5315-01-521-2478
Quick Release Pin
5315015212478 015212478 CLM-6-BLPT-40 CLM-06-BLPT-40
A headed fastening device having a solid cylindrical or tubular body with retaining ball or pinlike detent(s). The detent(s) is/are positioned and actuated by means of a spring, elastomer or plunger. Plunger may be operated by thumb, cam or other means. May be furnished with a pull ring, pull and/or lock ring, attaching ring or hook. View more Quick Release Pin
May 2023
3
Marketplace 5315-01-521-2478
Request a Quotation from participating marketplace vendors
Related Documents 5315-01-521-2478 5+ Documents (More...)
Photo 1/7 5315-01-521-2478 Photo 2/7 5315-01-521-2478 Photo 3/7 5315-01-521-2478 Photo 4/7 5315
-01-521-2478 Photo 5/7 5315-01-521-2478 Photo 6/7 NSN 5315-01-521-2478 (Identification) 7/7 - - - - -
www.nsnlookup.com /fsg-53/fsc-5315/us 5315-01-616-1494 Quick Release Pin 5315016161494016161494 CLM-6-BLPT-40
Quick Release Pin 5315015212478 015212478 Quotation Updated Every Day 5315-01-521-2478 RQST NE
Restrictions 5315-01-521-2478
5315-01-521-2478 is a Quick Release Pin that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
End Users 5315-01-521-2478
- Spain (YB01)
- Effective Date:
- 1 Jan 2005
- Germany (ZG01)
- Effective Date:
- 1 Jan 2005
- United Kingdom (ZK01)
- Effective Date:
- 1 Jun 2004
Approved Sources 5315-01-521-2478
- Part Number
- Manufacturer
- Status
- CLM-6-BLPT-40
- Manufacturer
- 99862 - Carr Lane Manufacturing Co (Active)
- Primary Buy
- Primary Buy
- CLM-06-BLPT-40
- 99862 - Carr Lane Manufacturing Co (Active)
- Secondary Buy
- Secondary Buy
Datasheet 5315-01-521-2478
- Characteristic
- Specifications
- FIIG
- Specifications
- A212A0
- Material [MATT]
- Steel Overall
- Style Designator [STYL]
- T Handle
- Handle Length [AASN]
- 44.0 Millimeters Nominal
- Shank Diameter [AAZE]
- 5.9 Millimeters Nominal
- Grip Length [ANEE]
- 40.0 Millimeters Nominal
- Shoulder To Head End Distance [CRQD]
- 32.0 Millimeters Nominal
- Detent To Tapered End Distance [CTXT]
- 6.99 Millimeters Nominal
- Actuation Type [APCM]
- Push
- Actuation Method [AFLW]
- Push Button
- Detent Quantity [ABRM]
- 2
- Pin Attachment Type [CTDJ]
- Ring
- End Item Identification [AGAV]
- Eurofighter 2000
Similar Supply Items to 5315-01-521-2478
Freight Information 5315-01-521-2478
5315-01-521-2478 has freight characteristics.. 5315-01-521-2478 has a variance between NMFC and UFC when transported by rail and the description should be consulted.
