5310-00-790-8116
Round Plain Nut
5310007908116 007908116 1-100-034-01
A nut, circular in shape, which may have wrenching facilities such as flats, holes, protrusions, slots or splines in or on the periphery or in the face opposite the bearing surface. For items having a thickness (or height) exceeding two times the outside diameter, use POST, ELECTRICAL-MECHANICAL EQUIPMENT. See also NUT (1), PLAIN, KNURLED. (When height or thickness and/or outside diameter is designated as a tolerance dimension, the maximum dimension will be used to determine compliance.) View more Round Plain Nut
May 2023
28
Marketplace 5310-00-790-8116
Request a Quotation from participating marketplace vendors
Related Documents 5310-00-790-8116 5+ Documents (More...)
United States (US) 4. 5310-00-790-8116 Marketplace Restrictions Approved Sources Datasheet Management
,ROUND 2 EA NS Request Quotation Updated Every Day 5310-00-790-8116 RQST NE Updated Every Day 5310-00
Restrictions 5310-00-790-8116
5310-00-790-8116 is a Round Plain Nut that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item contains Silver.
Import and Export 5310-00-790-8116
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5310-00-790-8116
- US Army (A919)
- Effective Date:
- 1 Jun 2005
- Former MOE Rule:
- A187
- Supplementary Receivers:
- BDCT
- US Air Force (FXGI)
- Effective Date:
- 1 Jun 2005
- Former MOE Rule:
- FXKZ
- US Navy (N9BZ)
- Effective Date:
- 1 Jul 2016
- Former MOE Rule:
- N9ZD
- Supplementary Collaborators:
- GG
- Brazil (YA01)
- Effective Date:
- 1 Oct 2000
- Spain (YB01)
- Effective Date:
- 1 Apr 1991
- Columbia (YC01)
- Effective Date:
- 1 Jul 2015
- Israel (YD01)
- Effective Date:
- 1 Aug 2016
- Australia (ZA01)
- Effective Date:
- 1 Apr 1991
- Canada (ZC01)
- Effective Date:
- 1 Apr 1991
- New Zealand (ZE01)
- Effective Date:
- 1 Apr 1991
- Germany (ZG01)
- Effective Date:
- 1 Apr 1991
- Republic of Korea (ZH01)
- Effective Date:
- 1 Apr 1991
- Greece (ZU01)
- Effective Date:
- 1 Aug 1995
- Turkey (ZW01)
- Effective Date:
- 1 Nov 2005
Approved Sources 5310-00-790-8116
- Part Number
- Manufacturer
- Status
- 1-100-034-01
- Manufacturer
- 99193 - Honeywell International Inc. (Active)
- Primary Buy
- Primary Buy
- 1-100-034-01
- 9A148 - Norcatec Llc (Active)
- Secondary Buy
- Secondary Buy
- 1-100-034-01
- 5V179 - Md3 Industries, Limited (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- 1-100-034-01
- 78U39 - Ozark Aeroworks Llc (Active)
- Advisory Reference
- Advisory Reference
Datasheet 5310-00-790-8116
- Characteristic
- Specifications
- FIIG
- Specifications
- A021A0
- Drive Point Depth [ABQU]
- 0.113 Inches Minimum And 0.118 Inches Maximum
- Drive Point Quantity [ADBM]
- 8
- Drive Point Width [ADBH]
- 0.380 Nominal Inches
- Hardness Rating [CQFM]
- 26.0 Rockwell C Minimum And 32.0 Rockwell C Maximum
- Material [MATT]
- Steel Comp 4140 Overall
- Nominal Thread Size [CQJX]
- 1.967 Inches
- Nut Diameter [ACTD]
- 2.495 Inches Nominal
- Nut Style [ACTA]
- Round
- Nut Thickness [ADBG]
- 0.260 Inches Nominal
- Material Document And Classification [MDCL]
- Ams 6382 Assn Std Single Material Response Overall
- Precious Material [PRMT]
- Silver
- Surface Treatment Document And Classification [STDC]
- Ams 2410 Assn Std Single Treatment Response Overall
- Surface Treatment [SFTT]
- Silver Overall
- Thread Direction [AAJF]
- Right-Hand
- Thread Series [BZRR]
- Uns
- Thread Pitch Diameters [AAJE]
- +1.9309/+1.9354 Inches
- Thread Quantity Per Inch [CMLP]
- 18
Weapon Systems (WSDC) 5310-00-790-8116
DLA Procurement Analysis 5310-00-790-8116
- Last Stock Position:
- 4 In Stock
- DLA Administrative Lead Time:
- Subscribe
- DLA Production Lead Time:
- Subscribe
Management Data 5310-00-790-8116
- Effective Date
- Organization
- Unit of Issue
- Unit Price
- Qty Unit Pack
- Unit of Issue
- Oct 2022
- Defense Logistics Agency (DS)
- EA
- Subscribe
- 1
- EA
- Oct 2021
- Department of the Air Force (DF)
- EA
- Subscribe
- 1
- EA
- Oct 2020
- Department of the Air Force (DF)
- EA
- Subscribe
- 1
- EA
- Oct 2019
- Department of the Air Force (DF)
- EA
- Subscribe
- 1
- EA
- MOE
- USC
- Code
- Statement
- Order of Use
- Jump To Code
- Qty Per Assy
- UOM
- Technical Document
- Quantative Expression
- Code
- Department of the Air Force (DF)
- F
- R
- Refer To Aft095req
- AFT095REQ
- R
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
Similar Supply Items to 5310-00-790-8116
Freight Information 5310-00-790-8116
5310-00-790-8116 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 093486. A Sub NMFC of Z. It has a NMFC Description of BOLTS,NUTS OR SCREWS, NOI (SUB 3). 5310-00-790-8116 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 48950 which rates the freight between FCL and LCL. 5310-00-790-8116 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 573 for ocean manifesting and military sealift. 5310-00-790-8116 is not classified as a special type of cargo when transported by water. 5310-00-790-8116 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 5310-00-790-8116
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- Bare Metal Item
- 2lb or less, one dimension 2" or less, other dimensions less than 24"
- Above 110G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- --
- --
- --
- --
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- No Requirement
- --
- --
- --
- No special marking
- No Requirement
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- ASTM - D5118, Fiberboard Box
Procurement History 5310-00-790-8116 5 Records
- Contract
- Date
- CAGE
- Quantity
- Net Price
- Std Price
- CAGE
- SPE4A122P0215
- 28 Oct 2021
- Subscribe
- 13
- Subscribe
- Subscribe
- Subscribe
- SPE4A121P0947
- 10 May 2021
- Subscribe
- 13
- Subscribe
- Subscribe
- Subscribe
- SPM4A111G001026P9
- 10 Sep 2015
- Subscribe
- 86
- Subscribe
- Subscribe
- Subscribe
- SPM4A111G001019P1
- 08 Apr 2015
- Subscribe
- 131
- Subscribe
- Subscribe
- Subscribe
- SPM4A111G001009S901
- 17 Jun 2013
- Subscribe
- 115
- Subscribe
- Subscribe
- Subscribe
Contracting Technical Data File (CTDF) 5310-00-790-8116 October 2021
Criticality and Quality
- Critical Item Code:
- X
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- T
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- N
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
