5310-00-685-2404
Round Plain Nut
5310006852404 006852404 6794006
A nut, circular in shape, which may have wrenching facilities such as flats, holes, protrusions, slots or splines in or on the periphery or in the face opposite the bearing surface. For items having a thickness (or height) exceeding two times the outside diameter, use POST, ELECTRICAL-MECHANICAL EQUIPMENT. See also NUT (1), PLAIN, KNURLED. (When height or thickness and/or outside diameter is designated as a tolerance dimension, the maximum dimension will be used to determine compliance.) View more Round Plain Nut
May 2023
7
Marketplace 5310-00-685-2404
Request a Quotation from participating marketplace vendors
Related Documents 5310-00-685-2404 5+ Documents (More...)
United States (US) 4. 5310-00-685-2404 Marketplace Restrictions Approved Sources Datasheet Management
Every Day 6794006 RQST NE Updated Every Day 5310-00-685-2404 RQST NE Updated Every Day 5310-00-685-2404
Restrictions 5310-00-685-2404
5310-00-685-2404 is a Round Plain Nut that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. The precious metals content of this item is unknown.
Import and Export 5310-00-685-2404
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5310-00-685-2404
- US Air Force (FXGI)
- Effective Date:
- 1 Aug 2005
- Former MOE Rule:
- FXKZ
- US Navy (N9BZ)
- Effective Date:
- 1 Aug 2005
- Supplementary Collaborators:
- KE
Approved Sources 5310-00-685-2404
- Part Number
- Manufacturer
- Status
- 6794006
- Manufacturer
- 63005 - Rolls-Royce Corporation (Active)
- Primary Buy
- Primary Buy
- 6794006
- 24617 - General Motors Corp (Active)
- Secondary Buy
- Secondary Buy
- 6794006
- 73342 - Allison Transmission Inc (Active)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 5310-00-685-2404
- Characteristic
- Specifications
- FIIG
- Specifications
- A021A0
- Drive Point Depth [ABQU]
- 0.169 Inches Minimum And 0.189 Inches Maximum
- Drive Point Quantity [ADBM]
- 8
- Drive Point Width [ADBH]
- 0.240 Nominal Mils And 0.260 Nominal Centimeters
- Hardness Rating [CQFM]
- 26.0 Rockwell C Minimum And 32.0 Rockwell C Maximum
- Material [MATT]
- Steel Comp 8735 Overall Or Steel Comp 8740 Overall
- Nominal Thread Size [CQJX]
- 2.125 Inches
- Nut Diameter [ACTD]
- 2.990 Inches Minimum And 3.010 Inches Maximum
- Nut Style [ACTA]
- Round
- Nut Thickness [ADBG]
- 0.430 Inches Minimum And 0.450 Inches Maximum
- Material Document And Classification [MDCL]
- Ams 6320 Assn Std 1St Material Response Overall Or Ams 6322 Assn Std 2Nd Material Response Overall Or Ams 6323 Assn Std 2Nd Material Response Overall Or Ams 6324 Assn Std 2Nd Material Response Overall
- Surface Treatment Document And Classification [STDC]
- Ams 2481 Assn Std Single Treatment Response Overall
- Surface Treatment [SFTT]
- Phosphate Overall
- Thread Direction [AAJF]
- Left-Hand
- Thread Class [AAJD]
- 3B
- Thread Quantity Per Inch [CMLP]
- 16
- Thread Series [BZRR]
- Un
DLA Procurement Analysis 5310-00-685-2404
Management Data 5310-00-685-2404
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
Similar Supply Items to 5310-00-685-2404
Freight Information 5310-00-685-2404
5310-00-685-2404 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 093486. A Sub NMFC of Z. It has a NMFC Description of BOLTS,NUTS OR SCREWS, NOI (SUB 3). 5310-00-685-2404 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 48950 which rates the freight between FCL and LCL. 5310-00-685-2404 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 573 for ocean manifesting and military sealift. 5310-00-685-2404 is not classified as a special type of cargo when transported by water. 5310-00-685-2404 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Contracting Technical Data File (CTDF) 5310-00-685-2404 February 2021
Criticality and Quality
- Critical Item Code:
- X
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- N
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
