5315-00-837-4545
Spring Pin
5315008374545 008374545 Y178-28 MS16562-29 NAS561P3-14 12267970 MS16562-123 52-022-094-0875 F52-022-094-0875 5315PL0941607
A tubular item, so formed as to provide a spring action against the inside wall of a hole when driven into abutting pieces to position and hold them in place. View more Spring Pin
Managed by United States
NSN Created on 1 Jan 1962
Data Last Changed
July 2025
July 2025
NATO Update Count
62
62
NATO Data Quality
Marketplace 5315-00-837-4545
Need Help?
Request a Quotation from participating marketplace vendors
Request a Quotation from participating marketplace vendors
NAS561P3-14 PIN,SPRING 100 HD NS
12267970 PIN,SPRING 100 HD NS
F52-022-094-0875 PIN,SPRING 100 HD NS
MS16562-29 PIN,SPRING 100 HD NS
52-022-094-0875 PIN,SPRING 100 HD NS
Updated Every Day 5315-00-837-4545 RQST NE
Updated Every Day 5315-00-837-4545 RQST
Updated Every Day 5315-00-837-4545 RQST NE
Related Documents 5315-00-837-4545 5+ Documents (More...)
Y178-28 MS16562-29 NAS561P3-14 12267970 MS16562-123 52-022-094-0875 F52-022-094-0875 5315PL0941607 A
NAS561P3-14 PIN,SPRING 1000 HD NS Request Quotation Subscribe to View Vendor Details... 5315-00-837-4545
NAS561P3-14 PIN,SPRING 100 HD NS Request Quotation 12267970 PIN,SPRING 100 HD NS Request Quotation F52
NAS561P3-14 PIN,SPRING 1000 HD NS Request Quotation Subscribe to View Vendor Details... 5315-00-837-4545
NAS561P3-14 PIN,SPRING 100 HD NS Request Quotation 12267970 PIN,SPRING 100 HD NS Request Quotation F52
web browser . 5315-21-608-9118Spring Pin5315216089118 216089118 Cancelled - Replaced by NSN 5315-00-837-4545
vendors Request Restrictions 5315-21-608-9118 DEMIL https//www.nsnlookup.com /fsg-53/fsc-5315/us 5315-00-837-4545
Spring Pin 5315008374545 008374545,,Y178-28 094-0875 PIN,SPRING 100 EA NS Request Quotation https
vendors Request Restrictions 5315-21-608-9118 DEMIL https//www.nsnlookup.com /fsg-53/fsc-5315/us 5315-00-837-4545
Spring Pin 5315008374545 008374545,,Y178-28 094-0875 PIN,SPRING 100 EA NS Request Quotation https
MS16562-29 PIN,SPRING 77 EA NS Request Quotation Subscribe to View Vendor Details...
NAS561P3-14 PIN,SPRING 500 EA NS Request Quotation Subscribe to View Vendor Details... 52-022-094-0875
MS16562-29 PIN,SPRING 100 EA NS Request Quotation 52-022-094-0875 PIN,SPRING 100 EA NS Request Quotation
NAS561P3-14 PIN,SPRING 500 EA NS Request Quotation Subscribe to View Vendor Details... 52-022-094-0875
MS16562-29 PIN,SPRING 100 EA NS Request Quotation 52-022-094-0875 PIN,SPRING 100 EA NS Request Quotation
MS16562-29 PIN,SPRING 77 HD NS Request Quotation Subscribe to View Vendor Details...
MS16562-29 PIN,SPRING 34 HD NS Request Quotation Subscribe to View Vendor Details...
NAS561P3-14 PIN,SPRING 500 HD NS Request Quotation Subscribe to View Vendor Details... 52-022-094-0875
MS16562-29 PIN,SPRING 34 HD NS Request Quotation Subscribe to View Vendor Details...
NAS561P3-14 PIN,SPRING 500 HD NS Request Quotation Subscribe to View Vendor Details... 52-022-094-0875
Spring Pin 9999991455105 991455105 844-3965 5315-00-069-4704 5315-99-290-6462 5315-00-664-3162 5315-00-837-4545
Spring Pin 9999991455178 991455178 844-3965 5315-00-069-4704 5315-99-290-6462 5315-00-664-3162 5315-00-837-4545
Spring Pin 9999992150368 992150368 844-3965 5315-00-069-4704 5315-99-290-6462 5315-00-664-3162 5315-00-837-4545
Spring Pin 9999991455178 991455178 844-3965 5315-00-069-4704 5315-99-290-6462 5315-00-664-3162 5315-00-837-4545
Spring Pin 9999992150368 992150368 844-3965 5315-00-069-4704 5315-99-290-6462 5315-00-664-3162 5315-00-837-4545
Restrictions 5315-00-837-4545
5315-00-837-4545 is a Spring Pin that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
Import and Export 5315-00-837-4545
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5315-00-837-4545
- US Army (A919)
- Effective Date:
- 1 Apr 2006
- Former MOE Rule:
- A187
- Supplementary Receivers:
- AJCLBFBDAZ
- US Coast Guard (C918)
- Effective Date:
- 1 Apr 2006
- Former MOE Rule:
- C004
- US Air Force (FXGI)
- Effective Date:
- 1 Apr 2006
- Former MOE Rule:
- FXKZ
- US Marine Corps (MC47)
- Effective Date:
- 1 Apr 2006
- Former MOE Rule:
- MC10
- US Navy (N9BZ)
- Effective Date:
- 1 Apr 2006
- Former MOE Rule:
- N9ZD
- Supplementary Collaborators:
- GTKEJNHXHD
- Austria (WB01)
- Effective Date:
- 1 Feb 2005
- Lithuania (WI01)
- Effective Date:
- 1 Mar 2001
- Poland (WP01)
- Effective Date:
- 1 Aug 2004
- Brazil (YA01)
- Effective Date:
- 1 Oct 2000
- Spain (YB01)
- Effective Date:
- 1 Apr 1991
- Israel (YD01)
- Effective Date:
- 1 Aug 2016
- Singapore (YJ01)
- Effective Date:
- 1 Apr 1991
- Kuwait (YK01)
- Effective Date:
- 1 Jan 2015
- Morocco (YP01)
- Effective Date:
- 1 Nov 2008
- Malaysia (YW01)
- Effective Date:
- 1 Apr 1991
- Australia (ZA01)
- Effective Date:
- 1 Apr 1991
- Belgium (ZB01)
- Effective Date:
- 1 Apr 1991
- Canada (ZC01)
- Effective Date:
- 1 May 2000
- New Zealand (ZE01)
- Effective Date:
- 1 Apr 1991
- France (ZF01)
- Effective Date:
- 1 Apr 1991
- Germany (ZG01)
- Effective Date:
- 1 Apr 1991
- Republic of Korea (ZH01)
- Effective Date:
- 1 Apr 1991
- United Kingdom (ZK01)
- Effective Date:
- 1 Apr 1991
- Netherlands (ZN01)
- Effective Date:
- 1 Apr 1991
- Portugal (ZP01)
- Effective Date:
- 1 Apr 1991
- Italy (ZR01)
- Effective Date:
- 1 Apr 1991
- Denmark (ZS01)
- Effective Date:
- 1 Apr 1991
- Norway (ZT01)
- Effective Date:
- 1 Apr 1991
- Greece (ZU01)
- Effective Date:
- 1 Apr 1991
- Turkey (ZW01)
- Effective Date:
- 1 Aug 1993
- NATO Maintenance and Supply Agency (ZX01)
- Effective Date:
- 1 Apr 1991
Approved Sources 5315-00-837-4545
- Part Number
- Manufacturer
- Status
- MS16562-29
- Manufacturer
- 80205 - National Aerospace Standards (Active)
- Primary Buy
- Primary Buy
- 52-022-094-0875
- 86403 - Chrysler Corp Service And Parts Opns (Active)
- Secondary Buy
- Secondary Buy
- MS16562-29
- A9271 - Goriziane Group Spa (Active)
- Secondary Buy
- Secondary Buy
- NAS561P3-14
- 80205 - National Aerospace Standards (Active)
- Secondary Buy
- Secondary Buy
- 12267970
- 19207 - U S Army Tank Automotive Command (Active)
- Secondary Buy
- Secondary Buy
- 5315008374545
- SCY13 - E.C.A Etablissement (Replaced)
- Canceled/Obsolete
- Canceled/Obsolete
- MS16562-123
- 80205 - National Aerospace Standards (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- 52-022-094-0875
- 72962 - Harvard Industries Inc (Replaced)
- Canceled/Obsolete
- Canceled/Obsolete
- F52-022-094-0875
- 72962 - Harvard Industries Inc (Replaced)
- Canceled/Obsolete
- Canceled/Obsolete
- MS16562-29
- 96906 - Military Standards (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- MS16562-123
- 96906 - Military Standards (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- 5315PL0941607
- 9009H - Jednolity Indeks Materialowy - (Active)
- NATO Reference
- NATO Reference
- 5315008374545
- A00AM - E.C.A Etablissement Central Des (Active)
- NATO Reference
- NATO Reference
- Y178-28
- 03990 - Ingersoll-Rand Company (Active)
- Advisory Reference
- Advisory Reference
Datasheet 5315-00-837-4545
- Characteristic
- Specifications
- FIIG
- Specifications
- A212A0
- Diameter [ABMZ]
- 0.099 Inches Minimum And 0.103 Inches Maximum
- Hardness Rating [CQFM]
- 46.0 Rockwell C Minimum Overall And 53.0 Rockwell C Maximum Overall
- Material Thickness [ABPX]
- 0.022 Inches Nominal
- Material [MATT]
- Steel Comp 1070 Overall Or Steel Comp 1074 Overall Or Steel Comp 1080 Overall Or Steel Comp 1086 Overall Or Steel Comp 1095 Overall
- Material Document And Classification [MDCL]
- 66 Fed Std All Material Responses Overall
- Shear Strength [CQSX]
- 1000 Double Pound
- Overall Length [ABHP]
- 0.860 Inches Minimum And 0.890 Inches Maximum
- Style Designator [STYL]
- Slotted
- Surface Treatment Document And Classification [STDC]
- Qq-P-416,Ty2 Cl2 Fed Spec Single Treatment Response Overall
- Surface Treatment [SFTT]
- Cadmium Overall And Chromate Overall
Weapon Systems (WSDC) 5315-00-837-4545
DLA Procurement Analysis 5315-00-837-4545
- Last Stock Position:
- 40100 In Stock
- DLA Administrative Lead Time:
- Subscribe
- DLA Production Lead Time:
- Subscribe
Management Data 5315-00-837-4545
- Effective Date
- Organization
- Unit of Issue
- Unit Price
- Qty Unit Pack
- Unit of Issue
- Oct 2022
- Department of the Air Force (DF)
- HD
- Subscribe
- 1
- HD
- Dec 2021
- Department of the Air Force (DF)
- HD
- Subscribe
- 1
- HD
- Oct 2021
- US Marine Corps (DM)
- HD
- Subscribe
- 1
- HD
- Oct 2020
- Defense Logistics Agency (DS)
- HD
- Subscribe
- 1
- HD
- Oct 2019
- Department of the Air Force (DF)
- HD
- Subscribe
- 1
- HD
- MOE
- USC
- Code
- Statement
- Order of Use
- Jump To Code
- Qty Per Assy
- UOM
- Technical Document
- Quantative Expression
- Code
- US Marine Corps (DM)
- M
- 0
- Reversal Of Phrase Code Z 5315-00-058-6070
- 0
Army
- Materiel Category and Inventory Manager:
- T
- Industrial Supplies (DLA/GSA Items)
- Appropriation and Budget Activity:
- 2
- Stock Fund Secondary Items
- Management Inventory Segment:
- 2
- Non-Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify items, which are not reparable.
- Weapons System / End Item / Homogeneous Group:
- 00
- DLA/GSA Material
DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item
- Accounting Requirements:
- X
- Expendable item.An item of Army property coded with an ARC of X in the AMDF. Expendable items require no formal accountability after issue from a stock record account.Commercial and fabricated items similar to items coded X in the AMDF are considered expendable items.
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
- Special Material Content:
- 9
- Non-Hazardous or Non-Sensitive Item
Marine Corps
- Stores Account:
- 1
- Stock Fund Account Item
- Combat Essentiality:
- 5
- Critical Repair Part to a Combat Essential End Item
- Echelon Management:
- B2
- Material Identification:
- B
- Consumable Repair Parts
- Operational Test:
- No Special Procedures
Similar Supply Items to 5315-00-837-4545
Freight Information 5315-00-837-4545
5315-00-837-4545 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 095190. A Sub NMFC of J. It has a NMFC Description of HARDWARE, NOI SUB 9. 5315-00-837-4545 is rated as class 70 when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 49790 which rates the freight between FCL and LCL. 5315-00-837-4545 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 713 for ocean manifesting and military sealift. 5315-00-837-4545 is not classified as a special type of cargo when transported by water. 5315-00-837-4545 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 5315-00-837-4545
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- Plated/Coated Item
- 2lb or less, one dimension 2" or less, other dimensions less than 24"
- Above 110G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- --
- --
- --
- Physical Protection
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- No Requirement
- No Requirement
- Not Applicable
- Any Suitable Container
- No special marking
- No Requirement
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- PPP-B-566, PPP-B-676, or ASTM-D5118, Folding, Setup or Fiberboard Box
Contracting Technical Data File (CTDF) 5315-00-837-4545 February 2021
Criticality and Quality
- Critical Item Code:
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- F
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- N
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
