5310-00-779-6769
Plate Self-Locking Nut
5310007796769 007796769 RF200C5 NAS686C5 NAS1031C5 MS21060-5 LHTA521-2860-054 T65C524C 13705-054
A nut with a flanged base of varied shapes which may be plain or mounted by rivets, bolts, welding or integral prongs. An integral feature is incorporated for locking on the threads of a mating member. View more Plate Self-Locking Nut
Managed by United States
NSN Created on 1 Jan 1960
Data Last Changed
November 2023
November 2023
NATO Update Count
39
39
NATO Data Quality
Marketplace 5310-00-779-6769
Need Help?
Request a Quotation from participating marketplace vendors
Request a Quotation from participating marketplace vendors
Related Documents 5310-00-779-6769 5+ Documents (More...)
RF200C5 NAS686C5 NAS1031C5 MS21060-5 LHTA521-2860-054 T65C524C 13705-054 A nut with a flanged base of
NAS1031C5 NUT,SELF-LOCKING,PLATE 178 EA NS Request Quotation MS21060-5 NUT,SELF-LOCKING,PLATE 9 EA NS
of Photo 1/3 NSN 5310-00-779-6769 (Identification) 2/3 NSN 5310-00-779-6769 (Identification) 3/3 - NAS1031C5
NAS1031C5 NUT,SELF-LOCKING,PLATE 178 EA NS Request Quotation MS21060-5 NUT,SELF-LOCKING,PLATE 9 EA NS
of Photo 1/3 NSN 5310-00-779-6769 (Identification) 2/3 NSN 5310-00-779-6769 (Identification) 3/3 - NAS1031C5
day Upgrade your Account Upgrade 5310-99-606-5425Plate Self Locking Nut5310996065425 996065425 LHTA521-2860-054
5310-99-606-5425 Plate Self Locking Nut 5310996065425 Canceled/Obsolete RNCC 5 RNVC 9 DAC E LHTA521-2860-054
Plate Self-Locking Nut 5310007796769,RF200C5 00-779-6769Plate Self-Locking Nut5310007796769 007796769
5310-99-606-5425 Plate Self Locking Nut 5310996065425 Canceled/Obsolete RNCC 5 RNVC 9 DAC E LHTA521-2860-054
Plate Self-Locking Nut 5310007796769,RF200C5 00-779-6769Plate Self-Locking Nut5310007796769 007796769
MS21060-5 NUT,SELF-LOCKING,PLATE 99 EA NS Request Quotation Subscribe to View Vendor Details...
MS21060-5 NUT,SELF-LOCKING,PLATE 32 EA NS Request Quotation Subscribe to View Vendor Details...
MS21060-5 NUT,SELF-LOCKING,PLATE 4 EA NS Request Quotation Subscribe to View Vendor Details...
MS21060-5 NUT,SELF-LOCKING,PLATE 32 EA NS Request Quotation Subscribe to View Vendor Details...
MS21060-5 NUT,SELF-LOCKING,PLATE 4 EA NS Request Quotation Subscribe to View Vendor Details...
vendors Request Updated Every Day 5310-00-064-1064 https//www.nsnlookup.com /fsg-53/fsc-5310/us 5310-00-779-6769
Plate Self-Locking Nut 5310007796769,RF200C5 Request Quotation Subscribe to View Vendor Details
Per AssyUOMTechnical DocumentQuantative ExpressionDepartment of the Navy (DN)NLSuperseded By 5310-00-779-6769
Plate Self-Locking Nut 5310007796769,RF200C5 Request Quotation Subscribe to View Vendor Details
Per AssyUOMTechnical DocumentQuantative ExpressionDepartment of the Navy (DN)NLSuperseded By 5310-00-779-6769
149-7033 5310-00-778-9283 5310-01-473-4829 5310-00-691-0900 5310-00-779-6594 5310-01-345-1813 5310-00-779-6769
Restrictions 5310-00-779-6769
5310-00-779-6769 is a Plate Self-Locking Nut that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item contains Silver.
Import and Export 5310-00-779-6769
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5310-00-779-6769
- US Coast Guard (C918)
- Effective Date:
- 1 Apr 2006
- Former MOE Rule:
- C004
- US Air Force (FXGI)
- Effective Date:
- 1 Apr 2006
- Former MOE Rule:
- FXKZ
- US Navy (N9BZ)
- Effective Date:
- 1 Apr 2006
- Former MOE Rule:
- N9ZD
- Supplementary Collaborators:
- GTKE
- Poland (WP01)
- Effective Date:
- 1 Jul 2011
- Australia (ZA01)
- Effective Date:
- 1 Mar 1994
- Canada (ZC01)
- Effective Date:
- 1 Oct 2016
- Republic of Korea (ZH01)
- Effective Date:
- 1 Apr 1991
- Denmark (ZS01)
- Effective Date:
- 1 Nov 2016
- NATO Maintenance and Supply Agency (ZX01)
- Effective Date:
- 1 Oct 2016
Approved Sources 5310-00-779-6769
- Part Number
- Manufacturer
- Status
- MS21060-5
- Manufacturer
- 80205 - National Aerospace Standards (Active)
- Primary Buy
- Primary Buy
- RF200C5
- 52828 - Republic Fastener Mfg. Corp. (Active)
- Incomplete Secondary Reference
- Incomplete Secondary Reference
- 13705-054
- 80539 - Sps Technologies, Llc (Active)
- Incomplete Secondary Reference
- Incomplete Secondary Reference
- LHTA521-2860-054
- 019L2 - Esna, Llc (Active)
- Secondary Buy
- Secondary Buy
- T65C524C
- 11815 - Sps Technologies, Llc (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- 13705-054
- 56878 - Sps Technologies, Llc (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- MS21060-5
- 96906 - Military Standards (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- LHTA521-2860-054
- 72962 - Harvard Industries Inc (Replaced)
- Canceled/Obsolete
- Canceled/Obsolete
- NAS686C5
- 80205 - National Aerospace Standards (Active)
- Advisory Reference
- Advisory Reference
- NAS1031C5
- 80205 - National Aerospace Standards (Active)
- Advisory Reference
- Advisory Reference
Datasheet 5310-00-779-6769
- Characteristic
- Specifications
- FIIG
- Specifications
- A021A0
- Center To Center Distance Between Mounting Holes Along Length [ADFY]
- 0.998 Inches Minimum And 1.002 Inches Maximum
- Distance From Aperture Center To Mounting Hole Center [ADFW]
- 0.495 Inches Minimum And 0.505 Inches Maximum
- Features Provided [CBBL]
- Floating Nut
- Hardness Rating [CQFM]
- 49.0 Rockwell C Maximum
- Material [MATT]
- Iron Alloy 660 Overall
- Mounting Hole Arrangement Style [ADFU]
- 2 Holes
- Mounting Hole Diameter [ABTB]
- 0.130 Inches Minimum And 0.135 Inches Maximum
- Nominal Thread Size [CQJX]
- 0.312 Inches
- Nut Height [ADEA]
- 0.328 Inches Maximum
- Nut Length [ACVN]
- 1.292 Inches Maximum
- Nut Mounting Provision [ADFP]
- Straight Holes
- Nut Style [ACTA]
- Plate
- Locking Feature [AAUM]
- Prevailing Torque All Metal Design
- Material Document And Classification [MDCL]
- Ams 5525 Assn Std Single Material Response Overall Or Ams 5735 Assn Std Single Material Response Overall Or Ams 5737 Assn Std Single Material Response Overall
- Plate Width [ADEC]
- 0.412 Inches Minimum And 0.609 Inches Maximum
- Plate Thickness [ADEB]
- 0.045 Inches Maximum
- Precious Material [PRMT]
- Silver
- Surface Treatment Document And Classification [STDC]
- Ams 2410 Assn Std Single Treatment Response Overall
- Surface Treatment [SFTT]
- Silver Overall
- Temp Rating [AZKQ]
- 800.0 Deg Fahrenheit Nominal
- Thread Class [AAJD]
- 3B
- Thread Direction [AAJF]
- Right-Hand
- Thread Series [BZRR]
- Unjf
- Thread Quantity Per Inch [CMLP]
- 24
Weapon Systems (WSDC) 5310-00-779-6769
DLA Procurement Analysis 5310-00-779-6769
- Last Stock Position:
- 7316 In Stock
- DLA Administrative Lead Time:
- Subscribe
- DLA Production Lead Time:
- Subscribe
Management Data 5310-00-779-6769
- Effective Date
- Organization
- Unit of Issue
- Unit Price
- Qty Unit Pack
- Unit of Issue
- Apr 2023
- US Coast Guard (GP)
- EA
- Subscribe
- EA
- Jan 2022
- Department of the Air Force (DF)
- EA
- Subscribe
- EA
- Oct 2021
- Department of the Navy (DN)
- EA
- Subscribe
- EA
- Oct 2020
- Defense Logistics Agency (DS)
- EA
- Subscribe
- EA
- Oct 2019
- Department of the Air Force (DF)
- EA
- Subscribe
- EA
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
Similar Supply Items to 5310-00-779-6769
Freight Information 5310-00-779-6769
5310-00-779-6769 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 093486. A Sub NMFC of Z. It has a NMFC Description of BOLTS,NUTS OR SCREWS, NOI (SUB 3). 5310-00-779-6769 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 48950 which rates the freight between FCL and LCL. 5310-00-779-6769 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 573 for ocean manifesting and military sealift. 5310-00-779-6769 is not classified as a special type of cargo when transported by water. 5310-00-779-6769 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 5310-00-779-6769
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- Bare Metal Item
- 2lb or less, one dimension 2" or less, other dimensions less than 24"
- Above 110G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- --
- --
- --
- --
- Physical Protection
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- No Requirement
- No Requirement
- Not Applicable
- Any Suitable Container
- No special marking
- No Requirement
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- PPP-B-566, PPP-B-676, or ASTM-D5118, Folding, Setup or Fiberboard Box
Procurement History 5310-00-779-6769 5 Records
- Contract
- Date
- CAGE
- Quantity
- Net Price
- Std Price
- CAGE
- SPE5E817V2190
- 20 Dec 2016
- Subscribe
- 162
- Subscribe
- Subscribe
- Subscribe
- SPE5E817PQ028
- 29 Nov 2016
- Subscribe
- 1601
- Subscribe
- Subscribe
- Subscribe
- SPE5E817P0197
- 13 Oct 2016
- Subscribe
- 5583
- Subscribe
- Subscribe
- Subscribe
- SPE5E816MQ259
- 23 Sep 2016
- Subscribe
- 1486
- Subscribe
- Subscribe
- Subscribe
- SPM5E813MQ122
- 27 Mar 2013
- Subscribe
- 1300
- Subscribe
- Subscribe
- Subscribe
Contracting Technical Data File (CTDF) 5310-00-779-6769 February 2021
Criticality and Quality
- Critical Item Code:
- X
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- F
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- N
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
