5320-01-151-1061

Blind Rivet

5320011511061 011511061 719816-2 CR 3213 - 4- 2 AF3213-4-02 MBBN3012L3202 CR3213 NAS9301BNS-4-02 HC3213-4-2 M7885/2-4-02 8000981-13 M7885/2-4-2 CR-213-4-2 AF3213-4-2 CR3213-4-2 M7885-2-4-02 MIL-R-7885/2 CR3213-4-02 10111865 10482718

An item consisting of two or more of the following components: stem, rivet body, sleeve, expander, bolt, and collar. It is a headed fastening device with the shank designed to be expanded by means of a separate or integral stem or mandrel, or bolt and expander. It is designed to be installed or expanded from one side only. Excludes NUT, BLIND ASSEMBLY. View more Blind Rivet

Managed by United States

NSN Created on 13 Apr 1983

Data Last Changed
November 2023

NATO Update Count
76

NATO Data Quality

5320-01-151-1061 RIVET,BLIND 5320011511061 011511061 1/3 — 5320-01-151-1061 Photo 1/3

AASK Style C28 for 5320-01-151-1061 2/3 — NSN 5320-01-151-1061 (Identification) 2/3

AAZF Style D32 for 5320-01-151-1061 3/3 — NSN 5320-01-151-1061 (Identification) 3/3

Marketplace 5320-01-151-1061

Need Help?
Request a Quotation from participating marketplace vendors

Subscribe to View Vendor Details...

M7885/2-4-02 RIVET,BLIND 399 EA NS

CR3213-4-02 RIVET,BLIND 32 EA NS

NAS9301BNS-4-02 RIVET,BLIND 7 EA NS

Subscribe to View Vendor Details...

CR3213-4-02 RIVET,BLIND 1800 EA NS

8000981-13 RIVET,BLIND 159 EA NS

Subscribe to View Vendor Details...

CR3213-4-2 RIVET,BLIND RQST NS

Subscribe to View Vendor Details...

CR3213-4-2 RIVET,BLIND RQST NS

Subscribe to View Vendor Details...

CR3213-4-02 RIVET,BLIND 15 EA NS

Subscribe to View Vendor Details...

CR3213-4-2 RIVET,BLIND 57 EA NS

Subscribe to View Vendor Details...

M7885/2-4-2 RIVET,BLIND 48 EA NS

CR3213-4-02 RIVET,BLIND 125 EA NS

M7885/2-4-02 RIVET,BLIND 94 EA NS

CR3213-4-2 RIVET,BLIND 66 EA NS

Updated Every Day

5320-01-151-1061 RQST NE

Updated Every Day

5320-01-151-1061 RQST

Updated Every Day

5320-01-151-1061 RQST NE

Restrictions 5320-01-151-1061

5320-01-151-1061 is a Blind Rivet that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.

Import and Export 5320-01-151-1061

Schedule B: Subscribe to View Schedule B
HTS Code: Subscribe to View HTS Code

End Users 5320-01-151-1061

US Army (A919)
Effective Date:: 1 Apr 2006
Former MOE Rule:: A187
Supplementary Receivers:: AJCTCLBFBDAZ; AMC 1 AMSC G IMC Z IMCACTY CT

MOE Rule:: BGX1
Effective Date:: 1 Apr 2006
Former MOE Rule:: BKZ1; AMC 1 AMSC G

US Coast Guard (C918)
Effective Date:: 1 Apr 2006
Former MOE Rule:: C004
Supplementary Receivers:: XH; AMC 1 AMSC G

US Air Force (FXGI)
Effective Date:: 1 Apr 2006
Former MOE Rule:: FXKZ; AMC 1 AMSC G IMC Z IMCACTY SX

NASA (G860)
Effective Date:: 1 Apr 1997; AMC 0 AMSC 0 AAC C

US Marine Corps (MC47)
Effective Date:: 1 Apr 2006
Former MOE Rule:: MC10; AMC 1 AMSC G IMC Z IMCACTY PA

US Navy (N9BZ)
Effective Date:: 1 Apr 2006
Former MOE Rule:: N9ZD
Supplementary Collaborators:: GTKEHD; AMC 1 AMSC G IMC Z IMCACTY KE

Austria (WB01)
Effective Date:: 1 Feb 2005

Finland (WF01)
Effective Date:: 1 Apr 2011

Slovenia (WL01)
Effective Date:: 1 Aug 2012

Poland (WP01)
Effective Date:: 1 Apr 2007

Bulgaria (WU01)
Effective Date:: 1 Nov 2002

Czech Republic (WZ01)
Effective Date:: 1 Feb 2008

Brazil (YA01)
Effective Date:: 1 Dec 1999

Spain (YB01)
Effective Date:: 1 Apr 1991

Columbia (YC01)
Effective Date:: 1 Jun 2015

Singapore (YJ01)
Effective Date:: 1 Apr 1991

Malaysia (YW01)
Effective Date:: 1 Aug 1997

Australia (ZA01)
Effective Date:: 1 Apr 1991

Belgium (ZB01)
Effective Date:: 1 Jun 1995

Canada (ZC01)
Effective Date:: 1 Apr 1991

New Zealand (ZE01)
Effective Date:: 1 Apr 1991

France (ZF01)
Effective Date:: 1 Apr 1991

Germany (ZG01)
Effective Date:: 1 Apr 1991

Republic of Korea (ZH01)
Effective Date:: 1 Apr 1991

United Kingdom (ZK01)
Effective Date:: 1 Apr 1991

Philippines (ZM01)
Effective Date:: 1 Feb 2015

Netherlands (ZN01)
Effective Date:: 1 Aug 1995

Portugal (ZP01)
Effective Date:: 1 Sep 1993

Italy (ZR01)
Effective Date:: 1 Jan 2001

Denmark (ZS01)
Effective Date:: 1 Apr 1991

Norway (ZT01)
Effective Date:: 1 Apr 1991

Greece (ZU01)
Effective Date:: 1 May 2006

Turkey (ZW01)
Effective Date:: 1 Oct 2003

NATO Maintenance and Supply Agency (ZX01)
Effective Date:: 1 Mar 2003

Approved Sources 5320-01-151-1061

Part Number
Manufacturer
Status
NAS9301BNS-4-02: 80205 - National Aerospace Standards (Active); Primary Buy; RNCC 3 RNVC 2 DAC A
CR 3213 - 4- 2: AC910 - Aertekno S.R.L. (Active); Secondary Buy; RNCC 5 RNVC 2 DAC 5
AF3213-4-02: 53551 - Allfast Fastening Systems, Llc (Active); Secondary Buy; RNCC 5 RNVC 2 DAC E
CR3213-4-2: FB011 - Aero Stock (Active); Secondary Buy; RNCC 5 RNVC 2 DAC 4
MBBN3012L3202: C0418 - Airbus Helicopters Deutschland Gmbh (Active); Secondary Buy; RNCC 5 RNVC 2 DAC 3
CR3213: C4293 - Fairchild Fasteners Europe - Vsd (Active); Secondary Buy; RNCC 5 RNVC 2 DAC 3
NAS9301BNS-4-02: 11815 - Sps Technologies, Llc (Active); Secondary Buy; RNCC 5 RNVC 2 DAC 6
NAS9301BNS-4-02: 53551 - Allfast Fastening Systems, Llc (Active); Secondary Buy; RNCC 5 RNVC 2 DAC 6
HC3213-4-2: 17446 - Huck International, Inc (Active); Secondary Buy; RNCC 5 RNVC 2 DAC 4
M7885/2-4-02: A0126 - Leonardo Spa Helicopters Division - (Active); Secondary Buy; RNCC 5 RNVC 2 DAC 5
CR3213-4-2: A0311 - Tecno Trade S.R.L. (Active); Secondary Buy; RNCC 5 RNVC 2 DAC 5
NAS9301BNS-4-02: K0668 - Leonardo Uk Ltd (Active); Secondary Buy; RNCC 5 RNVC 2 DAC 4
8000981-13: 07187 - Honeywell International Inc. (Active); Secondary Buy; RNCC 5 RNVC 2 DAC 1
NAS9301BNS-4-02: A0126 - Leonardo Spa Helicopters Division - (Active); Secondary Buy; RNCC 5 RNVC 2 DAC 5
CR3213-4-2: 11815 - Sps Technologies, Llc (Active); Secondary Buy; RNCC 5 RNVC 2 DAC 1
M7885/2-4-2: 81349 - Military Specifications (Active); Secondary Buy; RNCC 5 RNVC 2 DAC 3
CR-213-4-2: 11815 - Sps Technologies, Llc (Active); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 5
AF3213-4-2: 53551 - Allfast Fastening Systems, Llc (Active); Canceled/Obsolete; RNCC 5 RNVC 9 DAC E
CR3213-4-2: F7652 - Klx Aerospace Solutions Ii Sas (Replaced); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 4
CR3213: 92215 - Howmet Global Fastening Systems Inc (Active); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 5
M7885-2-4-02: 33823 - Adams Industries Inc A Sub Of Banner (Obsolete); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 4
MIL-R-7885/2: 81349 - Military Specifications (Active); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 4
M7885/2-4-02: 81349 - Military Specifications (Active); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 4
CR3213-4-02: 11815 - Sps Technologies, Llc (Active); Canceled/Obsolete; RNCC 5 RNVC 9 DAC A
10111865: A486G - Nimikkeistokeskus Ncb Finland (Active); NATO Reference; RNCC 6 RNVC 9 DAC 9
10482718: A486G - Nimikkeistokeskus Ncb Finland (Active); NATO Reference; RNCC 6 RNVC 9 DAC 9
719816-2: D9182 - Zf Industrieantriebe Witten Gmbh (Active); Advisory Reference; RNCC C RNVC 1 DAC 6
CR3213-4-2: FB009 - Boeing Distribution Services Inc (Active); Advisory Reference; RNCC C RNVC 1 DAC 4

Datasheet 5320-01-151-1061

Characteristic
Specifications
FIIG: A040A0
Expansion Device [ABAF]: Serrated Stem-Type W
Fastener Length [AASB]: 0.194 Inches Minimum And 0.224 Inches Maximum
Grip Length [ANEE]: 0.063 Inches Minimum And 0.125 Inches Maximum
Head Height [AASU]: 0.054 Inches Minimum And 0.064 Inches Maximum
Head Style [AASK]: Universal
Head Major Diameter [AAZG]: 0.240 Inches Minimum And 0.260 Inches Maximum
Material Document And Classification [MDCL]: Qq-A-430 Fed Spec Single Material Response Sleeve
Material [MATT]: Aluminum Alloy 5056 Sleeve
Material [MATT]: Steel Comp 8740 Stem
Material Document And Classification [MDCL]: Ams 6322 Assn Std Single Material Response Stem
Shank Diameter [AAZE]: 0.125 Inches Minimum And 0.129 Inches Maximum
Shank Style [AAZF]: Self-Plugging Mechanically Locked Stem
Special Features [FEAT]: Ns" Letters After The Material Code "B" Indicate No Preference To Lock Type (May Be Visible Or Internal). Rivets With No Letter Code (Indicating Visible Lock Type) And Rivets With The Letter "H" After The Material Code (Indicating Internal Lock Type) Are Both Acceptable For This Item Of Supply.
Surface Treatment Document And Classification [STDC]: Mil-C-5541 Mil Spec Single Treatment Response Sleeve
Surface Treatment Document And Classification [STDC]: Qq-P-416,Type 2,Class 2 Fed Spec Single Treatment Response Stem
Surface Treatment [SFTT]: Cadmium Stem And Chromate Stem
Surface Treatment [SFTT]: Chromate Sleeve

Weapon Systems (WSDC) 5320-01-151-1061

Subscribe
View WSDC

Subscribe to View Weapon System Codes...

Subscribe
View Data

DLA Procurement Analysis 5320-01-151-1061

Last Stock Position:: 66646 In Stock
DLA Administrative Lead Time:: Subscribe
DLA Production Lead Time:: Subscribe

Subscribe to View DLA Inventory and Forecast...

Management Data 5320-01-151-1061

Subscribe
View Prices

Effective Date: Organization; Unit of Issue; Unit Price; Qty Unit Pack
Oct 2022: Department of the Navy (DN); EA; Subscribe
Oct 2021: Department of the Air Force (DF); EA; Subscribe
Oct 2020: Department of the Air Force (DF); EA; Subscribe
Feb 2020: Department of the Army (DA); EA; Subscribe

MOE: USC; Code; Statement; Order of Use; Jump To Code; Qty Per Assy; UOM; Technical Document; Quantative Expression
US Marine Corps (DM): M; 4; Reversal Of Phrase Code A 5320-01-116-8122

Army

Materiel Category and Inventory Manager:

T: Industrial Supplies (DLA/GSA Items)

Appropriation and Budget Activity:

2: Stock Fund Secondary Items

Management Inventory Segment:

2: Non-Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify items, which are not reparable.

Weapons System / End Item / Homogeneous Group:

CC: Other Aircraft Categories
Multi-Application Aviation Spares

Accounting Requirements:

X: Expendable item.An item of Army property coded with an ARC of X in the AMDF. Expendable items require no formal accountability after issue from a stock record account.Commercial and fabricated items similar to items coded X in the AMDF are considered expendable items.

Navy

Cognizance:

9B: Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg

Marine Corps

Stores Account:

1: Stock Fund Account Item

Combat Essentiality:

6: Critical Repair Part to a Non-Combat Essential End Item

Echelon Management:

B2

Operational Test:

: No Special Procedures

Similar Supply Items to 5320-01-151-1061

Freight Information 5320-01-151-1061

5320-01-151-1061 has freight characteristics managed by the Southwestern Power Administration.It has a National Motor Freight Classification (NMFC) of 013630. A Sub NMFC of X. It has a NMFC Description of ALUM RIVETS. 5320-01-151-1061 is rated as class 70 when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 05720 which rates the freight between FCL and LCL. 5320-01-151-1061 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 713 for ocean manifesting and military sealift. 5320-01-151-1061 is not classified as a special type of cargo when transported by water. 5320-01-151-1061 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.

Packaging Data 5320-01-151-1061

Responsible Activity
Packaging Data Source: Primary Inventory Control Activity (PICA); --

Item Pack Level (Unpackaged)

Item Size
Item Weight
Characteristics
Weight/Dimensions Category
Fragility
Item Preservation: --; --; Plated/Coated Item; 2lb or less, one dimension 2" or less, other dimensions less than 24"; Above 110G; No Requirement

Unit Pack Level (Packaged)

Quantity per Pack
Unit Size
Unit Weight
Unit Cube
Preservation Method
Cleaning/Drying: --; --; --; --; Physical Protection; Any Suitable Process

Preservation Material
Wrapping Material
Cushioning/Dunnage
Cushioning Thickness
Container
Special Marking: No Requirement; --; --; --; Bags made of material conforming to MIL-P-130, MIL-DTL-17667, MIL-PRF-121, or any material authorized by MIL-DTL-117. Closure may be by staples, tape, adhesive or heat seal; No special marking

Intermediate Pack Level

Quantity of Unit Packs
Container: PPP-B-566, PPP-B-676, or ASTM-D5118, Folding, Setup or Fiberboard Box

Procurement History 5320-01-151-1061 Most Recent 83 Records

Subscribe
View Prices

Contract: Date; CAGE; Quantity; Net Price; Std Price
SPE4A624FA9TB: 27 Oct 2023; Subscribe; 50; Subscribe; Subscribe
SPE4A624FA0GE: 12 Oct 2023; Subscribe; 400; Subscribe; Subscribe
SPE4A624FA0GT: 12 Oct 2023; Subscribe; 500; Subscribe; Subscribe
SPE4A624FA0GE: 12 Oct 2023; Subscribe; 400; Subscribe; Subscribe
SPE4A624FA0GT: 12 Oct 2023; Subscribe; 500; Subscribe; Subscribe
SPE4A623FBUL2: 13 Aug 2023; Subscribe; 600; Subscribe; Subscribe
SPE4A623FBUL4: 13 Aug 2023; Subscribe; 43584; Subscribe; Subscribe
SPE4A623FBUL5: 13 Aug 2023; Subscribe; 56272; Subscribe; Subscribe
SPE4A623FBUL2: 13 Aug 2023; Subscribe; 600; Subscribe; Subscribe
SPE4A623FBUL3: 13 Aug 2023; Subscribe; 1644; Subscribe; Subscribe
SPE4A623FBUL4: 13 Aug 2023; Subscribe; 43584; Subscribe; Subscribe
SPE4A623FBUL5: 13 Aug 2023; Subscribe; 56272; Subscribe; Subscribe
SPE4A623FBUL3: 13 Aug 2023; Subscribe; 1644; Subscribe; Subscribe
SPE4A623FB7DL: 14 Jul 2023; Subscribe; 22752; Subscribe; Subscribe
SPE4A623FB7DM: 14 Jul 2023; Subscribe; 34548; Subscribe; Subscribe
SPE4A623FB7DL: 14 Jul 2023; Subscribe; 22752; Subscribe; Subscribe
SPE4A623FB7DM: 14 Jul 2023; Subscribe; 34548; Subscribe; Subscribe
SPE4A623F133M: 16 May 2023; Subscribe; 61053; Subscribe; Subscribe
SPE4A623F133M: 16 May 2023; Subscribe; 61053; Subscribe; Subscribe
SPE4A623F6752: 01 Feb 2023; Subscribe; 3337; Subscribe; Subscribe
SPE4A623F6753: 01 Feb 2023; Subscribe; 8101; Subscribe; Subscribe
SPE4A623F6754: 01 Feb 2023; Subscribe; 12037; Subscribe; Subscribe
SPE4A623F6755: 01 Feb 2023; Subscribe; 37578; Subscribe; Subscribe
SPE4A623F6752: 01 Feb 2023; Subscribe; 3337; Subscribe; Subscribe
SPE4A623F6753: 01 Feb 2023; Subscribe; 8101; Subscribe; Subscribe
SPE4A623F6754: 01 Feb 2023; Subscribe; 12037; Subscribe; Subscribe
SPE4A623F6755: 01 Feb 2023; Subscribe; 37578; Subscribe; Subscribe
SPE4A622F119H: 15 May 2022; Subscribe; 2738; Subscribe; Subscribe
SPE4A622F119K: 15 May 2022; Subscribe; 27861; Subscribe; Subscribe
SPE4A622F119L: 15 May 2022; Subscribe; 30454; Subscribe; Subscribe
SPE4A622F119H: 15 May 2022; Subscribe; 2738; Subscribe; Subscribe
SPE4A622F119K: 15 May 2022; Subscribe; 27861; Subscribe; Subscribe
SPE4A622F119L: 15 May 2022; Subscribe; 30454; Subscribe; Subscribe
SPE4A621F6923: 28 Jan 2021; Subscribe; 3340; Subscribe; Subscribe
SPE4A621F6924: 28 Jan 2021; Subscribe; 29860; Subscribe; Subscribe
SPE4A621F6923: 28 Jan 2021; Subscribe; 3340; Subscribe; Subscribe
SPE4A621F6924: 28 Jan 2021; Subscribe; 29860; Subscribe; Subscribe
SPE5E819V1617: 26 Nov 2018; Subscribe; 73190; Subscribe; Subscribe
SPE5E919V0548: 25 Oct 2018; Subscribe; 4098; Subscribe; Subscribe
SPE5E919V0409: 18 Oct 2018; Subscribe; 60020; Subscribe; Subscribe
SPE5EY18F081G: 24 May 2018; Subscribe; 64003; Subscribe; Subscribe
SPE5EY18F6386: 16 Feb 2018; Subscribe; 60251; Subscribe; Subscribe
SPE5EY18F0466: 12 Oct 2017; Subscribe; 382; Subscribe; Subscribe
SPE5EY18F0468: 12 Oct 2017; Subscribe; 9523; Subscribe; Subscribe
SPE5EY18F0467: 12 Oct 2017; Subscribe; 674; Subscribe; Subscribe
SPM5EY13D05421122: 05 Sep 2017; Subscribe; 3357; Subscribe; Subscribe
SPM5EY13D05421123: 05 Sep 2017; Subscribe; 8994; Subscribe; Subscribe
SPM5EY13D05421121: 05 Sep 2017; Subscribe; 147; Subscribe; Subscribe
SPM5EY13D05421000: 21 May 2017; Subscribe; 1815; Subscribe; Subscribe
SPM5EY13D05421002: 21 May 2017; Subscribe; 74379; Subscribe; Subscribe
SPM5EY13D05421001: 21 May 2017; Subscribe; 6719; Subscribe; Subscribe
SPM5EY13D05420929: 21 Feb 2017; Subscribe; 39379; Subscribe; Subscribe
SPM5EY13D05420928: 20 Feb 2017; Subscribe; 1353; Subscribe; Subscribe
SPM5EY13D05420927: 20 Feb 2017; Subscribe; 948; Subscribe; Subscribe
SPM5EY13D05420883: 28 Dec 2016; Subscribe; 93085; Subscribe; Subscribe
SPM5EY13D05420882: 28 Dec 2016; Subscribe; 7024; Subscribe; Subscribe
SPM5EY13D05420881: 28 Dec 2016; Subscribe; 5413; Subscribe; Subscribe
SPM5EY13D05420829: 23 Nov 2016; Subscribe; 46441; Subscribe; Subscribe
SPM5EY13D05420828: 23 Nov 2016; Subscribe; 1119; Subscribe; Subscribe
SPM5EY13D05420827: 23 Nov 2016; Subscribe; 449; Subscribe; Subscribe
SPM5EY13D05420688: 06 Jun 2016; Subscribe; 1203; Subscribe; Subscribe
SPM5EY13D05420689: 06 Jun 2016; Subscribe; 6908; Subscribe; Subscribe
SPM5EY13D05420690: 06 Jun 2016; Subscribe; 122036; Subscribe; Subscribe
SPM5EY13D05420379: 01 Jun 2015; Subscribe; 35077; Subscribe; Subscribe
SPM5EY13D05420380: 01 Jun 2015; Subscribe; 88605; Subscribe; Subscribe
SPM5EY13D05420377: 27 May 2015; Subscribe; 9626; Subscribe; Subscribe
SPM5EY13D05420378: 27 May 2015; Subscribe; 29404; Subscribe; Subscribe
SPM5EY13D05420278: 29 Mar 2015; Subscribe; 12872; Subscribe; Subscribe
SPM5EY13D05420272: 23 Mar 2015; Subscribe; 20940; Subscribe; Subscribe
SPM5EY13D05420270: 23 Mar 2015; Subscribe; 3484; Subscribe; Subscribe
SPM5EY13D05420271: 23 Mar 2015; Subscribe; 14109; Subscribe; Subscribe
SPM5EY13D05420242: 01 Mar 2015; Subscribe; 9651; Subscribe; Subscribe
SPM5EY13D05420217: 09 Feb 2015; Subscribe; 153582; Subscribe; Subscribe
SPM5EY13D05420215: 06 Feb 2015; Subscribe; 3592; Subscribe; Subscribe
SPM5EY13D05420216: 06 Feb 2015; Subscribe; 11819; Subscribe; Subscribe
SPM5EY13D05420185: 12 Dec 2014; Subscribe; 42842; Subscribe; Subscribe
SPM5EY13D05420184: 11 Dec 2014; Subscribe; 312; Subscribe; Subscribe
SPM5EY13D05420183: 11 Dec 2014; Subscribe; 214; Subscribe; Subscribe
SPM5EY13D05420035: 31 Jan 2014; Subscribe; 236821; Subscribe; Subscribe
SPM5EY13D05420024: 20 Nov 2013; Subscribe; 89350; Subscribe; Subscribe
SPM5EY13D05420023: 13 Nov 2013; Subscribe; 710; Subscribe; Subscribe
SPM5E913V1686: 06 May 2013; Subscribe; 111122; Subscribe; Subscribe
SPM5E913V0622: 11 Jan 2013; Subscribe; 212474; Subscribe; Subscribe

Contracting Technical Data File (CTDF) 5320-01-151-1061 April 2020

Criticality and Quality

Critical Item Code:: X
Flight Safety:
Life Support:
Certified Samples:
Serialization:
First Article Test (FAT):
Certificate of Quality Compliance:
Production Lot Testing:
Special Testing:
Qualified Products List (QPL):

Commercial Properties

Government Furnished Material:
Government Furnished Tooling:
Government Furnished Property:
Price Evaluation Code:
Diminshing Manufacturing Sources:
Warranty:
Commerical Off The Shelf (COTS):
End Item Application:
Auctioning Candidate:
Source of Procurement:
Contract Option:

Restrictions

Boeing Rights Guard:
Export Controlled:
Controlled Technical Data Package (TDP):
Restricted Technical Data Package (TDP):
Contains Classified Material
Weapons System Indicator Code (WSIC):: F

Packaging Requirements

Packaging Determination Table:
Packaging Review Code:: N
Special Packaging Instruction Number (SPIN):
Special Packaging Instruction Number Revision:
Special Packaging Instruction Number Date:
Pallet Reference Number Required:

Subscribe
View CTDF

Subscribe to View CTDF Details...

Marketplace 5320-01-151-1061

Related Documents 5320-01-151-1061 5+ Documents (More...)

Restrictions 5320-01-151-1061

Import and Export 5320-01-151-1061

End Users 5320-01-151-1061

Approved Sources 5320-01-151-1061

Datasheet 5320-01-151-1061

Weapon Systems (WSDC) 5320-01-151-1061

DLA Procurement Analysis 5320-01-151-1061

Management Data 5320-01-151-1061

Army

Navy

Marine Corps

Similar Supply Items to 5320-01-151-1061

Freight Information 5320-01-151-1061

Packaging Data 5320-01-151-1061

Item Pack Level (Unpackaged)

Unit Pack Level (Packaged)

Intermediate Pack Level

Procurement History 5320-01-151-1061 Most Recent 83 Records

Contracting Technical Data File (CTDF) 5320-01-151-1061 April 2020

Criticality and Quality

Commercial Properties

Restrictions

Packaging Requirements
