5315-00-084-1996
Powder Actuated Drive Pin
5315000841996 000841996 GGGD777 2411
An item designed to fasten metal, wood, composition material and the like to concrete, masonry, metal, and wood, with power provided from a cartridge (powder), compressed gas, pneumatic and/or hydraulic power. Excludes items that have the actuating media as an integral part of the pin. View more Power Actuated Drive Pin
January 2023
6
Marketplace 5315-00-084-1996
Request a Quotation from participating marketplace vendors
Related Documents 5315-00-084-1996 5+ Documents (More...)
United States (US) 4. 5315-00-084-1996 Marketplace Restrictions Approved Sources Datasheet Management
ACTUATED 3 EA NS Request Quotation Updated Every Day 5315-00-084-1996 RQST NE Updated Every Day 5315-
vendors Request Restrictions 5315-21-860-4572 DEMIL https//www.nsnlookup.com /fsg-53/fsc-5315/us 5315-00-084-1996
Powder Actuated Drive Pin 5315000841996 Account Upgrade 5130-21-102-8781Powder Actuated https//
Powder Actuated Drive Pin 5315000841996 day Upgrade your Account Upgrade 5315-00-084-1996Powder
Actuated Drive Pin5315000841996 000841996 GGGD777 Powder Actuated Drive Pin 5315006630010 day Upgrade
Powder Actuated Drive Pin 5315000841996 day Upgrade your Account Upgrade 5315-00-084-1996Powder
Actuated Drive Pin5315000841996 000841996 GGGD777 day Upgrade your Account Upgrade 5315-00-663-0010Powder
Powder Actuated Drive Pin 5315000841996 day Upgrade your Account Upgrade 5315-00-084-1996Powder
Actuated Drive Pin5315000841996 000841996 GGGD777 day Upgrade your Account Upgrade 5315-00-663-0010Powder
Restrictions 5315-00-084-1996
5315-00-084-1996 is a Powder Actuated Drive Pin that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
End Users 5315-00-084-1996
- Canada (ZC01)
- Effective Date:
- 1 Apr 1991
Approved Sources 5315-00-084-1996
- Part Number
- Manufacturer
- Status
- 2411
- Manufacturer
- 30323 - Illinois Tool Works Inc (Active)
- Primary Buy
- Primary Buy
- 2411
- 11078 - Ramset Ltd (Obsolete)
- Original Design
- Original Design
- GGGD777
- 81348 - Federal Specifications Promulgated (Active)
- Incomplete Standard
- Incomplete Standard
Datasheet 5315-00-084-1996
- Characteristic
- Specifications
- FIIG
- Specifications
- A212A0
- Grip Diameter [AAUR]
- 0.212 Inches Minimum And 0.250 Inches Maximum
- Material For Which Designed [BTPM]
- Steel
- Material [MATT]
- Steel Overall
- Nominal Thread Size [CQJX]
- 0.250 Inches
- Nondefinitive Spec/Std Data [ZZZT]
- C Style
- Shank Diameter [AAZE]
- 0.155 Inches Nominal
- Shank Length [AATR]
- 0.688 Inches Nominal
- Overall Length [ABHP]
- 2.750 Inches Nominal
- Style Designator [STYL]
- Powder Actuated
- Surface Treatment [SFTT]
- Zinc Overall
- Thread Class [AAJD]
- 2A
- Thread Direction [AAJF]
- Right-Hand
- Thread Length [AASA]
- 1.000 Inches Nominal
- Thread Series Designator [THSD]
- Unc
Similar Supply Items to 5315-00-084-1996
Freight Information 5315-00-084-1996
5315-00-084-1996 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 095190. A Sub NMFC of J. It has a NMFC Description of HARDWARE, NOI SUB 9. 5315-00-084-1996 is rated as class 70 when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 49790 which rates the freight between FCL and LCL. 5315-00-084-1996 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 713 for ocean manifesting and military sealift. 5315-00-084-1996 is not classified as a special type of cargo when transported by water. 5315-00-084-1996 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
