5310-00-934-9747

Hexagon Plain Nut

5310009349747 009349747 MILS933TYPEA 134530 MS20341-65 MS35469-262 MS35649-062 82-3017-005 4157400-29 M35649-262 313-0117-000 2810208-002 MS 35649-262 9842437-13-8 607F489 GR2 PC 49 911C208-3 411115-62 313011700 102-3S6 5031-208 002-003990-009 0716832 806ADX 404 594 C51A83 HNW-559 115997

A nut, flat on top and bottom having 6 flat sides. For items which have internal tapered or straight (parallel) pipe threads, specific electrical conduit size designation, and which when installed, provide a method of tightening to lock the connection, see LOCKNUT, ELECTRICAL CONDUIT. See also LOCKNUT, TUBE FITTING. For items having a thickness (or height) exceeding two times the width across the flats, use POST, ELECTRICAL-MECHANICAL EQUIPMENT. (When height or thickness and/or width across the flats is designated as a tolerance dimension, the maximum dimension will be used to determine compliance.) View more Hexagon Plain Nut

Managed by United States

NSN Created on 8 Mar 1967

Data Last Changed
November 2023

NATO Update Count
180

NATO Data Quality

ACTA Style A12 for 5310-00-934-9747 1/1 — NSN 5310-00-934-9747 (Identification) 1/1

Marketplace 5310-00-934-9747

Need Help?
Request a Quotation from participating marketplace vendors

Subscribe to View Vendor Details...

MS35649-262 NUT,PLAIN,HEXAGON 112 HD NS

Subscribe to View Vendor Details...

632 NUT,PLAIN,HEXAGON 3704 HD NS

AN340-6 NUT,PLAIN,HEXAGON 8238 HD NS

MS35649-262 NUT,PLAIN,HEXAGON 110 HD NS

MS35649-062 NUT,PLAIN,HEXAGON 734 HD NS

FF-N836 NUT,PLAIN,HEXAGON 226 HD NS

FF-N-836 NUT,PLAIN,HEXAGON 35 HD NS

8006 NUT,PLAIN,HEXAGON 233 HD NS

FFN836. NUT,PLAIN,HEXAGON 126 HD NS

Subscribe to View Vendor Details...

MS35649-262 NUT 500 HD NS

MS35649-262 NUT 300 HD NS

MS35649-262 NUT 45868 HD NS

Subscribe to View Vendor Details...

NUT632 NUT,PLAIN,HEXAGON RQST NS

Subscribe to View Vendor Details...

5310-00-934-9747 NUT, PLAIN, HEXAGON 650 HD NS

Updated Every Day

5310-00-934-9747 RQST NE

Updated Every Day

5310-00-934-9747 RQST

Updated Every Day

5310-00-934-9747 RQST NE

Restrictions 5310-00-934-9747

5310-00-934-9747 is a Hexagon Plain Nut that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.

Import and Export 5310-00-934-9747

Schedule B: Subscribe to View Schedule B
HTS Code: Subscribe to View HTS Code

End Users 5310-00-934-9747

US Army (A919)
Effective Date:: 1 Apr 2006
Former MOE Rule:: A187
Supplementary Receivers:: AJCTCLBFBDAZ; AMC 1 AMSC G IMC Z IMCACTY CD

MOE Rule:: BGX1
Effective Date:: 1 Apr 2006
Former MOE Rule:: BKZ1; AMC 1 AMSC G

US Coast Guard (C918)
Effective Date:: 1 Apr 2006
Former MOE Rule:: C004
Supplementary Receivers:: XH; AMC 1 AMSC G

US Air Force (FXGI)
Effective Date:: 1 Apr 2006
Former MOE Rule:: FXKZ; AMC 1 AMSC G IMC Z IMCACTY SX

NASA (G070)
Effective Date:: 1 Apr 1991; AMC 0 AMSC 0 AAC L

NASA (G170)
Effective Date:: 1 Apr 1991; AMC 0 AMSC 0 AAC C

NASA (G180)
Effective Date:: 1 Apr 1991; AMC 0 AMSC 0 AAC C

NASA (G190)
Effective Date:: 1 Apr 1991; AMC 0 AMSC 0 AAC C

NASA (G860)
Effective Date:: 1 Apr 1991; AMC 0 AMSC 0 AAC C

NASA (G940)
Effective Date:: 1 Apr 1991; AMC 0 AMSC 0 AAC C

US Marine Corps (MC47)
Effective Date:: 1 Apr 2006
Former MOE Rule:: MC10; AMC 1 AMSC G IMC Z IMCACTY PA

US Navy (N9BZ)
Effective Date:: 1 Apr 2006
Former MOE Rule:: NIZD
Supplementary Collaborators:: GEKEJVJFJBHXHSHDGT; AMC 1 AMSC G IMC Z IMCACTY GH

MOE Rule:: S911
Effective Date:: 1 Apr 2006
Former MOE Rule:: S006; AMC 1 AMSC G IMC Z IMCACTY XN

Austria (WB01)
Effective Date:: 1 Feb 2005

Finland (WF01)
Effective Date:: 1 Jul 2009

Lithuania (WI01)
Effective Date:: 1 Jul 2000

Slovenia (WL01)
Effective Date:: 1 Jan 2012

Poland (WP01)
Effective Date:: 1 Nov 2006

MOE Rule:: X002
Effective Date:: 1 Apr 1991

Brazil (YA01)
Effective Date:: 1 Oct 2000

Spain (YB01)
Effective Date:: 1 Apr 1991

Columbia (YC01)
Effective Date:: 1 Jul 2015

Israel (YD01)
Effective Date:: 1 Apr 1991

Argentina (YF01)
Effective Date:: 1 Feb 2015

Singapore (YJ01)
Effective Date:: 1 Apr 1991

Kuwait (YK01)
Effective Date:: 1 Feb 2015

Morocco (YP01)
Effective Date:: 1 Nov 2008

Saudi Arabia (YS01)
Effective Date:: 1 Feb 2015

Malaysia (YW01)
Effective Date:: 1 Apr 1991

Thailand (YY01)
Effective Date:: 1 Feb 2015

Australia (ZA01)
Effective Date:: 1 Apr 1991

Belgium (ZB01)
Effective Date:: 1 Apr 1991

Canada (ZC01)
Effective Date:: 1 Apr 1991

New Zealand (ZE01)
Effective Date:: 1 Apr 1991

France (ZF01)
Effective Date:: 1 Apr 1991

Germany (ZG01)
Effective Date:: 1 Apr 1991

Republic of Korea (ZH01)
Effective Date:: 1 Apr 1991

United Kingdom (ZK01)
Effective Date:: 1 Apr 1991

Philippines (ZM01)
Effective Date:: 1 Feb 2015

Netherlands (ZN01)
Effective Date:: 1 Apr 1991

Portugal (ZP01)
Effective Date:: 1 Apr 1991

Italy (ZR01)
Effective Date:: 1 Apr 1991

Denmark (ZS01)
Effective Date:: 1 Apr 1991

Norway (ZT01)
Effective Date:: 1 Apr 2011

Greece (ZU01)
Effective Date:: 1 Apr 1991

Turkey (ZW01)
Effective Date:: 1 Aug 1993

NATO Maintenance and Supply Agency (ZX01)
Effective Date:: 1 Sep 2004

Approved Sources 5310-00-934-9747

Part Number
Manufacturer
Status
MS35649-262: 80205 - National Aerospace Standards (Active); Primary Buy; RNCC 3 RNVC 2 DAC E
MILS933TYPEA: 81349 - Military Specifications (Active); Incomplete Standard; RNCC 4 RNVC 1 DAC E
MS35649-262: 15090 - Raytheon Company (Active); Incomplete Secondary Reference; RNCC 5 RNVC 1 DAC 4
607F489 GR2 PC 49: 90099 - Northrop Grumman Systems Corporation (Active); Secondary Buy; RNCC 5 RNVC 2 DAC 1
911C208-3: 99167 - Hamilton Sundstrand Corporation (Active); Secondary Buy; RNCC 5 RNVC 2 DAC 2
411115-62: 96214 - Raytheon Company (Active); Secondary Buy; RNCC 5 RNVC 2 DAC 5
313011700: 94033 - Cardwell Condenser Corp (Active); Secondary Buy; RNCC 5 RNVC 2 DAC 5
102-3S6: 80063 - Us Army Communications & Electronics (Active); Secondary Buy; RNCC 5 RNVC 2 DAC 5
5031-208: 05869 - Raytheon Company (Active); Secondary Buy; RNCC 5 RNVC 2 DAC 6
002-003990-009: 26916 - Northrop Grumman Systems Corporation (Active); Secondary Buy; RNCC 5 RNVC 2 DAC E
0716832: S3002 - General Dynamics European, (Active); Secondary Buy; RNCC 5 RNVC 2 DAC 3
806ADX: 73734 - Federal Screw Products Inc. (Active); Secondary Buy; RNCC 5 RNVC 2 DAC E
313-0117-000: 13499 - Rockwell Collins, Inc. (Active); Secondary Buy; RNCC 5 RNVC 2 DAC 6
L-6611-49: 46717 - Pettibone Llc (Obsolete); Canceled/Obsolete; RNCC 5 RNVC 9 DAC E
3310630: 21340 - Itt Telecom Products Corp (Obsolete); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 5
HN-6-32: 08289 - The Delbert Blinn Co Inc (Active); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 4
1W19986FA7: 11530 - Lockheed Martin Corporation (Active); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 6
20501-21: 96774 - Honeywell International Inc. (Active); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 5
57435-804: 02734 - Lockheed Martin Corporation (Active); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 5
8006: 73734 - Federal Screw Products Inc. (Active); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 4
MS35649-262: 45152 - Oshkosh Corp (Active); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 5
NHS626-10: 80249 - Bae Systems Information And (Active); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 6
6-32: 73734 - Federal Screw Products Inc. (Active); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 1
5951740: S0522 - Tadiran Ltd (Obsolete); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 3
71141-262: 95097 - Little Giant Crane And Shovel Inc (Obsolete); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 5
BBKX2-503525: 00000 - Ordnance Corps (Obsolete); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 5
57435-804: 49671 - Lockheed Martin Corporation (Obsolete); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 5
911C208-3: 83843 - Sundstrand Corp Electric Power (Obsolete); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 2
ES692442: 64959 - American Telephone And Telegraph Co (Replaced); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 6
6026-1085-5: 36378 - Raytheon Technical Services Company (Replaced); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 5
5310009349747: SCY13 - E.C.A Etablissement (Replaced); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 9
ES692442: 70408 - At And T Corp (Obsolete); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 5
SP574-15: 09017 - Edo (Obsolete); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 5
AN340-6: 88044 - Aeronautical Standards Group (Active); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 4
MS20341-6S: 96906 - Military Standards (Active); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 4
MS35649-262: 96906 - Military Standards (Active); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 4
5310PL0812684: 9009H - Jednolity Indeks Materialowy - (Active); NATO Reference; RNCC 6 RNVC 9 DAC 9
5310PL0941876: 9009H - Jednolity Indeks Materialowy - (Active); NATO Reference; RNCC 6 RNVC 9 DAC 9
5310PL1370067: 9009H - Jednolity Indeks Materialowy - (Active); NATO Reference; RNCC 6 RNVC 9 DAC 9
10121849: A486G - Nimikkeistokeskus Ncb Finland (Active); NATO Reference; RNCC 6 RNVC 9 DAC 9
134530: 80195 - Ed Etnyre & Co (Active); Advisory Reference; RNCC C RNVC 1 DAC 6
MS20341-65: D9182 - Zf Industrieantriebe Witten Gmbh (Active); Advisory Reference; RNCC C RNVC 1 DAC 6
MS35469-262: D9182 - Zf Industrieantriebe Witten Gmbh (Active); Advisory Reference; RNCC C RNVC 1 DAC 6
MS35649-062: D9182 - Zf Industrieantriebe Witten Gmbh (Active); Advisory Reference; RNCC C RNVC 1 DAC 6
82-3017-005: 04664 - Pierce Manufacturing Inc (Active); Advisory Reference; RNCC C RNVC 1 DAC 6
4157400-29: D9182 - Zf Industrieantriebe Witten Gmbh (Active); Advisory Reference; RNCC C RNVC 1 DAC 6
M35649-262: D9182 - Zf Industrieantriebe Witten Gmbh (Active); Advisory Reference; RNCC C RNVC 1 DAC 6
313-0117-000: 95105 - Rockwell Collins, Inc. (Active); Advisory Reference; RNCC C RNVC 1 DAC 6
2810208-002: 29436 - Cyberguard Corporation (Active); Advisory Reference; RNCC C RNVC 1 DAC 5
MS35469-262: 80205 - National Aerospace Standards (Active); Advisory Reference; RNCC C RNVC 1 DAC 5
MS 35649-262: D9182 - Zf Industrieantriebe Witten Gmbh (Active); Advisory Reference; RNCC C RNVC 1 DAC 6
9842437-13-8: 94833 - Keco Industries, Inc. (Replaced); Advisory Reference; RNCC C RNVC 1 DAC 5
404 594: 77294 - Piper Industrial Manufacturing (Active); Transferred; RNCC E RNVC 8 DAC 5
C51A83: 58588 - Surface Combustion Inc (Active); Transferred; RNCC E RNVC 8 DAC 5
HNW-559: 08289 - The Delbert Blinn Co Inc (Active); Transferred; RNCC E RNVC 8 DAC 4
115997: 21450 - Army Weapons Command (Active); Transferred; RNCC E RNVC 8 DAC 1
8528047: 18876 - Us Army Aviation And Missile Command (Active); Transferred; RNCC E RNVC 8 DAC 5
10965034: 19203 - Combat Capabilities Development (Active); Transferred; RNCC E RNVC 8 DAC 5
76784: 57733 - Stewart-Warner Corporation (Active); Transferred; RNCC E RNVC 8 DAC 5
STD3051-2: 99193 - Honeywell International Inc. (Active); Transferred; RNCC E RNVC 8 DAC 4
219049: 31361 - Woodward, Inc. (Active); Transferred; RNCC E RNVC 8 DAC 5
25-000091-008: 63123 - Farris, M & Associates (Active); Transferred; RNCC E RNVC 8 DAC 5
FFS836: 81348 - Federal Specifications Promulgated (Active); Transferred; RNCC E RNVC 8 DAC 3
219049: 66503 - Woodward, Inc. (Active); Transferred; RNCC E RNVC 8 DAC 1
FF-N-836: 81348 - Federal Specifications Promulgated (Active); Transferred; RNCC E RNVC 8 DAC 4

Datasheet 5310-00-934-9747

Characteristic
Specifications
FIIG: A021A0
Bearing Surface Type [CRTM]: Chamfered
Material [MATT]: Steel Overall
Nominal Thread Size [CQJX]: 0.138 Inches
Nut Height [ADEA]: 0.102 Inches Minimum And 0.114 Inches Maximum
Nut Style [ACTA]: Hexagon
Width Across Flats [ASDB]: 0.302 Inches Minimum And 0.312 Inches Maximum
Surface Treatment Document And Classification [STDC]: Qq-P-416,Ty 2,Cl 3 Fed Spec Single Treatment Response Overall
Surface Treatment [SFTT]: Cadmium Overall And Chromate Overall Or Phosphate Overall
Thread Class [AAJD]: 2B
Thread Direction [AAJF]: Right-Hand
Thread Series [BZRR]: Unc
Thread Quantity Per Inch [CMLP]: 32

Weapon Systems (WSDC) 5310-00-934-9747

Subscribe
View WSDC

Subscribe to View Weapon System Codes...

Subscribe
View Data

DLA Procurement Analysis 5310-00-934-9747

Last Stock Position:: 346600 In Stock
DLA Administrative Lead Time:: Subscribe
DLA Production Lead Time:: Subscribe

Subscribe to View DLA Inventory and Forecast...

Management Data 5310-00-934-9747

Subscribe
View Prices

Effective Date: Organization; Unit of Issue; Unit Price; Qty Unit Pack
Nov 2022: Defense Logistics Agency (DS); HD; Subscribe; 1
Oct 2022: US Marine Corps (DM); HD; Subscribe; 1
Oct 2021: US Marine Corps (DM); HD; Subscribe; 1
Oct 2020: Defense Logistics Agency (DS); HD; Subscribe; 1
Oct 2019: Department of the Air Force (DF); HD; Subscribe; 1

MOE: USC; Code; Statement; Order of Use; Jump To Code; Qty Per Assy; UOM; Technical Document; Quantative Expression
Department of the Air Force (DF): F; 7; Substitute For 5310-00-804-3859; AAA
Department of the Air Force (DF): F; R; Refer To Approved For Faa Use; APPROVED FOR FAA USE
Department of the Air Force (DF): F; Dod I&S Family Master Nsn - - -; ABA
US Marine Corps (DM): M; 7; Substitute For 5310-00-804-3859; AAA
US Marine Corps (DM): M; Dod I&S Family Master Nsn - - -; ABA
Department of the Navy (DN): N; 7; Substitute For 5310-00-804-3859; AAA
Department of the Navy (DN): N; Dod I&S Family Master Nsn - - -; ABA
Defense Logistics Agency (DS): I; 7; Substitute For 5310-00-804-3859; AAA
Defense Logistics Agency (DS): I; Dod I&S Family Master Nsn - - -; ABA
US Coast Guard (GP): C; 7; Substitute For 5310-00-804-3859
Department of the Army (DA): A; 7; Substitute For 5310-00-804-3859; AAA
Department of the Army (DA): A; Dod I&S Family Master Nsn - - -; ABA
Department of the Air Force (DF): F; 7; Substitute For 5310-00-804-3859; AAA
Department of the Air Force (DF): F; R; Refer To Approved For Faa Use; APPROVED FOR FAA USE
Department of the Air Force (DF): F; Dod I&S Family Master Nsn - - -; ABA
US Marine Corps (DM): M; 7; Substitute For 5310-00-804-3859; AAA
US Marine Corps (DM): M; Dod I&S Family Master Nsn - - -; ABA
Department of the Navy (DN): N; 7; Substitute For 5310-00-804-3859; AAA
Department of the Navy (DN): N; Dod I&S Family Master Nsn - - -; ABA
Defense Logistics Agency (DS): I; 7; Substitute For 5310-00-804-3859; AAA
Defense Logistics Agency (DS): I; Dod I&S Family Master Nsn - - -; ABA
US Coast Guard (GP): C; 7; Substitute For 5310-00-804-3859
Department of the Army (DA): A; 7; Substitute For 5310-00-804-3859; AAA
Department of the Army (DA): A; Dod I&S Family Master Nsn - - -; ABA
Department of the Air Force (DF): F; 7; Substitute For 5310-00-804-3859; AAA
Department of the Air Force (DF): F; R; Refer To Approved For Faa Use; APPROVED FOR FAA USE
Department of the Air Force (DF): F; Dod I&S Family Master Nsn - - -; ABA
US Marine Corps (DM): M; 7; Substitute For 5310-00-804-3859; AAA
US Marine Corps (DM): M; Dod I&S Family Master Nsn - - -; ABA
Department of the Navy (DN): N; 7; Substitute For 5310-00-804-3859; AAA
Department of the Navy (DN): N; Dod I&S Family Master Nsn - - -; ABA
Defense Logistics Agency (DS): I; 7; Substitute For 5310-00-804-3859; AAA
Defense Logistics Agency (DS): I; Dod I&S Family Master Nsn - - -; ABA
US Coast Guard (GP): C; 7; Substitute For 5310-00-804-3859

Army

Materiel Category and Inventory Manager:

T: Industrial Supplies (DLA/GSA Items)

Appropriation and Budget Activity:

2: Stock Fund Secondary Items

Management Inventory Segment:

2: Non-Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify items, which are not reparable.

Weapons System / End Item / Homogeneous Group:

BJ: Rotary Wing Aircraft
AH-64 Airframe

Accounting Requirements:

X: Expendable item.An item of Army property coded with an ARC of X in the AMDF. Expendable items require no formal accountability after issue from a stock record account.Commercial and fabricated items similar to items coded X in the AMDF are considered expendable items.

Air Force

Fund:

SF: Stock fund applicable to items managed for the Air Force by the respective Inventory Control Point

Budget:

9: 57X4921.070 - General Support DIV - Air Force decentralized managed expense items (ERRC XB3, XF3) with a unit cost of less than $250,000 that are requisitioned/procured at base (retail) level from DLA, GSA, Army, Navy, Depot Maintenance Service, Air Force Industrial Fund (AFMC), local manufacture and commercial vendors

Price Validation Code:

V: The current standard price has been validated.
The item has been analyzed in conjunction with the Zero Overpricing Program and is in the accepted price range.
The item was procured under open competition and under the competitive arena the price is considered fair and reasonable.
ZOP or Standard price challenges are permissible but must be supported by adequate justification.

Expendability Recoverability Repairability:

N: Expendable. Condemn at User. Stock Fund (except Munitions).

Navy

Cognizance:

9B: Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg

Special Material Content:

9: Non-Hazardous or Non-Sensitive Item

Marine Corps

Stores Account:

1: Stock Fund Account Item

Combat Essentiality:

5: Critical Repair Part to a Combat Essential End Item

Echelon Management:

B2

Material Identification:

B: Consumable Repair Parts

Operational Test:

: No Special Procedures

NATO Stock Numbers Related to 5310-00-934-9747

5310-14-558-7805 5310-14-548-8576 5310-14-396-5539 5310-14-257-8451 5310-14-556-3965 5310-14-469-0789 5310-14-042-4616 5310-14-402-4767 5310-99-209-1404 5310-17-102-9085 5310-26-300-4675 5310-14-040-4538 5310-14-401-1478 5310-14-543-7313 5310-14-494-1963 5310-14-042-1616 5310-17-109-0499 5310-17-104-9776

Freight Information 5310-00-934-9747

5310-00-934-9747 has freight characteristics managed by the Southwestern Power Administration.It has a National Motor Freight Classification (NMFC) of 093486. A Sub NMFC of Z. It has a NMFC Description of BOLTS,NUTS OR SCREWS, NOI (SUB 3). 5310-00-934-9747 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 48950 which rates the freight between FCL and LCL. 5310-00-934-9747 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 573 for ocean manifesting and military sealift. 5310-00-934-9747 is not classified as a special type of cargo when transported by water. 5310-00-934-9747 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.

Packaging Data 5310-00-934-9747

Responsible Activity
Packaging Data Source: Primary Inventory Control Activity (PICA); --

Item Pack Level (Unpackaged)

Item Size
Item Weight
Characteristics
Weight/Dimensions Category
Fragility
Item Preservation: --; --; Bare Metal Item; 2lb or less, one dimension 2" or less, other dimensions less than 24"; Above 110G; No Requirement

Unit Pack Level (Packaged)

Quantity per Pack
Unit Size
Unit Weight
Unit Cube
Preservation Method
Cleaning/Drying: 1; --; --; --; Physical Protection; Any Suitable Process

Preservation Material
Wrapping Material
Cushioning/Dunnage
Cushioning Thickness
Container
Special Marking: No Requirement; No Requirement; No Requirement; Not Applicable; Any Suitable Container; No special marking

Intermediate Pack Level

Quantity of Unit Packs
Container: --

Procurement History 5310-00-934-9747 1 Records

Subscribe
View Prices

Contract: Date; CAGE; Quantity; Net Price; Std Price
SPE5E118V1793: 13 Aug 2018; Subscribe; 649; Subscribe; Subscribe

Contracting Technical Data File (CTDF) 5310-00-934-9747 February 2021

Criticality and Quality

Critical Item Code:: X
Flight Safety:
Life Support:
Certified Samples:
Serialization:
First Article Test (FAT):
Certificate of Quality Compliance:
Production Lot Testing:
Special Testing:
Qualified Products List (QPL):

Commercial Properties

Government Furnished Material:
Government Furnished Tooling:
Government Furnished Property:
Price Evaluation Code:
Diminshing Manufacturing Sources:
Warranty:
Commerical Off The Shelf (COTS):
End Item Application:
Auctioning Candidate:
Source of Procurement:
Contract Option:

Restrictions

Boeing Rights Guard:
Export Controlled:
Controlled Technical Data Package (TDP):
Restricted Technical Data Package (TDP):
Contains Classified Material
Weapons System Indicator Code (WSIC):: F

Packaging Requirements

Packaging Determination Table:
Packaging Review Code:: N
Special Packaging Instruction Number (SPIN):
Special Packaging Instruction Number Revision:
Special Packaging Instruction Number Date:
Pallet Reference Number Required:

Subscribe
View CTDF

Subscribe to View CTDF Details...

Marketplace 5310-00-934-9747

Related Documents 5310-00-934-9747 5+ Documents (More...)

Restrictions 5310-00-934-9747

Import and Export 5310-00-934-9747

End Users 5310-00-934-9747

Approved Sources 5310-00-934-9747

Datasheet 5310-00-934-9747

Weapon Systems (WSDC) 5310-00-934-9747

DLA Procurement Analysis 5310-00-934-9747

Management Data 5310-00-934-9747

Army

Air Force

Navy

Marine Corps

NATO Stock Numbers Related to 5310-00-934-9747

Freight Information 5310-00-934-9747

Packaging Data 5310-00-934-9747

Item Pack Level (Unpackaged)

Unit Pack Level (Packaged)

Intermediate Pack Level

Procurement History 5310-00-934-9747 1 Records

Contracting Technical Data File (CTDF) 5310-00-934-9747 February 2021

Criticality and Quality

Commercial Properties

Restrictions

Packaging Requirements
