5310-00-882-0903
Double Hexagon Extended Washer Self-Locking Nut
5310008820903 008820903 42FLW1018
A nut having 12 drive points, 24 sides, and an integral washer which extends beyond the points or periphery. An integral feature is incorporated for locking on the threads of a mating member. View more Double Hexagon Extended Washer Self-Locking Nut
Managed by United States
NSN Created on 17 Nov 1967
Data Last Changed
November 2023
November 2023
NATO Update Count
28
28
NATO Data Quality
Marketplace 5310-00-882-0903
Need Help?
Request a Quotation from participating marketplace vendors
Request a Quotation from participating marketplace vendors
Updated Every Day 5310-00-882-0903 RQST NE
Updated Every Day 5310-00-882-0903 RQST
Updated Every Day 5310-00-882-0903 RQST NE
Related Documents 5310-00-882-0903 5+ Documents (More...)
Photo 1/2 NSN 5310-00-882-0903 (Identification) 2/2 - - 1.
United States (US) 4. 5310-00-882-0903 Marketplace Restrictions Approved Sources Datasheet Management
WASHER,DOUBLE HEXAGON 17 EA NS Request Quotation Updated Every Day 5310-00-882-0903 RQST NE Updated
United States (US) 4. 5310-00-882-0903 Marketplace Restrictions Approved Sources Datasheet Management
WASHER,DOUBLE HEXAGON 17 EA NS Request Quotation Updated Every Day 5310-00-882-0903 RQST NE Updated
Request a Quotation from participating marketplace vendors Request Subscribe to View Vendor Details... 42FLW1018
1018 NUT,SELF-LOCKING,EXTENDED WASHER 5 EA NS Request Quotation Subscribe to View Vendor Details... 42FLW1018
NUT,SELF-LOCKING,EXTENDED WASHER 99 EA NS Request Quotation Subscribe to View Vendor Details... 42FLW1018
1018 NUT,SELF-LOCKING,EXTENDED WASHER 5 EA NS Request Quotation Subscribe to View Vendor Details... 42FLW1018
NUT,SELF-LOCKING,EXTENDED WASHER 99 EA NS Request Quotation Subscribe to View Vendor Details... 42FLW1018
5310-01-407-8191Double Hexagon Extended Washer Self-Locking Nut5310014078191 014078191 9235574-01 42FLW1018
NUT,SELF-LOCKING,EXTENDED WASHER 99 EA NS Request Quotation Subscribe to View Vendor Details... 42FLW1018
https//www.nsnlookup.com /fsg-53/fsc-5310/us 5310-00-882-0903 5310008820903 008820903,42FLW1018 Account
NUT,SELF-LOCKING,EXTENDED WASHER 99 EA NS Request Quotation Subscribe to View Vendor Details... 42FLW1018
https//www.nsnlookup.com /fsg-53/fsc-5310/us 5310-00-882-0903 5310008820903 008820903,42FLW1018 Account
463-9227 5310-99-145-0138 5310-00-857-4987 5310-00-655-9863 5310-00-567-5341 5310-00-133-3671 5310-00-882-0903
463-9227 5310-99-145-0138 5310-00-857-4987 5310-00-655-9863 5310-00-567-5341 5310-00-133-3671 5310-00-882-0903
Restrictions 5310-00-882-0903
5310-00-882-0903 is a Double Hexagon Extended Washer Self-Locking Nut that is an aviation critical safety item or flight safety critical aircraft part. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. The precious metals content of this item is unknown.
Import and Export 5310-00-882-0903
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5310-00-882-0903
- US Coast Guard (C920)
- Effective Date:
- 1 Jun 2012
- US Air Force (FXGI)
- Effective Date:
- 1 Apr 2006
- Former MOE Rule:
- FXKZ
- NASA (G860)
- Effective Date:
- 1 Apr 1991
- US Navy (N9BZ)
- Effective Date:
- 1 Apr 2006
- Former MOE Rule:
- N9ZD
- Supplementary Collaborators:
- GTKE
- Poland (WP01)
- Effective Date:
- 1 Jul 2011
- Brazil (YA01)
- Effective Date:
- 1 May 2012
- Spain (YB01)
- Effective Date:
- 1 Apr 1991
- Singapore (YJ01)
- Effective Date:
- 1 Apr 1991
- Australia (ZA01)
- Effective Date:
- 1 Apr 1991
- Canada (ZC01)
- Effective Date:
- 1 Apr 1991
- New Zealand (ZE01)
- Effective Date:
- 1 Apr 1991
- Germany (ZG01)
- Effective Date:
- 1 Feb 2005
- Republic of Korea (ZH01)
- Effective Date:
- 1 Apr 1998
- United Kingdom (ZK01)
- Effective Date:
- 1 Apr 1991
- Netherlands (ZN01)
- Effective Date:
- 1 Apr 1991
- Portugal (ZP01)
- Effective Date:
- 1 Dec 2001
- Norway (ZT01)
- Effective Date:
- 1 Apr 1991
- Greece (ZU01)
- Effective Date:
- 1 Apr 2006
- Turkey (ZW01)
- Effective Date:
- 1 Nov 2005
Approved Sources 5310-00-882-0903
- Part Number
- Manufacturer
- Status
- 42FLW1018
- Manufacturer
- 56878 - Sps Technologies, Llc (Active)
- Primary Buy
- Primary Buy
- 42FLW1018
- D9182 - Zf Industrieantriebe Witten Gmbh (Active)
- Advisory Reference
- Advisory Reference
Datasheet 5310-00-882-0903
- Characteristic
- Specifications
- FIIG
- Specifications
- A021A0
- Hardness Rating [CQFM]
- 34.0 Rockwell C Minimum And 43.0 Rockwell C Maximum
- Material [MATT]
- Steel Comp 8630 Overall Or Steel Comp 4037 Overall Or Steel Comp 8740 Overall
- Nominal Thread Size [CQJX]
- 0.625 Inches
- Nut Style [ACTA]
- Double Hexagon
- Locking Feature [AAUM]
- Prevailing Torque All Metal Design
- Lubrication [ABAJ]
- Soluble Lubricant
- Material Document And Classification [MDCL]
- Ams 6280 Assn Std 1St Material Response Overall Or Ams 6300 Assn Std 2Nd Material Response Overall Or Ams 6322 Assn Std 3Rd Material Response Overall
- Overall Height [ABKW]
- 0.650 Inches Maximum
- Washer Outside Diameter [AAVX]
- 1.050 Inches Maximum
- Washer Thickness [ADEM]
- 0.084 Inches Minimum
- Width Across Flats [ASDB]
- 0.772 Inches Minimum And 0.783 Inches Maximum
- Surface Treatment Document And Classification [STDC]
- Qq-P-416,Ty 1,Cl 3 Fed Spec Single Treatment Response Overall
- Surface Treatment [SFTT]
- Cadmium Overall
- Temp Rating [AZKQ]
- 450.0 Deg Fahrenheit Nominal
- Thread Class [AAJD]
- 3B
- Thread Direction [AAJF]
- Right-Hand
- Thread Series [BZRR]
- Unjf
- Thread Quantity Per Inch [CMLP]
- 18
Weapon Systems (WSDC) 5310-00-882-0903
DLA Procurement Analysis 5310-00-882-0903
- Last Stock Position:
- 646 In Stock
- DLA Administrative Lead Time:
- Subscribe
- DLA Production Lead Time:
- Subscribe
Management Data 5310-00-882-0903
- Effective Date
- Organization
- Unit of Issue
- Unit Price
- Qty Unit Pack
- Unit of Issue
- Oct 2022
- US Coast Guard (GP)
- EA
- Subscribe
- 1
- EA
- Feb 2022
- Department of the Air Force (DF)
- EA
- Subscribe
- 1
- EA
- Dec 2021
- Defense Logistics Agency (DS)
- EA
- Subscribe
- 1
- EA
- Oct 2021
- Department of the Navy (DN)
- EA
- Subscribe
- EA
- Oct 2020
- Defense Logistics Agency (DS)
- EA
- Subscribe
- EA
- Oct 2019
- Department of the Air Force (DF)
- EA
- Subscribe
- EA
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
Similar Supply Items to 5310-00-882-0903
Freight Information 5310-00-882-0903
5310-00-882-0903 has freight characteristics managed by the Southwestern Power Administration.It has a National Motor Freight Classification (NMFC) of 093486. A Sub NMFC of Z. It has a NMFC Description of BOLTS,NUTS OR SCREWS, NOI (SUB 3). 5310-00-882-0903 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 48950 which rates the freight between FCL and LCL. 5310-00-882-0903 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 573 for ocean manifesting and military sealift. 5310-00-882-0903 is not classified as a special type of cargo when transported by water. 5310-00-882-0903 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 5310-00-882-0903
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- Bare Metal Item
- 2lb or less, one dimension 2" or less, other dimensions less than 24"
- Above 110G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- --
- --
- --
- Physical Protection
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- No Requirement
- No Requirement
- Not Applicable
- Any Suitable Container
- No special marking
- No Requirement
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- --
Procurement History 5310-00-882-0903 27 Records
- Contract
- Date
- CAGE
- Quantity
- Net Price
- Std Price
- CAGE
- SPE4A722PC006
- 21 Jun 2022
- Subscribe
- 13994
- Subscribe
- Subscribe
- Subscribe
- SPE4A722PB894
- 17 Jun 2022
- Subscribe
- 13997
- Subscribe
- Subscribe
- Subscribe
- SPE5EY19F3449
- 12 Dec 2018
- Subscribe
- 23868
- Subscribe
- Subscribe
- Subscribe
- SPE5EY19F2995
- 16 Nov 2018
- Subscribe
- 5659
- Subscribe
- Subscribe
- Subscribe
- SPE5EY14D05020442
- 06 Jun 2017
- Subscribe
- 20177
- Subscribe
- Subscribe
- Subscribe
- SPE5EY14D05020428
- 23 May 2017
- Subscribe
- 1610
- Subscribe
- Subscribe
- Subscribe
- SPE5EY14D05020383
- 28 Feb 2017
- Subscribe
- 1878
- Subscribe
- Subscribe
- Subscribe
- SPE5EY14D0502029003
- 08 Jul 2016
- Subscribe
- 14583
- Subscribe
- Subscribe
- Subscribe
- SPE5EY14D0502026603
- 01 Jun 2016
- Subscribe
- 8866
- Subscribe
- Subscribe
- Subscribe
- SPE5EY14D05020230
- 25 Feb 2016
- Subscribe
- 1332
- Subscribe
- Subscribe
- Subscribe
- SPE5EY14D0502023103
- 25 Feb 2016
- Subscribe
- 4412
- Subscribe
- Subscribe
- Subscribe
- SPE5EY14D05020206
- 11 Dec 2015
- Subscribe
- 2000
- Subscribe
- Subscribe
- Subscribe
- SPE5EY14D05020175
- 09 Oct 2015
- Subscribe
- 2105
- Subscribe
- Subscribe
- Subscribe
- SPE5EY14D05020164
- 24 Sep 2015
- Subscribe
- 1508
- Subscribe
- Subscribe
- Subscribe
- SPE5EY14D05020163
- 24 Sep 2015
- Subscribe
- 452
- Subscribe
- Subscribe
- Subscribe
- SPE5EY14D0502013702
- 21 Jul 2015
- Subscribe
- 15000
- Subscribe
- Subscribe
- Subscribe
- SPE5EY14D0502010801
- 14 May 2015
- Subscribe
- 168
- Subscribe
- Subscribe
- Subscribe
- SPE5EY14D0502010901
- 14 May 2015
- Subscribe
- 1719
- Subscribe
- Subscribe
- Subscribe
- SPE5EY14D0502010401
- 14 May 2015
- Subscribe
- 1512
- Subscribe
- Subscribe
- Subscribe
- SPE5EY14D0502010301
- 01 May 2015
- Subscribe
- 971
- Subscribe
- Subscribe
- Subscribe
- SPE5EY14D0502010501
- 01 May 2015
- Subscribe
- 3907
- Subscribe
- Subscribe
- Subscribe
- SPE5EY14D0502009901
- 21 Apr 2015
- Subscribe
- 7174
- Subscribe
- Subscribe
- Subscribe
- SPE5EY14D0502008302
- 20 Mar 2015
- Subscribe
- 14694
- Subscribe
- Subscribe
- Subscribe
- SPE5EY14D0502008202
- 20 Mar 2015
- Subscribe
- 14063
- Subscribe
- Subscribe
- Subscribe
- SPE5EC14M0130
- 18 Feb 2014
- Subscribe
- 19299
- Subscribe
- Subscribe
- Subscribe
- SPE5EC14M0043
- 09 Dec 2013
- Subscribe
- 16000
- Subscribe
- Subscribe
- Subscribe
- SPM50003D9512030601
- 20 Sep 2013
- Subscribe
- 16000
- Subscribe
- Subscribe
- Subscribe
Contracting Technical Data File (CTDF) 5310-00-882-0903 February 2021
Criticality and Quality
- Critical Item Code:
- X
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- F
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- Y
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
