5310-01-089-5672
Recessed Washer
5310010895672 010895672 MS14155-6 9387511203 10122108 5310PL2202692
A washer of any peripheral shape having a centrally located hole. Both bearing surfaces are parallel and flat, but one or both of the bearing surfaces must be broken by a counterbore, countersink, or similarly shaped recess. The thickness must not exceed 25 per cent of the outside diameter or the largest outside dimension. The maximum limit of the tolerance or range applied to the thickness and/or largest outside dimension must be used to determine compliance. Excludes WASHER, CONCAVE, RETAINER, PACKING, and thrust type washers. See also SPACER, SLEEVE; and SPACER, STEPPED. View more Recessed Washer
Managed by United States
NSN Created on 5 Feb 1980
Data Last Changed
November 2023
November 2023
NATO Update Count
32
32
NATO Data Quality
Marketplace 5310-01-089-5672
Need Help?
Request a Quotation from participating marketplace vendors
Request a Quotation from participating marketplace vendors
Related Documents 5310-01-089-5672 5+ Documents (More...)
MS14155-6 9387511203 10122108 5310PL2202692 A washer of any peripheral shape having a centrally located
Photo 1/3 5310-01-089-5672 Photo 2/3 NSN 5310-01-089-5672 (Identification) 3/3 - - - 1.
MS14155-6 WASHER 7 EA NS Request Quotation MS14155-6 WASHER 8 EA NS Request Quotation Subscribe to View
Photo 1/3 5310-01-089-5672 Photo 2/3 NSN 5310-01-089-5672 (Identification) 3/3 - - - 1.
MS14155-6 WASHER 7 EA NS Request Quotation MS14155-6 WASHER 8 EA NS Request Quotation Subscribe to View
for $1 a day Upgrade your Account Upgrade 9905-00-925-4414Instruction Plate9905009254414 009254414 10122108
/www.nsnlookup.com /fsg-99/fsc-9905/us 9905-00-925-4414 Instruction Plate 9905009254414009254414 10122108
vendors Request Updated Every Day 9905-00-925-4414 https//www.nsnlookup.com /fsg-53/fsc-5310/us 5310-01-089-5672
/www.nsnlookup.com /fsg-99/fsc-9905/us 9905-00-925-4414 Instruction Plate 9905009254414009254414 10122108
vendors Request Updated Every Day 9905-00-925-4414 https//www.nsnlookup.com /fsg-53/fsc-5310/us 5310-01-089-5672
EDC: | ADPEC : 9999-99-617-1655 is a Recessed Washer Similar Supply Items to 9999-99-617-1655 5310-01-089-5672
EDC: | ADPEC : 9999-99-610-6182 is a Recessed Washer Similar Supply Items to 9999-99-610-6182 5310-01-089-5672
EDC: | ADPEC : 9999-99-610-6197 is a Recessed Washer Similar Supply Items to 9999-99-610-6197 5310-01-089-5672
Restrictions 5310-01-089-5672
5310-01-089-5672 is a Recessed Washer that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. The precious metals content of this item is unknown.
Import and Export 5310-01-089-5672
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5310-01-089-5672
- US Air Force (FXGI)
- Effective Date:
- 1 Apr 2006
- Former MOE Rule:
- FXKZ
- US Marine Corps (MC47)
- Effective Date:
- 1 Apr 2006
- Former MOE Rule:
- MC10
- US Navy (N9BZ)
- Effective Date:
- 1 Apr 2006
- Former MOE Rule:
- N9ZD
- Supplementary Collaborators:
- GTKE
- Finland (WF01)
- Effective Date:
- 1 Jul 2009
- Poland (WP01)
- Effective Date:
- 1 Feb 2007
- Brazil (YA01)
- Effective Date:
- 1 May 2012
- Spain (YB01)
- Effective Date:
- 1 Apr 1991
- Singapore (YJ01)
- Effective Date:
- 1 Apr 1991
- Malaysia (YW01)
- Effective Date:
- 1 Aug 1997
- Australia (ZA01)
- Effective Date:
- 1 Apr 1991
- Belgium (ZB01)
- Effective Date:
- 1 Jan 2002
- Canada (ZC01)
- Effective Date:
- 1 Apr 1991
- Republic of Korea (ZH01)
- Effective Date:
- 1 Apr 2008
- Netherlands (ZN01)
- Effective Date:
- 1 Jan 1998
- Portugal (ZP01)
- Effective Date:
- 1 Nov 2008
- Italy (ZR01)
- Effective Date:
- 1 Jul 1997
- Denmark (ZS01)
- Effective Date:
- 1 Jul 1998
- Norway (ZT01)
- Effective Date:
- 1 Jun 2003
- Greece (ZU01)
- Effective Date:
- 1 May 2008
Approved Sources 5310-01-089-5672
- Part Number
- Manufacturer
- Status
- MS14155-6
- Manufacturer
- 80205 - National Aerospace Standards (Active)
- Primary Buy
- Primary Buy
- MS14155-6
- A0170 - Leonardo Spa Aerostructure Division (Active)
- Secondary Buy
- Secondary Buy
- 9387511203
- S4080 - Pilatus Aircraft Ltd (Active)
- Secondary Buy
- Secondary Buy
- MS14155-6
- 96906 - Military Standards (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- 10122108
- A486G - Nimikkeistokeskus Ncb Finland (Active)
- NATO Reference
- NATO Reference
- 5310PL2202692
- 9009H - Jednolity Indeks Materialowy - (Active)
- NATO Reference
- NATO Reference
Datasheet 5310-01-089-5672
- Characteristic
- Specifications
- FIIG
- Specifications
- A022B0
- Bottom Recess Angle [CRKG]
- 90.0 Degrees Nominal
- Bottom Recess Diameter [CSML]
- 0.494 Inches Minimum And 0.504 Inches Maximum
- Hardness Rating [CQFM]
- 39.0 Rockwell C Minimum And 43.0 Rockwell C Maximum
- Hole Diameter [AAUB]
- 0.376 Inches Minimum And 0.380 Inches Maximum
- Material Document And Classification [MDCL]
- Mil-S-5059,Ty 302,1/2 Hard Mil Spec 1St Material Response Overall Or Mil-S-18729 Mil Spec 2Nd Material Response Overall
- Material Thickness [ABPX]
- 0.144 Inches Minimum And 0.158 Inches Maximum
- Material [MATT]
- Steel Comp 4130 Overall
- Outside Diameter [ABKV]
- 0.756 Inches Minimum And 0.766 Inches Maximum
- Top Recess Angle [CRSD]
- 90.0 Degrees Nominal
- Top Recess Diameter [CQJW]
- 0.494 Inches Minimum And 0.504 Inches Maximum
- Style Designator [STYL]
- Recessed Both Sides
- Surface Treatment Document And Classification [STDC]
- Qq-P-416,Ty 2,Cl 2 Fed Spec Single Treatment Response Overall
- Surface Treatment [SFTT]
- Cadmium Overall
Weapon Systems (WSDC) 5310-01-089-5672
DLA Procurement Analysis 5310-01-089-5672
- Last Stock Position:
- 12738 In Stock
- DLA Administrative Lead Time:
- Subscribe
- DLA Production Lead Time:
- Subscribe
Management Data 5310-01-089-5672
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
Marine Corps
- Stores Account:
- 1
- Stock Fund Account Item
- Combat Essentiality:
- 2
- Non-Critical Repair Part
- Echelon Management:
- B2
- Operational Test:
- No Special Procedures
Similar Supply Items to 5310-01-089-5672
Freight Information 5310-01-089-5672
5310-01-089-5672 has freight characteristics managed by the Southwestern Power Administration.It has a National Motor Freight Classification (NMFC) of 194160. A Sub NMFC of X. It has a NMFC Description of WASHER OR GASKETS, IRON OR STEEL,. 5310-01-089-5672 is rated as class 50 when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 55210 which rates the freight between FCL and LCL. 5310-01-089-5672 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 713 for ocean manifesting and military sealift. 5310-01-089-5672 is not classified as a special type of cargo when transported by water. 5310-01-089-5672 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 5310-01-089-5672
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- Bare Metal Item
- 2lb or less, one dimension 2" or less, other dimensions less than 24"
- Above 110G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- --
- --
- --
- --
- Physical Protection
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- No Requirement
- No Requirement
- Not Applicable
- Bags made of material conforming to MIL-P-130, MIL-DTL-17667, MIL-PRF-121, or any material authorized by MIL-DTL-117. Closure may be by staples, tape, adhesive or heat seal
- No special marking
- No Requirement
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- PPP-B-566, PPP-B-676, or ASTM-D5118, Folding, Setup or Fiberboard Box
