5320-01-042-2897
Blind Rivet
5320010422897 010422897 NAS9310M-4-01 CR3553-4-1 HR3553-4-01 AF3553-4-01 M7885/8-4-01 MIL-R-7885/8 AF3553-4-1
An item consisting of two or more of the following components: stem, rivet body, sleeve, expander, bolt, and collar. It is a headed fastening device with the shank designed to be expanded by means of a separate or integral stem or mandrel, or bolt and expander. It is designed to be installed or expanded from one side only. Excludes NUT, BLIND ASSEMBLY. View more Blind Rivet
Managed by United States
NSN Created on 8 Jun 1977
Data Last Changed
November 2023
November 2023
NATO Update Count
50
50
NATO Data Quality
Marketplace 5320-01-042-2897
Need Help?
Request a Quotation from participating marketplace vendors
Request a Quotation from participating marketplace vendors
Related Documents 5320-01-042-2897 5+ Documents (More...)
NAS9310M-4-01 CR3553-4-1 HR3553-4-01 AF3553-4-01 M7885/8-4-01 MIL-R-7885/8 AF3553-4-1 An item consisting
Photo 1/3 NSN 5320-01-042-2897 (Identification) 2/3 NSN 5320-01-042-2897 (Identification) 3/3 -
RQST NE Updated Every Day 5320-01-042-2897 RQST Updated Every Day 5320-01-042-2897 RQST NE Related
Photo 1/3 NSN 5320-01-042-2897 (Identification) 2/3 NSN 5320-01-042-2897 (Identification) 3/3 -
RQST NE Updated Every Day 5320-01-042-2897 RQST Updated Every Day 5320-01-042-2897 RQST NE Related
-306-1541Blind Rivet5320013061541 013061541 AF3553-5-09 HR3553-5-09 NAS9310M-5-09 M7885/8-5-09 MIL-R-7885/8
Upgrade 5320-01-042-2893Blind Rivet5320010422893 010422893 NAS9310M-4-07 CR3553-4-7 AF3553-4-07 MIL-R-7885/8
Rivet 5320010428250 010428250, -4 HR3553-6-04 AF3553-6-04 ASNA0078E604K M7885/8-6-04 AF3553-6-4 MIL-R-7885/8
Upgrade 5320-01-042-2893Blind Rivet5320010422893 010422893 NAS9310M-4-07 CR3553-4-7 AF3553-4-07 MIL-R-7885/8
Rivet 5320010428250 010428250, -4 HR3553-6-04 AF3553-6-04 ASNA0078E604K M7885/8-6-04 AF3553-6-4 MIL-R-7885/8
https//www.nsnlookup.com /fsg-53/fsc-5320/us 5320-01-042-2897 Blind Rivet 5320010422897 010422897
2897Blind Rivet5320010422897 010422897 NAS9310M-4-01 CR3553-4-1 HR3553-4-01 AF3553-4-01 M7885/8-4-01
MIL-R-7885/8 Rivet 5320010428250 010428250, -4 HR3553-6-04 AF3553-6-04 ASNA0078E604K M7885/8-6-04 AF3553
2897Blind Rivet5320010422897 010422897 NAS9310M-4-01 CR3553-4-1 HR3553-4-01 AF3553-4-01 M7885/8-4-01
MIL-R-7885/8 Rivet 5320010428250 010428250, -4 HR3553-6-04 AF3553-6-04 ASNA0078E604K M7885/8-6-04 AF3553
https//www.nsnlookup.com /fsg-53/fsc-5320/us 5320-01-042-2897 Blind Rivet 5320010422897 010422897
2897Blind Rivet5320010422897 010422897 NAS9310M-4-01 CR3553-4-1 HR3553-4-01 AF3553-4-01 M7885/8-4-01
MIL-R-7885/8 Rivet 5320010428250 010428250, -4 HR3553-6-04 AF3553-6-04 ASNA0078E604K M7885/8-6-04 AF3553
2897Blind Rivet5320010422897 010422897 NAS9310M-4-01 CR3553-4-1 HR3553-4-01 AF3553-4-01 M7885/8-4-01
MIL-R-7885/8 Rivet 5320010428250 010428250, -4 HR3553-6-04 AF3553-6-04 ASNA0078E604K M7885/8-6-04 AF3553
5320-01-042-5148 Blind Rivet 5320010425148 010425148 -12 AF3553-6-12 HR3553-6-12 M7885/8-6-12 MIL-R-7885/8
Rivet5320012966387 012966387CR3553-6-2NAS9310M -11 HR3553-6-11 AF3553-6-11 M7885/8-6-11 MIL-R-7885/8
Rivet5320012966387 012966387CR3553-6-2NAS9310M -11 HR3553-6-11 AF3553-6-11 M7885/8-6-11 MIL-R-7885/8
Rivet5320012966387 012966387CR3553-6-2NAS9310M -11 HR3553-6-11 AF3553-6-11 M7885/8-6-11 MIL-R-7885/8
Rivet5320012966387 012966387CR3553-6-2NAS9310M -11 HR3553-6-11 AF3553-6-11 M7885/8-6-11 MIL-R-7885/8
Restrictions 5320-01-042-2897
5320-01-042-2897 is a Blind Rivet that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. The precious metals content of this item is unknown.
Import and Export 5320-01-042-2897
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5320-01-042-2897
- US Army (A919)
- Effective Date:
- 1 Apr 2006
- Former MOE Rule:
- A187
- Supplementary Receivers:
- BDCT
- US Coast Guard (C918)
- Effective Date:
- 1 Apr 2006
- Former MOE Rule:
- C004
- Supplementary Receivers:
- XH
- US Air Force (FXGI)
- Effective Date:
- 1 Apr 2006
- Former MOE Rule:
- FXKZ
- US Navy (N9BZ)
- Effective Date:
- 1 Dec 2013
- Supplementary Collaborators:
- GGGT
- Poland (WP01)
- Effective Date:
- 1 Jul 2011
- Bulgaria (WU01)
- Effective Date:
- 1 Nov 2002
- Spain (YB01)
- Effective Date:
- 1 Feb 1994
- Columbia (YC01)
- Effective Date:
- 1 Jun 2015
- Singapore (YJ01)
- Effective Date:
- 1 Apr 1991
- Australia (ZA01)
- Effective Date:
- 1 Apr 1991
- Belgium (ZB01)
- Effective Date:
- 1 Jun 2012
- Canada (ZC01)
- Effective Date:
- 1 Aug 2010
- New Zealand (ZE01)
- Effective Date:
- 1 Nov 2004
- France (ZF01)
- Effective Date:
- 1 May 2011
- Germany (ZG01)
- Effective Date:
- 1 Apr 1991
- Republic of Korea (ZH01)
- Effective Date:
- 1 Apr 1991
- Italy (ZR01)
- Effective Date:
- 1 May 2014
- Denmark (ZS01)
- Effective Date:
- 1 Apr 2012
- Norway (ZT01)
- Effective Date:
- 1 Apr 1991
- Greece (ZU01)
- Effective Date:
- 1 Aug 1995
- Turkey (ZW01)
- Effective Date:
- 1 Dec 1995
- NATO Maintenance and Supply Agency (ZX01)
- Effective Date:
- 1 Jun 2013
Approved Sources 5320-01-042-2897
- Part Number
- Manufacturer
- Status
- CR3553-4-1
- Manufacturer
- 11815 - Sps Technologies, Llc (Active)
- Primary Buy
- Primary Buy
- NAS9310M-4-01
- 80205 - National Aerospace Standards (Active)
- Primary Buy
- Primary Buy
- CR3553-4-1
- C4293 - Fairchild Fasteners Europe - Vsd (Active)
- Secondary Buy
- Secondary Buy
- CR3553-4-1
- 06950 - Howmet Global Fastening Systems Inc (Active)
- Secondary Buy
- Secondary Buy
- HR3553-4-01
- 0HDW7 - Huck International, Inc. (Active)
- Secondary Buy
- Secondary Buy
- AF3553-4-01
- 53551 - Allfast Fastening Systems, Llc (Active)
- Secondary Buy
- Secondary Buy
- M7885/8-4-01
- 81349 - Military Specifications (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- MIL-R-7885/8
- 81349 - Military Specifications (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- CR3553-4-1
- 92215 - Howmet Global Fastening Systems Inc (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- AF3553-4-1
- 53551 - Allfast Fastening Systems, Llc (Active)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 5320-01-042-2897
- Characteristic
- Specifications
- FIIG
- Specifications
- A040A0
- Expansion Device [ABAF]
- Serrated Stem-Type W
- Fastener Length [AASB]
- 0.160 Inches Minimum And 0.180 Inches Maximum
- Grip Length [ANEE]
- 0.020 Inches Minimum And 0.062 Inches Maximum
- Head Height [AASU]
- 0.054 Inches Minimum And 0.064 Inches Maximum
- Head Major Diameter [AAZG]
- 0.240 Inches Minimum And 0.260 Inches Maximum
- Head Style [AASK]
- Universal
- Material Document And Classification [MDCL]
- Qq-N-281 Fed Spec All Material Responses Body
- Material [MATT]
- Nickel Alloy 400 Body Or Nickel Alloy R-405 Body
- Material [MATT]
- Steel Comp 632 Stem
- Lubrication [ABAJ]
- Dry Film
- Material Document And Classification [MDCL]
- Ams 5657 Assn Std Single Material Response Stem
- Shank Diameter [AAZE]
- 0.139 Inches Minimum And 0.143 Inches Maximum
- Shank Style [AAZF]
- Self-Plugging Mechanically Locked Stem
- Special Features [FEAT]
- Lubrication On Stem Only
Weapon Systems (WSDC) 5320-01-042-2897
DLA Procurement Analysis 5320-01-042-2897
- Last Stock Position:
- 1700 In Stock
- DLA Administrative Lead Time:
- Subscribe
- DLA Production Lead Time:
- Subscribe
Management Data 5320-01-042-2897
Army
- Materiel Category and Inventory Manager:
- T
- Industrial Supplies (DLA/GSA Items)
- Appropriation and Budget Activity:
- 2
- Stock Fund Secondary Items
- Management Inventory Segment:
- 2
- Non-Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify items, which are not reparable.
- Weapons System / End Item / Homogeneous Group:
- 00
- DLA/GSA Material
DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item
- Accounting Requirements:
- X
- Expendable item.An item of Army property coded with an ARC of X in the AMDF. Expendable items require no formal accountability after issue from a stock record account.Commercial and fabricated items similar to items coded X in the AMDF are considered expendable items.
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
Similar Supply Items to 5320-01-042-2897
Freight Information 5320-01-042-2897
5320-01-042-2897 has freight characteristics managed by the Southwestern Power Administration.It has a National Motor Freight Classification (NMFC) of 139820. A Sub NMFC of X. It has a NMFC Description of NICKEL BOLTS/NAILS/NUTS/RIVETS ETC. 5320-01-042-2897 is rated as class 85 when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 70220 which rates the freight between FCL and LCL. 5320-01-042-2897 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 713 for ocean manifesting and military sealift. 5320-01-042-2897 is not classified as a special type of cargo when transported by water. 5320-01-042-2897 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 5320-01-042-2897
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- Plated/Coated Item
- 2lb or less, one dimension 2" or less, other dimensions less than 24"
- Above 110G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- --
- --
- --
- Physical Protection
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- No Requirement
- No Requirement
- Not Applicable
- Bags made of material conforming to MIL-P-130, MIL-DTL-17667, MIL-PRF-121, or any material authorized by MIL-DTL-117. Closure may be by staples, tape, adhesive or heat seal
- No special marking
- No Requirement
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- PPP-B-566, PPP-B-676, or ASTM-D5118, Folding, Setup or Fiberboard Box
Procurement History 5320-01-042-2897 30 Records
