5320-00-256-6404
Solid Rivet
5320002566404 002566404 FF-R-556 B18G1929TABLE1T1NNERSRIVETS
A headed fastening device having a smooth solid shank designed to have the shank end upset after insertion. View more Solid Rivet
Managed by United States
NSN Created on 1 Jan 1960
Data Last Changed
November 2023
November 2023
NATO Update Count
3
3
NATO Data Quality
Marketplace 5320-00-256-6404
Need Help?
Request a Quotation from participating marketplace vendors
Request a Quotation from participating marketplace vendors
Related Documents 5320-00-256-6404 5+ Documents (More...)
FF-R-556 B18G1929TABLE1T1NNERSRIVETS A headed fastening device having a smooth solid shank designed
Photo 1/3 NSN 5320-00-256-6404 (Identification) 2/3 NSN 5320-00-256-6404 (Identification) 3/3 -
Day 5320-00-256-6404 RQST Updated Every Day 5320-00-256-6404 RQST NE Related Documents 5320-00-256-6404
Photo 1/3 NSN 5320-00-256-6404 (Identification) 2/3 NSN 5320-00-256-6404 (Identification) 3/3 -
Day 5320-00-256-6404 RQST Updated Every Day 5320-00-256-6404 RQST NE Related Documents 5320-00-256-6404
FF-R-556 RIVET,SOLID RQST NS Request Quotation Subscribe to View Vendor Details...
FF-R-556 RIVET,SOLID RQST NS Request Quotation Subscribe to View Vendor Details...
FF-R-556 RIVET,SOLID RQST NS Request Quotation Subscribe to View Vendor Details...
FF-R-556 RIVET,SOLID RQST NS Request Quotation Subscribe to View Vendor Details...
FF-R-556 RIVET,SOLID RQST NS Request Quotation Subscribe to View Vendor Details...
579-9431 5320-01-495-2875 5320-00-584-0672 5320-01-463-6407 5320-01-019-2637 5320-01-450-4075 5320-00-256-6404
579-9431 5320-01-495-2875 5320-00-584-0672 5320-01-463-6407 5320-01-019-2637 5320-01-450-4075 5320-00-256-6404
579-9431 5320-01-495-2875 5320-00-584-0672 5320-01-463-6407 5320-01-019-2637 5320-01-450-4075 5320-00-256-6404
Restrictions 5320-00-256-6404
5320-00-256-6404 is a Solid Rivet that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. The precious metals content of this item is unknown.
Import and Export 5320-00-256-6404
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5320-00-256-6404
- US Army (A919)
- Effective Date:
- 1 Mar 2006
- Former MOE Rule:
- A187
- US Air Force (FXGI)
- Effective Date:
- 1 Mar 2006
- Former MOE Rule:
- FXKZ
- Greece (ZU01)
- Effective Date:
- 1 Apr 1991
- Turkey (ZW01)
- Effective Date:
- 1 Nov 2005
Approved Sources 5320-00-256-6404
- Part Number
- Manufacturer
- Status
- B18G1929TABLE1T1NNERSRIVETS
- Manufacturer
- 80204 - American National Standards (Active)
- Primary Buy
- Primary Buy
- FF-R-556
- 81348 - Federal Specifications Promulgated (Active)
- Incomplete Standard
- Incomplete Standard
Datasheet 5320-00-256-6404
- Characteristic
- Specifications
- FIIG
- Specifications
- A040A0
- Fastener Length [AASB]
- 0.234 Inches Nominal
- Hardness Rating [CQFM]
- 60.0 Rockwell B Maximum Overall
- Head Height [AASU]
- 0.034 Inches Minimum And 0.046 Inches Maximum
- Head Style [AASK]
- Flat/Tinner's
- Head Major Diameter [AAZG]
- 0.294 Inches Minimum And 0.316 Inches Maximum
- Material [MATT]
- Steel Comp 1005 Overall Or Steel Comp 1006 Overall Or Steel Comp 1008 Overall Or Steel Comp 1009 Overall Or Steel Comp 1010 Overall Or Steel Comp 1011 Overall Or Steel Comp 1012 Overall Or Steel Comp 1013 Overall Or Steel Comp 1015 Overall Or Steel Comp 1016 Overall Or Steel Comp 1017 Overall Or Steel Comp 1018 Overall Or Steel Comp 1019 Overall Or Steel Comp 1020 Overall Or Steel Comp 1021 Overall Or Steel Comp 1022 Overall
- Nondefinitive Spec/Std Data [ZZZT]
- 4 Type And E Grade
- Material Document And Classification [MDCL]
- 66 Fed Std All Material Responses Overall
- Shank Diameter [AAZE]
- 0.126 Inches Minimum And 0.132 Inches Maximum
- Shank Style [AAZF]
- Straight
- Shear Strength [CQSX]
- 32000 Single Pounds Per Square Inch
- Surface Treatment Document And Classification [STDC]
- Mil-T-10727 Mil Spec Single Treatment Response Overall
- Surface Treatment [SFTT]
- Tin Overall
DLA Procurement Analysis 5320-00-256-6404
- Last Stock Position:
- 3723 In Stock
- DLA Administrative Lead Time:
- Subscribe
- DLA Production Lead Time:
- Subscribe
Management Data 5320-00-256-6404
Army
- Materiel Category and Inventory Manager:
- T
- Industrial Supplies (DLA/GSA Items)
- Appropriation and Budget Activity:
- 2
- Stock Fund Secondary Items
- Management Inventory Segment:
- 2
- Non-Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify items, which are not reparable.
- Weapons System / End Item / Homogeneous Group:
- 00
- DLA/GSA Material
DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item
- Accounting Requirements:
- X
- Expendable item.An item of Army property coded with an ARC of X in the AMDF. Expendable items require no formal accountability after issue from a stock record account.Commercial and fabricated items similar to items coded X in the AMDF are considered expendable items.
Air Force
- Fund:
- SF
- Stock fund applicable to items managed for the Air Force by the respective Inventory Control Point
- Budget:
- 9
- 57X4921.070 - General Support DIV - Air Force decentralized managed expense items (ERRC XB3, XF3) with a unit cost of less than $250,000 that are requisitioned/procured at base (retail) level from DLA, GSA, Army, Navy, Depot Maintenance Service, Air Force Industrial Fund (AFMC), local manufacture and commercial vendors
- Aggregation Code:
- SX
- SICA RESIDUAL MMAC-OC-ALC
- Price Validation Code:
- N
- The current standard price in Catalog Management Data (CMD) has not analyzed or coded for LP/LM.
The price has not been analyzed or reviewed for accuracy.
ZOP or Standard price challenges are permissible but must be supported with adequate justification. However, if coded for Local Purchase (LP) or Fabrication/Manufacture as indicated with an (LM) Acquisition Advice Code of “L” or “F”, then it must be evaluated locally where purchased or fabricated.
- Expendability
Recoverability
Repairability: - N
- Expendable. Condemn at User. Stock Fund (except Munitions).
Similar Supply Items to 5320-00-256-6404
Freight Information 5320-00-256-6404
5320-00-256-6404 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 106510. A Sub NMFC of X. It has a NMFC Description of RIVETS I/S PLAIN/GALVANIZED ETC. 5320-00-256-6404 is rated as class 50 when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 54760 which rates the freight between FCL and LCL. 5320-00-256-6404 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 576 for ocean manifesting and military sealift. 5320-00-256-6404 is not classified as a special type of cargo when transported by water. 5320-00-256-6404 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 5320-00-256-6404
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- Plated/Coated Item
- 2lb or less, one dimension 2" or less, other dimensions less than 24"
- Above 110G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- --
- --
- --
- --
- Physical Protection
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- No Requirement
- No Requirement
- Not Applicable
- PPP-B-566, PPP-B-676, or ASTM-D5118, Folding, Setup or Fiberboard Box
- No special marking
- No Requirement
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- --
- No Requirement
Procurement History 5320-00-256-6404 1 Records
Contracting Technical Data File (CTDF) 5320-00-256-6404 August 2020
Criticality and Quality
- Critical Item Code:
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- N
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
