5310-00-739-0016

Plate Self-Locking Nut

5310007390016 007390016 SS5091-04-5 BACN10YF45 MF19058-4-5BAC RM52LHA3006M-5-048 MT8260S428S-5 MA13601-048-5 BRFM22A5-4 VN253A048-5 BACN10JQ45 RFM9206M-5-4 NS103201-048-5 5310PL0730421 5310PL1894327

A nut with a flanged base of varied shapes which may be plain or mounted by rivets, bolts, welding or integral prongs. An integral feature is incorporated for locking on the threads of a mating member. View more Plate Self-Locking Nut

Managed by United States

NSN Created on 1 Jan 1960

Data Last Changed
November 2023

NATO Update Count
43

NATO Data Quality

5310-00-739-0016 NUT,SELF-LOCKING,PLATE 5310007390016 007390016 1/4 — 5310-00-739-0016 Photo 1/4

5310-00-739-0016 NUT,SELF-LOCKING,PLATE 5310007390016 007390016 2/4 — 5310-00-739-0016 Photo 2/4

ACTA Style A116 for 5310-00-739-0016 3/4 — NSN 5310-00-739-0016 (Identification) 3/4

ADFU Style F38 for 5310-00-739-0016 4/4 — NSN 5310-00-739-0016 (Identification) 4/4

Marketplace 5310-00-739-0016

Need Help?
Request a Quotation from participating marketplace vendors

Subscribe to View Vendor Details...

BACN10-YF32 NUT,SELF-LOCKING,PLATE 767 EA NS

BACN10YF45 NUT,SELF-LOCKING,PLATE 379 EA NS

Subscribe to View Vendor Details...

BACN10JQ45 NUT,SELF-LOCKING,PLATE 20 EA NS

Subscribe to View Vendor Details...

MF19058-4-5BAC NUT,SELF-LOCKING,PLATE 17 EA NS

Subscribe to View Vendor Details...

RM52LHA3006M5-048 NUT,SELF-LOCKING,PLATE 253 EA NS

BACN10YF45 NUT,SELF-LOCKING,PLATE 1388 EA NS

Subscribe to View Vendor Details...

MF19058-4-5 NUT,SELF-LOCKING,PLATE 20 EA NS

Updated Every Day

5310-00-739-0016 RQST NE

Updated Every Day

5310-00-739-0016 RQST

Updated Every Day

5310-00-739-0016 RQST NE

Restrictions 5310-00-739-0016

5310-00-739-0016 is a Plate Self-Locking Nut that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. The precious metals content of this item is unknown.

Import and Export 5310-00-739-0016

Schedule B: Subscribe to View Schedule B
HTS Code: Subscribe to View HTS Code

End Users 5310-00-739-0016

US Air Force (FXGI)
Effective Date:: 1 Apr 2006
Former MOE Rule:: FXKZ; AMC 1 AMSC C IMC Z IMCACTY SX

US Navy (N9BZ)
Effective Date:: 1 Apr 2006
Former MOE Rule:: N9ZD
Supplementary Collaborators:: GTKE; AMC 1 AMSC C IMC Z IMCACTY GH

Poland (WP01)
Effective Date:: 1 Oct 2006

Brazil (YA01)
Effective Date:: 1 Sep 2000

Israel (YD01)
Effective Date:: 1 Aug 2016

Singapore (YJ01)
Effective Date:: 1 Apr 1991

Australia (ZA01)
Effective Date:: 1 Sep 2013

Belgium (ZB01)
Effective Date:: 1 Apr 1991

Republic of Korea (ZH01)
Effective Date:: 1 Apr 1991

Netherlands (ZN01)
Effective Date:: 1 Apr 1991

Portugal (ZP01)
Effective Date:: 1 Jan 2003

Denmark (ZS01)
Effective Date:: 1 Apr 1991

Norway (ZT01)
Effective Date:: 1 Apr 1991

Greece (ZU01)
Effective Date:: 1 Apr 2008

Turkey (ZW01)
Effective Date:: 1 Nov 2005

Approved Sources 5310-00-739-0016

Part Number
Manufacturer
Status
BACN10YF45: 81205 - The Boeing Company (Active); Primary Buy; RNCC 3 RNVC 2 DAC E
MF19058-4-5BAC: 15653 - Howmet Global Fastening Systems Inc (Active); Secondary Buy; RNCC 5 RNVC 2 DAC 2
RM52LHA3006M-5-048: 72962 - Harvard Industries Inc (Replaced); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 1
MT8260S428S-5: 11815 - Sps Technologies, Llc (Active); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 5
MA13601-048-5: 80539 - Sps Technologies, Llc (Active); Canceled/Obsolete; RNCC 5 RNVC 9 DAC E
BRFM22A5-4: 52828 - Republic Fastener Mfg. Corp. (Active); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 5
VN253A048-5: 92215 - Howmet Global Fastening Systems Inc (Active); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 5
BACN10JQ45: 81205 - The Boeing Company (Active); Canceled/Obsolete; RNCC 5 RNVC 9 DAC E
RFM9206M-5-4: 72962 - Harvard Industries Inc (Replaced); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 5
NS103201-048-5: 80539 - Sps Technologies, Llc (Active); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 5
5310PL0730421: 9009H - Jednolity Indeks Materialowy - (Active); NATO Reference; RNCC 6 RNVC 9 DAC 9
5310PL1894327: 9009H - Jednolity Indeks Materialowy - (Active); NATO Reference; RNCC 6 RNVC 9 DAC 9
SS5091-04-5: 78286 - Sikorsky Aircraft Corporation (Active); Advisory Reference; RNCC C RNVC 1 DAC E

Datasheet 5310-00-739-0016

Characteristic
Specifications
FIIG: A021A0
End Item Identification [AGAV]: C-5B Aircraft
Center To Center Distance Between Mounting Holes Along Length [ADFY]: 0.560 Inches Minimum And 0.564 Inches Maximum
Counterbore Diameter [AAWY]: 0.254 Inches Nominal Nut
Distance From Aperture Center To Mounting Hole Center [ADFW]: 0.276 Inches Minimum And 0.286 Inches Maximum
Features Provided [CBBL]: Floating Nut
Material [MATT]: Steel Overall
Mounting Hole Arrangement Style [ADFU]: 2 Holes
Mounting Hole Diameter [ABTB]: 0.098 Inches Minimum And 0.103 Inches Maximum
Nominal Thread Size [CQJX]: 0.250 Inches
Nut Counterbore Depth [ADFK]: 0.312 Inches Nominal Nut
Nut Length [ACVN]: 0.801 Inches Maximum
Nut Height [ADEA]: 0.531 Inches Maximum
Nut Mounting Provision [ADFP]: Straight Holes
Nut Style [ACTA]: Plate
Locking Feature [AAUM]: Prevailing Torque All Metal Design
Lubrication [ABAJ]: Dry Film Lubricant
Plate Width [ADEC]: 0.431 Inches Maximum
Plate Thickness [ADEB]: 0.125 Inches Nominal
Surface Treatment Document And Classification [STDC]: Mil-N-25027 Mil Spec Single Treatment Response Overall
Surface Treatment [SFTT]: Cadmium Overall
Temp Rating [AZKQ]: 450.0 Deg Fahrenheit Maximum
Thread Class [AAJD]: 3B
Thread Direction [AAJF]: Right-Hand
Thread Series [BZRR]: Unjf
Thread Quantity Per Inch [CMLP]: 28
