet 5320-01-334-3676
- Characteristic
- Specifications
- FIIG
- Specifications
- A040A0
- Expansion Device [ABAF]
- Plain Stem-Type T
- Fastener Length [AASB]
- 0.287 Inches Nominal
- Grip Length [ANEE]
- 0.126 Inches Minimum And 0.187 Inches Maximum
- Head Height [AASU]
- 0.054 Inches Minimum And 0.064 Inches Maximum
- Head Major Diameter [AAZG]
- 0.238 Inches Minimum And 0.262 Inches Maximum
- Head Style [AASK]
- Universal
- Material Document And Classification [MDCL]
- Qq-N-281 Fed Spec All Material Responses Sleeve
- Material [MATT]
- Nickel Alloy 400 Or Nickel Alloy R-405 Sleeve
- Material [MATT]
- Iron Alloy 660 Or Steel Comp 304 Locking Ring
- Material [MATT]
- Steel Comp 632 Stem
- Material Document And Classification [MDCL]
- Ams 5657 Assn Std Single Material Response Stem
- Material Document And Classification [MDCL]
- Ams 5731 Assn Std 1St Material Response Or Ams 5639 Assn Std 2Nd Material Response Locking Ring
- Shank Diameter [AAZE]
- 0.125 Inches Minimum And 0.129 Inches Maximum
- Shank Style [AAZF]
- Self-Plugging Mechanically Locked Stem
- Specification/Standard Data [ZZZK]
- 80205-Nas9307 Professional/Industrial Association Standard
- Surface Treatment Document And Classification [STDC]
- Qq-P-35 Fed Spec Single Treatment Response Locking Ring
- Surface Treatment [SFTT]
- Passivate Locking Ring
Weapon Systems (WSDC) 5320-01-334-3676
DLA Procurement Analysis 5320-01-334-3676
- Last Stock Position:
- 9766 In Stock
- DLA Administrative Lead Time:
- Subscribe
- DLA Production Lead Time:
- Subscribe
Management Data 5320-01-334-3676
Army
- Materiel Category and Inventory Manager:
- T
- Industrial Supplies (DLA/GSA Items)
- Appropriation and Budget Activity:
- 2
- Stock Fund Secondary Items
- Management Inventory Segment:
- 2
- Non-Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify items, which are not reparable.
- Weapons System / End Item / Homogeneous Group:
- 00
- DLA/GSA Material
DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item
- Accounting Requirements:
- X
- Expendable item.An item of Army property coded with an ARC of X in the AMDF. Expendable items require no formal accountability after issue from a stock record account.Commercial and fabricated items similar to items coded X in the AMDF are considered expendable items.
Air Force
- Fund:
- SF
- Stock fund applicable to items managed for the Air Force by the respective Inventory Control Point
- Budget:
- 9
- 57X4921.070 - General Support DIV - Air Force decentralized managed expense items (ERRC XB3, XF3) with a unit cost of less than $250,000 that are requisitioned/procured at base (retail) level from DLA, GSA, Army, Navy, Depot Maintenance Service, Air Force Industrial Fund (AFMC), local manufacture and commercial vendors
- Aggregation Code:
- SX
- SICA RESIDUAL MMAC-OC-ALC
- Price Validation Code:
- N
- The current standard price in Catalog Management Data (CMD) has not analyzed or coded for LP/LM.
The price has not been analyzed or reviewed for accuracy.
ZOP or Standard price challenges are permissible but must be supported with adequate justification. However, if coded for Local Purchase (LP) or Fabrication/Manufacture as indicated with an (LM) Acquisition Advice Code of “L” or “F”, then it must be evaluated locally where purchased or fabricated.
- Expendability
Recoverability
Repairability: - N
- Expendable. Condemn at User. Stock Fund (except Munitions).
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
Similar Supply Items to 5320-01-334-3676
Freight Information 5320-01-334-3676
5320-01-334-3676 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 106510. A Sub NMFC of X. It has a NMFC Description of RIVETS I/S PLAIN/GALVANIZED ETC. 5320-01-334-3676 is rated as class 50 when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 54760 which rates the freight between FCL and LCL. 5320-01-334-3676 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 713 for ocean manifesting and military sealift. 5320-01-334-3676 is not classified as a special type of cargo when transported by water. 5320-01-334-3676 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 5320-01-334-3676
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- Plated/Coated Item
- 2lb or less, one dimension 2" or less, other dimensions less than 24"
- Above 110G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- --
- --
- --
- --
- Physical Protection
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- --
- --
- --
- Bags made of material conforming to MIL-P-130, MIL-DTL-17667, MIL-PRF-121, or any material authorized by MIL-DTL-117. Closure may be by staples, tape, adhesive or heat seal
- No special marking
- --
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- PPP-B-566, PPP-B-676, or ASTM-D5118, Folding, Setup or Fiberboard Box
Procurement History 5320-01-334-3676 15 Records
- Contract
- Date
- CAGE
- Quantity
- Net Price
- Std Price
- CAGE
- SPE4A623F448G
- 17 Sep 2023
- Subscribe
- 3750
- Subscribe
- Subscribe
- Subscribe
- SPE4A623F448G
- 17 Sep 2023
- Subscribe
- 3750
- Subscribe
- Subscribe
- Subscribe
- SPE4A623F239Z
- 20 Jun 2023
- Subscribe
- 2401
- Subscribe
- Subscribe
- Subscribe
- SPE4A623F239Z
- 20 Jun 2023
- Subscribe
- 2401
- Subscribe
- Subscribe
- Subscribe
- SPE4A623F052Y
- 14 Apr 2023
- Subscribe
- 3087
- Subscribe
- Subscribe
- Subscribe
- SPE4A623F052Y
- 14 Apr 2023
- Subscribe
- 3087
- Subscribe
- Subscribe
- Subscribe
- SPE4A622F9907
- 20 Mar 2022
- Subscribe
- 5770
- Subscribe
- Subscribe
- Subscribe
- SPE4A622F9907
- 20 Mar 2022
- Subscribe
- 5770
- Subscribe
- Subscribe
- Subscribe
- SPE4A622F1405
- 15 Oct 2021
- Subscribe
- 3278
- Subscribe
- Subscribe
- Subscribe
- SPE4A622F1405
- 15 Oct 2021
- Subscribe
- 3278
- Subscribe
- Subscribe
- Subscribe
- SPE5EY19F2380
- 14 Nov 2018
- Subscribe
- 3482
- Subscribe
- Subscribe
- Subscribe
- SPE5EY18F380G
- 30 Aug 2018
- Subscribe
- 3668
- Subscribe
- Subscribe
- Subscribe
- SPE5E918V0298
- 19 Oct 2017
- Subscribe
- 8768
- Subscribe
- Subscribe
- Subscribe
- SPE5E916V3734
- 31 May 2016
- Subscribe
- 5532
- Subscribe
- Subscribe
- Subscribe
- SPE5E916V2071
- 17 Feb 2016
- Subscribe
- 4797
- Subscribe
- Subscribe
- Subscribe
Contracting Technical Data File (CTDF) 5320-01-334-3676 April 2020
Criticality and Quality
- Critical Item Code:
- X
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- F
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- N
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
