5310-00-589-1377
Round Plain Nut
5310005891377 005891377 S6167-64228-1
A nut, circular in shape, which may have wrenching facilities such as flats, holes, protrusions, slots or splines in or on the periphery or in the face opposite the bearing surface. For items having a thickness (or height) exceeding two times the outside diameter, use POST, ELECTRICAL-MECHANICAL EQUIPMENT. See also NUT (1), PLAIN, KNURLED. (When height or thickness and/or outside diameter is designated as a tolerance dimension, the maximum dimension will be used to determine compliance.) View more Round Plain Nut
May 2023
4
Marketplace 5310-00-589-1377
Request a Quotation from participating marketplace vendors
Related Documents 5310-00-589-1377 5+ Documents (More...)
RQST NE Updated Every Day 5310-00-589-1377 RQST Updated Every Day 5310-00-589-1377 RQST NE Related Documents
5310-00-589-1377 4+ Documents ( More... ) https//www.nsnlookup.com /fsg-53/fsc-5310/us 5310-00-589-1377
Round Plain Nut 5310005891377 005891377 $1 a day Upgrade your Account Upgrade 5310-00-589-1377Round
Plain Nut5310005891377 005891377 S6167-64228 7520 Spring Tension Washer 5310143327520 143327520 1800Storage
Restrictions 5310-00-589-1377
5310-00-589-1377 is a Round Plain Nut that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
Import and Export 5310-00-589-1377
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5310-00-589-1377
- US Coast Guard (C918)
- Effective Date:
- 1 Mar 2006
- Former MOE Rule:
- C004
Approved Sources 5310-00-589-1377
- Part Number
- Manufacturer
- Status
- S6167-64228-1
- Manufacturer
- 78286 - Sikorsky Aircraft Corporation (Active)
- Primary Buy
- Primary Buy
Datasheet 5310-00-589-1377
- Characteristic
- Specifications
- FIIG
- Specifications
- A021A0
- Drilled Hole Diameter [AGGP]
- 0.062 Inches Nominal
- Drive Point Depth [ABQU]
- 0.167 Inches Nominal
- Drive Point Quantity [ADBM]
- 8
- Drive Point Width [ADBH]
- 0.250 Inches Nominal
- Countersink Angle [CRSQ]
- 20.0 Degrees Nominal Nut
- Hole Configuration Style [CRHC]
- Configuration J
- Hole Type And Quantity [ALET]
- 4 Drilled
- Material Document And Classification [MDCL]
- Qq-A-267,T6 Fed Spec Single Material Response Overall
- Material [MATT]
- Aluminum Alloy 2024 Overall
- Nominal Thread Size [CQJX]
- 1.938 Inches
- Nut Diameter [ACTD]
- 2.375 Inches Nominal
- Nut Style [ACTA]
- Round
- Nut Thickness [ADBG]
- 0.375 Inches Nominal
- Small End Diameter [ABPH]
- 2.188 Inches Nominal
- Undercut Thickness [ADBJ]
- 0.375 Inches Nominal
- Surface Treatment Document And Classification [STDC]
- Mtl-A-8625 Mil Spec 1St Treatment Response Overall And Tt-P-1757 Fed Spec 2Nd Treatment Response Overall
- Surface Treatment [SFTT]
- Anodize Overall And Chromate Zinc Overall
- Thread Class [AAJD]
- 3B
- Thread Direction [AAJF]
- Right-Hand
- Thread Quantity Per Inch [CMLP]
- 16
- Thread Series [BZRR]
- Un
DLA Procurement Analysis 5310-00-589-1377
Management Data 5310-00-589-1377
Similar Supply Items to 5310-00-589-1377
Freight Information 5310-00-589-1377
5310-00-589-1377 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 013540. A Sub NMFC of X. It has a NMFC Description of ALUM NUTS. 5310-00-589-1377 is rated as class 70 when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 05680 which rates the freight between FCL and LCL. 5310-00-589-1377 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 713 for ocean manifesting and military sealift. 5310-00-589-1377 is not classified as a special type of cargo when transported by water. 5310-00-589-1377 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
