5310-00-857-4987
Double Hexagon Extended Washer Self-Locking Nut
5310008574987 008574987 395034 FN22-428 DSR1196-2
A nut having 12 drive points, 24 sides, and an integral washer which extends beyond the points or periphery. An integral feature is incorporated for locking on the threads of a mating member. View more Double Hexagon Extended Washer Self-Locking Nut
November 2023
33
Marketplace 5310-00-857-4987
Request a Quotation from participating marketplace vendors
Updated Every Day Updated Every Day
Updated Every Day Related Documents 5310-00-857-4987 5+ Documents (More...)
Photo 1/2 NSN 5310-00-857-4987 (Identification) 2/2 - - 1.
United States (US) 4. 5310-00-857-4987 Marketplace Restrictions Approved Sources Datasheet Management
FN22-428 NUT,SELF-LOCKING,EXTENDED WASHER 6 EA NS Request Quotation Subscribe to View Vendor Details.
FN22-428 NUT,SELF-LOCKING,EXTENDED WASHER 6 EA NS Request Quotation Subscribe to View Vendor Details.
FN22-428 NUT,SELF-LOCKING,EXTENDED WASHER 6 EA NS Request Quotation Subscribe to View Vendor Details
. https//www.nsnlookup.com /fsg-53/fsc-5310/us 5310-00-857-4987 5310008574987 008574987,395034,FN22-428
www.nsnlookup.com /fsg-48/fsc-4820/nz 4820-98-201 https//www.nsnlookup.com /fsg-53/fsc-5310/us 5310-00-857-4987
5310008574987 008574987,395034,FN22-428 Friction Catch Stud Receptacle 5340014927780 395034 https
Request a Quotation from participating marketplace vendors Request Subscribe to View Vendor Details... 395034
www.nsnlookup.com /fsg-53/fsc-5340/us 5340-01-492-7780 Friction Catch Stud Receptacle 5340014927780 395034
Restrictions 5310-00-857-4987
5310-00-857-4987 is a Double Hexagon Extended Washer Self-Locking Nut that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
Import and Export 5310-00-857-4987
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5310-00-857-4987
- US Army (A919)
- Effective Date:
- 1 Jun 2005
- Former MOE Rule:
- A187
- Supplementary Receivers:
- CT
- US Air Force (FXGI)
- Effective Date:
- 1 Jun 2005
- Former MOE Rule:
- FXKZ
- US Navy (N9BZ)
- Effective Date:
- 1 Jun 2005
- Former MOE Rule:
- N9ZD
- Supplementary Collaborators:
- GT
- Brazil (YA01)
- Effective Date:
- 1 Oct 2000
- Spain (YB01)
- Effective Date:
- 1 Apr 1991
- Israel (YD01)
- Effective Date:
- 1 Aug 2016
- Singapore (YJ01)
- Effective Date:
- 1 Nov 2000
- Belgium (ZB01)
- Effective Date:
- 1 Oct 2013
- New Zealand (ZE01)
- Effective Date:
- 1 Apr 1991
- Republic of Korea (ZH01)
- Effective Date:
- 1 Apr 2002
- Italy (ZR01)
- Effective Date:
- 1 Apr 1991
Approved Sources 5310-00-857-4987
- Part Number
- Manufacturer
- Status
- 395034
- Manufacturer
- 77445 - Rtx Corporation (Active)
- Source Control
- Source Control
- 395034
- 56878 - Sps Technologies, Llc (Active)
- Primary Buy
- Primary Buy
- FN22-428
- 56878 - Sps Technologies, Llc (Active)
- Secondary Buy
- Secondary Buy
- DSR1196-2
- 56878 - Sps Technologies, Llc (Active)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 5310-00-857-4987
- Characteristic
- Specifications
- FIIG
- Specifications
- A021A0
- Material [MATT]
- Steel Overall
- Nominal Thread Size [CQJX]
- 0.250 Inches
- Nut Style [ACTA]
- Double Hexagon
- Locking Feature [AAUM]
- Prevailing Torque All Metal Design
- Overall Height [ABKW]
- 0.230 Inches Nominal
- Washer Outside Diameter [AAVX]
- 0.438 Inches Nominal
- Washer Thickness [ADEM]
- 0.030 Inches Nominal
- Width Across Flats [ASDB]
- 0.304 Inches Minimum And 0.313 Inches Maximum
- Surface Treatment [SFTT]
- Cadmium Overall
- Thread Class [AAJD]
- 3B
- Thread Direction [AAJF]
- Right-Hand
- Thread Series [BZRR]
- Unf
- Thread Quantity Per Inch [CMLP]
- 28
Weapon Systems (WSDC) 5310-00-857-4987
DLA Procurement Analysis 5310-00-857-4987
- Last Stock Position:
- 1196 In Stock
- DLA Administrative Lead Time:
- Subscribe
- DLA Production Lead Time:
- Subscribe
Management Data 5310-00-857-4987
Army
- Materiel Category and Inventory Manager:
- T
- Industrial Supplies (DLA/GSA Items)
- Appropriation and Budget Activity:
- 2
- Stock Fund Secondary Items
- Management Inventory Segment:
- 2
- Non-Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify items, which are not reparable.
- Weapons System / End Item / Homogeneous Group:
- 00
- DLA/GSA Material
DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item
- Accounting Requirements:
- X
- Expendable item.An item of Army property coded with an ARC of X in the AMDF. Expendable items require no formal accountability after issue from a stock record account.Commercial and fabricated items similar to items coded X in the AMDF are considered expendable items.
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
Similar Supply Items to 5310-00-857-4987
Freight Information 5310-00-857-4987
5310-00-857-4987 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 093486. A Sub NMFC of Z. It has a NMFC Description of BOLTS,NUTS OR SCREWS, NOI (SUB 3). 5310-00-857-4987 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 48950 which rates the freight between FCL and LCL. 5310-00-857-4987 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 573 for ocean manifesting and military sealift. 5310-00-857-4987 is not classified as a special type of cargo when transported by water. 5310-00-857-4987 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 5310-00-857-4987
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- Bare Metal Item
- 2lb or less, one dimension 2" or less, other dimensions less than 24"
- Above 110G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- --
- --
- --
- Physical Protection
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- No Requirement
- No Requirement
- Not Applicable
- Any Suitable Container
- No special marking
- No Requirement
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- --
Procurement History 5310-00-857-4987 2 Records
Contracting Technical Data File (CTDF) 5310-00-857-4987 February 2021
Criticality and Quality
- Critical Item Code:
- X
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- H
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- N
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
