5310-00-814-0672

Hexagon Self-Locking Nut

5310008140672 008140672 MIL-DTL-45913/3 TIP00017 L31163 M45913/3-6FG8C BBZ4288 950374-9 560545 MS51943-36 71143-36 456720131110 5310PL0773342

A nut having a flat bottom and 6 sides. An integral feature is incorporated for locking on the threads of a mating member. Excludes NUT (1), SELF-LOCKING, CAP. View more Hexagon Self-Locking Nut

Managed by United States

NSN Created on 5 Apr 1968

Data Last Changed
October 2025

NATO Update Count
54

NATO Data Quality

5310-00-814-0672 NUT,SELF-LOCKING,HEXAGON 5310008140672 008140672 1/2 — 5310-00-814-0672 Photo 1/2

ACTA Style A12 for 5310-00-814-0672 2/2 — NSN 5310-00-814-0672 (Identification) 2/2

Marketplace 5310-00-814-0672

Need Help?
Request a Quotation from participating marketplace vendors

Subscribe to View Vendor Details...

5310-00-732-0558 NUT,SELF-LOCKING,HEXAGON 100 HD NS

MS51943-36 NUT,SELF-LOCKING,HEXAGON 200 HD NS

Subscribe to View Vendor Details...

MIL-DTL-45913/3 NUT,SELF-LOCKING,HEXAGON 34 HD NS

Subscribe to View Vendor Details...

M45913/3-6FG8C NUT 330 HD NS

MS51943-36 NUT 7 HD NS

Subscribe to View Vendor Details...

950374-9 NUT,SELF-LOCKING,HEXAGON RQST NS

Subscribe to View Vendor Details...

5310-00-814-0672 NUT, SELF-LOCKING 280 HD NS

Subscribe to View Vendor Details...

MS51943-36 NUT,SELF-LOCKING,HEXAGON 1651 HD NS

Subscribe to View Vendor Details...

M45913/3-6FG8C NUT,SELF-LOCKING,HEXAGON 44200 HD NS

Subscribe to View Vendor Details...

BBZ4288 NUT,SELF-LOCKING,HEXAGON 603 HD NS

71143-36 NUT,SELF-LOCKING,HEXAGON 501 HD NS

L31163 NUT,SELF-LOCKING,HEXAGON 502 HD NS

MS51943-36 NUT,SELF-LOCKING,HEXAGON 100 HD NS

950374-9 NUT,SELF-LOCKING,HEXAGON 101 HD NS

MIL-DTL-459133 NUT,SELF-LOCKING,HEXAGON 102 HD NS

M459123-6FG8C NUT,SELF-LOCKING,HEXAGON 101 HD NS

TIP00017 NUT,SELF-LOCKING,HEXAGON 501 HD NS

Subscribe to View Vendor Details...

008140672.5310 NUT,SELF-LOCKING,HEXAGON 47 HD NS

1549159 NUT,SELF-LOCKING,HEXAGON 280 HD NS

Updated Every Day

560545 RQST NE

Updated Every Day

5310-00-814-0672 RQST NE

Updated Every Day

5310-00-814-0672 RQST

Updated Every Day

5310-00-814-0672 RQST NE

Restrictions 5310-00-814-0672

5310-00-814-0672 is a Hexagon Self-Locking Nut that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. The precious metals content of this item is unknown.

Import and Export 5310-00-814-0672

Schedule B: Subscribe to View Schedule B
HTS Code: Subscribe to View HTS Code

End Users 5310-00-814-0672

US Army (A919)
Effective Date:: 1 Apr 2006
Former MOE Rule:: A187
Supplementary Receivers:: AZBFBD; AMC 1 AMSC G IMC Z IMCACTY CD

US Air Force (FXGI)
Effective Date:: 1 Apr 2006
Former MOE Rule:: FXKZ; AMC 1 AMSC G IMC Z IMCACTY SX

US Marine Corps (MC47)
Effective Date:: 1 Apr 2006
Former MOE Rule:: MC10; AMC 1 AMSC G IMC Z IMCACTY PA

US Navy (N9BZ)
Effective Date:: 1 Apr 2006
Former MOE Rule:: N9ZD
Supplementary Collaborators:: GTHD; AMC 1 AMSC G IMC Z IMCACTY GH

Austria (WB01)
Effective Date:: 1 Feb 2005

Hungary (WH01)
Effective Date:: 1 Sep 2013

Slovenia (WL01)
Effective Date:: 1 Dec 2014

Poland (WP01)
Effective Date:: 1 Jun 2005

Brazil (YA01)
Effective Date:: 1 Mar 2001

Spain (YB01)
Effective Date:: 1 Apr 1991

Israel (YD01)
Effective Date:: 1 Aug 2016

Morocco (YP01)
Effective Date:: 1 Oct 2016

Thailand (YY01)
Effective Date:: 1 Feb 2015

Australia (ZA01)
Effective Date:: 1 Jun 1996

Belgium (ZB01)
Effective Date:: 1 Apr 1991

Canada (ZC01)
Effective Date:: 1 Apr 1991

New Zealand (ZE01)
Effective Date:: 1 Apr 1991

France (ZF01)
Effective Date:: 1 May 2015

Republic of Korea (ZH01)
Effective Date:: 1 Aug 1995

Portugal (ZP01)
Effective Date:: 1 Apr 1991

Denmark (ZS01)
Effective Date:: 1 May 2007

Greece (ZU01)
Effective Date:: 1 Apr 1991

Turkey (ZW01)
Effective Date:: 1 Nov 1998

Approved Sources 5310-00-814-0672

Part Number
Manufacturer
Status
M45913/3-6FG8C: 96906 - Military Standards (Active); Definitive Standard; RNCC 2 RNVC 2 DAC E
MIL-DTL-45913/3: 81349 - Military Specifications (Active); Incomplete Standard; RNCC 4 RNVC 1 DAC E
TIP00017: 97403 - Cecom Lr Center (Active); Incomplete Secondary Reference; RNCC 5 RNVC 1 DAC 3
L31163: 10988 - Cnh Industrial America Llc (Active); Incomplete Secondary Reference; RNCC 5 RNVC 1 DAC 2
BBZ4288: F5316 - Giat Industries (Centre De Tarbes) (Active); Secondary Buy; RNCC 5 RNVC 2 DAC 6
950374-9: A591N - Gkn Aerospace Sweden Ab (Active); Secondary Buy; RNCC 5 RNVC 2 DAC 6
MS51943-36: 96906 - Military Standards (Active); Canceled/Obsolete; RNCC 5 RNVC 9 DAC E
71143-36: 95097 - Little Giant Crane And Shovel Inc (Obsolete); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 5
950374-9: S3956 - Gkn Aerospace Sweden Ab (Replaced); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 6
456720131110: 0000V - Ncb Hungary (Honvedsegi Egyseges (Active); NATO Reference; RNCC 6 RNVC 9 DAC 9
5310PL0773342: 9009H - Jednolity Indeks Materialowy - (Active); NATO Reference; RNCC 6 RNVC 9 DAC 9
5310008140672: A00AM - E.C.A Etablissement Central Des (Active); NATO Reference; RNCC 6 RNVC 9 DAC 9
560545: 7X677 - General Motors Llc (Active); Transferred; RNCC E RNVC 8 DAC 5

Datasheet 5310-00-814-0672

Characteristic
Specifications
FIIG: A021A0
Bearing Surface Type [CRTM]: Chamfered
End Item Identification [AGAV]: Mrap - Cougar Cat1 A2
Material [MATT]: Steel Overall
Nominal Thread Size [CQJX]: 0.375 Inches
Nut Height [ADEA]: 0.469 Inches Maximum
Nut Style [ACTA]: Hexagon
Locking Feature [AAUM]: Prevailing Torque With Nonmetallic Insert
Width Across Flats [ASDB]: 0.551 Inches Minimum And 0.564 Inches Maximum
Surface Treatment Document And Classification [STDC]: Qq-P-416,Ty 2,Cl 3 Fed Spec Single Treatment Response Overall Except Insert
Surface Treatment [SFTT]: Cadmium Overall Except Insert
Temp Rating [AZKQ]: 250.0 Deg Fahrenheit Nominal
Thread Class [AAJD]: 3B
Thread Direction [AAJF]: Right-Hand
Thread Series [BZRR]: Unf
Thread Quantity Per Inch [CMLP]: 24

Weapon Systems (WSDC) 5310-00-814-0672

Subscribe
View WSDC

Subscribe to View Weapon System Codes...

Subscribe
View Data

DLA Procurement Analysis 5310-00-814-0672

Last Stock Position:: 766800 In Stock
DLA Administrative Lead Time:: Subscribe
DLA Production Lead Time:: Subscribe

Subscribe to View DLA Inventory and Forecast...

Management Data 5310-00-814-0672

Subscribe
View Prices

Effective Date: Organization; Unit of Issue; Unit Price; Qty Unit Pack
Oct 2022: US Marine Corps (DM); HD; Subscribe; 1
Oct 2021: Defense Logistics Agency (DS); HD; Subscribe; 1
Oct 2020: Defense Logistics Agency (DS); HD; Subscribe; 1
Oct 2019: Department of the Air Force (DF); HD; Subscribe; 1

Army

Materiel Category and Inventory Manager:

T: Industrial Supplies (DLA/GSA Items)

Appropriation and Budget Activity:

2: Stock Fund Secondary Items

Management Inventory Segment:

2: Non-Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify items, which are not reparable.

Weapons System / End Item / Homogeneous Group:

00: DLA/GSA Material
DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item

Accounting Requirements:

X: Expendable item.An item of Army property coded with an ARC of X in the AMDF. Expendable items require no formal accountability after issue from a stock record account.Commercial and fabricated items similar to items coded X in the AMDF are considered expendable items.

Navy

Cognizance:

9B: Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg

Marine Corps

Stores Account:

1: Stock Fund Account Item

Combat Essentiality:

5: Critical Repair Part to a Combat Essential End Item

Echelon Management:

B2

Material Identification:

B: Consumable Repair Parts

Operational Test:

: No Special Procedures

Physical Category:

1: Bin

Similar Supply Items to 5310-00-814-0672

Freight Information 5310-00-814-0672

5310-00-814-0672 has freight characteristics managed by the Southwestern Power Administration.It has a National Motor Freight Classification (NMFC) of 093486. A Sub NMFC of Z. It has a NMFC Description of BOLTS,NUTS OR SCREWS, NOI (SUB 3). 5310-00-814-0672 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 48950 which rates the freight between FCL and LCL. 5310-00-814-0672 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 573 for ocean manifesting and military sealift. 5310-00-814-0672 is not classified as a special type of cargo when transported by water. 5310-00-814-0672 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.

Packaging Data 5310-00-814-0672

Responsible Activity
Packaging Data Source: Primary Inventory Control Activity (PICA); --

Item Pack Level (Unpackaged)

Item Size
Item Weight
Characteristics
Weight/Dimensions Category
Fragility
Item Preservation: --; --; Bare Metal Item; 2lb or less, one dimension 2" or less, other dimensions less than 24"; Above 110G; No Requirement

Unit Pack Level (Packaged)

Quantity per Pack
Unit Size
Unit Weight
Unit Cube
Preservation Method
Cleaning/Drying: 1; --; --; --; Physical Protection; Any Suitable Process

Preservation Material
Wrapping Material
Cushioning/Dunnage
Cushioning Thickness
Container
Special Marking: No Requirement; No Requirement; No Requirement; Not Applicable; PPP-B-566, PPP-B-676, or ASTM-D5118, Folding, Setup or Fiberboard Box; No special marking

Intermediate Pack Level

Quantity of Unit Packs
Container: --

Contracting Technical Data File (CTDF) 5310-00-814-0672 February 2021

Criticality and Quality

Critical Item Code:
Flight Safety:
Life Support:
Certified Samples:
Serialization:
First Article Test (FAT):
Certificate of Quality Compliance:
Production Lot Testing:
Special Testing:
Qualified Products List (QPL):

Commercial Properties

Government Furnished Material:
Government Furnished Tooling:
Government Furnished Property:
Price Evaluation Code:
Diminshing Manufacturing Sources:
Warranty:
Commerical Off The Shelf (COTS):
End Item Application:
Auctioning Candidate:
Source of Procurement:
Contract Option:

Restrictions

Boeing Rights Guard:
Export Controlled:
Controlled Technical Data Package (TDP):
Restricted Technical Data Package (TDP):
Contains Classified Material
Weapons System Indicator Code (WSIC):: F

Packaging Requirements

Packaging Determination Table:
Packaging Review Code:: N
Special Packaging Instruction Number (SPIN):
Special Packaging Instruction Number Revision:
Special Packaging Instruction Number Date:
Pallet Reference Number Required:
