5320-00-264-4427
Solid Rivet
5320002644427 002644427 MS20426A2-2 AN426A2-2 10123569
A headed fastening device having a smooth solid shank designed to have the shank end upset after insertion. View more Solid Rivet
Managed by United States
NSN Created on 1 Jan 1963
Data Last Changed
November 2023
November 2023
NATO Update Count
38
38
NATO Data Quality
Marketplace 5320-00-264-4427
Need Help?
Request a Quotation from participating marketplace vendors
Request a Quotation from participating marketplace vendors
Related Documents 5320-00-264-4427 5+ Documents (More...)
MS20426A2-2 AN426A2-2 10123569 A headed fastening device having a smooth solid shank designed to have
Photo 1/3 NSN 5320-00-264-4427 (Identification) 2/3 NSN 5320-00-264-4427 (Identification) 3/3 -
MS20426A2-2 RIVET,SOLID 9385 LB NS Request Quotation Updated Every Day 5320-00-264-4427 RQST NE Updated
Photo 1/3 NSN 5320-00-264-4427 (Identification) 2/3 NSN 5320-00-264-4427 (Identification) 3/3 -
MS20426A2-2 RIVET,SOLID 9385 LB NS Request Quotation Updated Every Day 5320-00-264-4427 RQST NE Updated
MS20426A2-2 RIVET,SOLID 6 EA NS Request Quotation Subscribe to View Vendor Details...
MS20426A2-2 RIVET,SOLID 164 EA NS Request Quotation Subscribe to View Vendor Details...
MS20426A2-2 RIVET,SOLID 4236 EA NS Request Quotation MS20426A2-2 RIVET,SOLID 4236 EA NS Request Quotation
MS20426A2-2 RIVET,SOLID 164 EA NS Request Quotation Subscribe to View Vendor Details...
MS20426A2-2 RIVET,SOLID 4236 EA NS Request Quotation MS20426A2-2 RIVET,SOLID 4236 EA NS Request Quotation
MS20426A2-2 RIVET,SOLID 6 EA NS Request Quotation Subscribe to View Vendor Details...
MS20426A2-2 RIVET,SOLID 164 EA NS Request Quotation Subscribe to View Vendor Details...
MS20426A2-2 RIVET,SOLID 4236 EA NS Request Quotation MS20426A2-2 RIVET,SOLID 4236 EA NS Request Quotation
MS20426A2-2 RIVET,SOLID 164 EA NS Request Quotation Subscribe to View Vendor Details...
MS20426A2-2 RIVET,SOLID 4236 EA NS Request Quotation MS20426A2-2 RIVET,SOLID 4236 EA NS Request Quotation
MS20426A2-2 RIVET,SOLID 6 EA NS Request Quotation Subscribe to View Vendor Details...
MS20426A2-2 RIVET,SOLID 164 EA NS Request Quotation Subscribe to View Vendor Details...
MS20426A2-2 RIVET,SOLID 4236 EA NS Request Quotation MS20426A2-2 RIVET,SOLID 4236 EA NS Request Quotation
MS20426A2-2 RIVET,SOLID 164 EA NS Request Quotation Subscribe to View Vendor Details...
MS20426A2-2 RIVET,SOLID 4236 EA NS Request Quotation MS20426A2-2 RIVET,SOLID 4236 EA NS Request Quotation
808-8511 5320-00-117-6950 5320-00-117-7575 5320-00-117-6963 5320-00-286-4209 5320-01-108-7635 5320-00-264-4427
Restrictions 5320-00-264-4427
5320-00-264-4427 is a Solid Rivet that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. The precious metals content of this item is unknown.
Import and Export 5320-00-264-4427
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5320-00-264-4427
- US Army (A919)
- Effective Date:
- 1 Jun 2005
- Former MOE Rule:
- A187
- Supplementary Receivers:
- BDCTCL
- US Air Force (FXGI)
- Effective Date:
- 1 Jun 2005
- Former MOE Rule:
- FXKZ
- US Navy (N9BZ)
- Effective Date:
- 1 Jun 2005
- Former MOE Rule:
- N9ZD
- Supplementary Collaborators:
- GTKEHD
- Finland (WF01)
- Effective Date:
- 1 Aug 2009
- Poland (WP01)
- Effective Date:
- 1 Jul 2006
- Brazil (YA01)
- Effective Date:
- 1 Jan 2011
- Spain (YB01)
- Effective Date:
- 1 Apr 1991
- Israel (YD01)
- Effective Date:
- 1 Aug 2016
- Singapore (YJ01)
- Effective Date:
- 1 Apr 1991
- Saudi Arabia (YS01)
- Effective Date:
- 1 Feb 2015
- Malaysia (YW01)
- Effective Date:
- 1 Apr 2007
- Australia (ZA01)
- Effective Date:
- 1 Feb 2017
- Canada (ZC01)
- Effective Date:
- 1 Apr 1991
- New Zealand (ZE01)
- Effective Date:
- 1 Apr 1991
- Germany (ZG01)
- Effective Date:
- 1 Apr 1991
- Republic of Korea (ZH01)
- Effective Date:
- 1 Apr 1991
- United Kingdom (ZK01)
- Effective Date:
- 1 Dec 1994
- Italy (ZR01)
- Effective Date:
- 1 Apr 1991
- Norway (ZT01)
- Effective Date:
- 1 Apr 1991
Approved Sources 5320-00-264-4427
- Part Number
- Manufacturer
- Status
- MS20426A2-2
- Manufacturer
- 80205 - National Aerospace Standards (Active)
- Primary Buy
- Primary Buy
- MS20426A2-2
- 81349 - Military Specifications (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- AN426A2-2
- 81352 - Air Force-Navy Aeronautical (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- AN426A2-2
- 88044 - Aeronautical Standards Group (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- MS20426A2-2
- 96906 - Military Standards (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- 10123569
- A486G - Nimikkeistokeskus Ncb Finland (Active)
- NATO Reference
- NATO Reference
Datasheet 5320-00-264-4427
- Characteristic
- Specifications
- FIIG
- Specifications
- A040A0
- Countersink Angle [CRSQ]
- 99.5 Degrees Minimum And 100.5 Degrees Maximum
- Fastener Length [AASB]
- 0.115 Inches Minimum And 0.135 Inches Maximum
- Grip Length [ANEE]
- 0.021 Nominal Mils And 0.041 Nominal Centimeters
- Head Style [AASK]
- Flush (Flat) Countersunk (Included Angle - Less Than 135 Deg W Or W/O Chamfer)
- Head Major Diameter [AAZG]
- 0.110 Inches Minimum And 0.118 Inches Maximum
- Material Document And Classification [MDCL]
- Qq-A-430 Fed Spec Single Material Response Overall
- Material [MATT]
- Aluminum Alloy 1100 Overall
- Shank Diameter [AAZE]
- 0.061 Inches Minimum And 0.065 Inches Maximum
- Shank Style [AAZF]
- Straight W/Radius Chamfered Tip
Weapon Systems (WSDC) 5320-00-264-4427
DLA Procurement Analysis 5320-00-264-4427
- Last Stock Position:
- 240 In Stock
- DLA Administrative Lead Time:
- Subscribe
- DLA Production Lead Time:
- Subscribe
Management Data 5320-00-264-4427
Army
- Materiel Category and Inventory Manager:
- T
- Industrial Supplies (DLA/GSA Items)
- Appropriation and Budget Activity:
- 2
- Stock Fund Secondary Items
- Management Inventory Segment:
- 2
- Non-Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify items, which are not reparable.
- Weapons System / End Item / Homogeneous Group:
- 00
- DLA/GSA Material
DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item
- Accounting Requirements:
- X
- Expendable item.An item of Army property coded with an ARC of X in the AMDF. Expendable items require no formal accountability after issue from a stock record account.Commercial and fabricated items similar to items coded X in the AMDF are considered expendable items.
Air Force
- Fund:
- SF
- Stock fund applicable to items managed for the Air Force by the respective Inventory Control Point
- Budget:
- 9
- 57X4921.070 - General Support DIV - Air Force decentralized managed expense items (ERRC XB3, XF3) with a unit cost of less than $250,000 that are requisitioned/procured at base (retail) level from DLA, GSA, Army, Navy, Depot Maintenance Service, Air Force Industrial Fund (AFMC), local manufacture and commercial vendors
- Aggregation Code:
- SX
- SICA RESIDUAL MMAC-OC-ALC
- Price Validation Code:
- V
- The current standard price has been validated.
The item has been analyzed in conjunction with the Zero Overpricing Program and is in the accepted price range.
The item was procured under open competition and under the competitive arena the price is considered fair and reasonable.
ZOP or Standard price challenges are permissible but must be supported by adequate justification.
- Expendability
Recoverability
Repairability: - N
- Expendable. Condemn at User. Stock Fund (except Munitions).
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
Similar Supply Items to 5320-00-264-4427
Freight Information 5320-00-264-4427
5320-00-264-4427 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 106510. A Sub NMFC of X. It has a NMFC Description of RIVETS I/S PLAIN/GALVANIZED ETC. 5320-00-264-4427 is rated as class 50 when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 54760 which rates the freight between FCL and LCL. 5320-00-264-4427 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 576 for ocean manifesting and military sealift. 5320-00-264-4427 is not classified as a special type of cargo when transported by water. 5320-00-264-4427 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 5320-00-264-4427
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- Plated/Coated Item
- 2lb or less, one dimension 2" or less, other dimensions less than 24"
- Above 110G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- --
- --
- --
- Physical Protection
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- No Requirement
- No Requirement
- Not Applicable
- PPP-B-566, PPP-B-676, or ASTM-D5118, Folding, Setup or Fiberboard Box
- No special marking
- No Requirement
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- --
- No Requirement
Contracting Technical Data File (CTDF) 5320-00-264-4427 August 2020
Criticality and Quality
- Critical Item Code:
- X
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- F
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- N
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
