5310-00-567-5341
Double Hexagon Extended Washer Self-Locking Nut
5310005675341 005675341 47FLW624 5001369 5310PL2138066
A nut having 12 drive points, 24 sides, and an integral washer which extends beyond the points or periphery. An integral feature is incorporated for locking on the threads of a mating member. View more Double Hexagon Extended Washer Self-Locking Nut
Managed by United States
NSN Created on 28 Nov 1974
Data Last Changed
September 2023
September 2023
NATO Update Count
16
16
NATO Data Quality
Marketplace 5310-00-567-5341
Need Help?
Request a Quotation from participating marketplace vendors
Request a Quotation from participating marketplace vendors
Related Documents 5310-00-567-5341 4+ Documents (More...)
47FLW624 5001369 5310PL2138066 A nut having 12 drive points, 24 sides, and an integral washer which
Photo 1/2 NSN 5310-00-567-5341 (Identification) 2/2 - - 1.
United States (US) 4. 5310-00-567-5341 Marketplace Restrictions Approved Sources Datasheet Management
Photo 1/2 NSN 5310-00-567-5341 (Identification) 2/2 - - 1.
United States (US) 4. 5310-00-567-5341 Marketplace Restrictions Approved Sources Datasheet Management
057-5704 5310-01-459-1198 5310-00-463-9227 5310-99-145-0138 5310-00-857-4987 5310-00-655-9863 5310-00-567-5341
057-5704 5310-01-459-1198 5310-00-463-9227 5310-99-145-0138 5310-00-857-4987 5310-00-655-9863 5310-00-567-5341
057-5704 5310-01-459-1198 5310-00-463-9227 5310-99-145-0138 5310-00-857-4987 5310-00-655-9863 5310-00-567-5341
Restrictions 5310-00-567-5341
5310-00-567-5341 is a Double Hexagon Extended Washer Self-Locking Nut that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. The precious metals content of this item is unknown.
Import and Export 5310-00-567-5341
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5310-00-567-5341
- US Army (A919)
- Effective Date:
- 1 Jun 2005
- Former MOE Rule:
- A187
- US Air Force (FXGI)
- Effective Date:
- 1 Jun 2005
- Former MOE Rule:
- FXKZ
- US Navy (N9BZ)
- Effective Date:
- 1 Jun 2005
- Former MOE Rule:
- N9ZD
- Supplementary Collaborators:
- GTKE
- Spain (YB01)
- Effective Date:
- 1 Feb 1994
- Columbia (YC01)
- Effective Date:
- 1 Jul 2015
- Singapore (YJ01)
- Effective Date:
- 1 Apr 1991
- South Africa (ZD01)
- Effective Date:
- 1 Aug 2008
- Republic of Korea (ZH01)
- Effective Date:
- 1 Oct 2009
- Italy (ZR01)
- Effective Date:
- 1 Nov 2001
- Turkey (ZW01)
- Effective Date:
- 1 Oct 2001
Approved Sources 5310-00-567-5341
- Part Number
- Manufacturer
- Status
- 47FLW624
- Manufacturer
- 56878 - Sps Technologies, Llc (Active)
- Primary Buy
- Primary Buy
- 47FLW624
- A0126 - Leonardo Spa Helicopters Division - (Active)
- Secondary Buy
- Secondary Buy
- 5310PL2138066
- 9009H - Jednolity Indeks Materialowy - (Active)
- NATO Reference
- NATO Reference
- 5001369
- 73842 - Goodyear Tire And Rubber Co The (Active)
- Vendor Drawing
- Vendor Drawing
Datasheet 5310-00-567-5341
- Characteristic
- Specifications
- FIIG
- Specifications
- A021A0
- Hardness Rating [CQFM]
- 34.0 Rockwell C Minimum And 43.0 Rockwell C Maximum
- Material [MATT]
- Steel Overall
- Nominal Thread Size [CQJX]
- 0.375 Inches
- Nut Style [ACTA]
- Double Hexagon
- Locking Feature [AAUM]
- Prevailing Torque All Metal Design
- Lubrication [ABAJ]
- Soluble Lubricant
- Overall Height [ABKW]
- 0.438 Inches Maximum
- Washer Outside Diameter [AAVX]
- 0.654 Inches Nominal
- Washer Thickness [ADEM]
- 0.056 Inches Nominal
- Width Across Flats [ASDB]
- 0.492 Inches Nominal
- Surface Treatment [SFTT]
- Cadmium Overall
- Temp Rating [AZKQ]
- 450.0 Deg Fahrenheit Nominal
- Thread Class [AAJD]
- 3B
- Thread Direction [AAJF]
- Right-Hand
- Thread Quantity Per Inch [CMLP]
- 24
- Thread Series [BZRR]
- Unjf
Weapon Systems (WSDC) 5310-00-567-5341
DLA Procurement Analysis 5310-00-567-5341
- Last Stock Position:
- 95 In Stock
- DLA Administrative Lead Time:
- Subscribe
- DLA Production Lead Time:
- Subscribe
Management Data 5310-00-567-5341
Army
- Materiel Category and Inventory Manager:
- T
- Industrial Supplies (DLA/GSA Items)
- Appropriation and Budget Activity:
- 2
- Stock Fund Secondary Items
- Management Inventory Segment:
- 2
- Non-Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify items, which are not reparable.
- Weapons System / End Item / Homogeneous Group:
- 00
- DLA/GSA Material
DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item
- Accounting Requirements:
- X
- Expendable item.An item of Army property coded with an ARC of X in the AMDF. Expendable items require no formal accountability after issue from a stock record account.Commercial and fabricated items similar to items coded X in the AMDF are considered expendable items.
Air Force
- Fund:
- SF
- Stock fund applicable to items managed for the Air Force by the respective Inventory Control Point
- Budget:
- 9
- 57X4921.070 - General Support DIV - Air Force decentralized managed expense items (ERRC XB3, XF3) with a unit cost of less than $250,000 that are requisitioned/procured at base (retail) level from DLA, GSA, Army, Navy, Depot Maintenance Service, Air Force Industrial Fund (AFMC), local manufacture and commercial vendors
- Aggregation Code:
- SX
- SICA RESIDUAL MMAC-OC-ALC
- Price Validation Code:
- N
- The current standard price in Catalog Management Data (CMD) has not analyzed or coded for LP/LM.
The price has not been analyzed or reviewed for accuracy.
ZOP or Standard price challenges are permissible but must be supported with adequate justification. However, if coded for Local Purchase (LP) or Fabrication/Manufacture as indicated with an (LM) Acquisition Advice Code of “L” or “F”, then it must be evaluated locally where purchased or fabricated.
- Expendability
Recoverability
Repairability: - N
- Expendable. Condemn at User. Stock Fund (except Munitions).
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
Similar Supply Items to 5310-00-567-5341
Freight Information 5310-00-567-5341
5310-00-567-5341 has freight characteristics managed by the Southwestern Power Administration.It has a National Motor Freight Classification (NMFC) of 093486. A Sub NMFC of Z. It has a NMFC Description of BOLTS,NUTS OR SCREWS, NOI (SUB 3). 5310-00-567-5341 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 48950 which rates the freight between FCL and LCL. 5310-00-567-5341 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 573 for ocean manifesting and military sealift. 5310-00-567-5341 is not classified as a special type of cargo when transported by water. 5310-00-567-5341 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 5310-00-567-5341
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- Bare Metal Item
- 2lb or less, one dimension 2" or less, other dimensions less than 24"
- Above 110G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- --
- --
- --
- --
- Physical Protection
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- No Requirement
- No Requirement
- Not Applicable
- Any Suitable Container
- No special marking
- No Requirement
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- --
Procurement History 5310-00-567-5341 15 Records
- Contract
- Date
- CAGE
- Quantity
- Net Price
- Std Price
- CAGE
- SPE4A624V0289
- 06 Oct 2023
- Subscribe
- 310
- Subscribe
- Subscribe
- Subscribe
- SPE5EJ21V2709
- 17 Mar 2021
- Subscribe
- 349
- Subscribe
- Subscribe
- Subscribe
- SPE5E717V1325
- 12 Dec 2016
- Subscribe
- 185
- Subscribe
- Subscribe
- Subscribe
- SPE5E017V0887
- 22 Nov 2016
- Subscribe
- 785
- Subscribe
- Subscribe
- Subscribe
- SPE5E717V0313
- 20 Oct 2016
- Subscribe
- 200
- Subscribe
- Subscribe
- Subscribe
- SPE5E716V4281
- 26 Jul 2016
- Subscribe
- 220
- Subscribe
- Subscribe
- Subscribe
- SPE5E016V2949
- 10 Jun 2016
- Subscribe
- 647
- Subscribe
- Subscribe
- Subscribe
- SPE5E716V1073
- 09 Dec 2015
- Subscribe
- 238
- Subscribe
- Subscribe
- Subscribe
- SPE5EN15V0226
- 27 Aug 2015
- Subscribe
- 131
- Subscribe
- Subscribe
- Subscribe
- SPE5E715M3310
- 10 Jul 2015
- Subscribe
- 338
- Subscribe
- Subscribe
- Subscribe
- SPE5E715V4465
- 01 Jul 2015
- Subscribe
- 182
- Subscribe
- Subscribe
- Subscribe
- SPE5E714V5304
- 28 Jul 2014
- Subscribe
- 286
- Subscribe
- Subscribe
- Subscribe
- SPM5E113V9940
- 27 Aug 2013
- Subscribe
- 100
- Subscribe
- Subscribe
- Subscribe
- SPM5E713V1876
- 23 May 2013
- Subscribe
- 179
- Subscribe
- Subscribe
- Subscribe
- SPM5E713M3164
- 29 Apr 2013
- Subscribe
- 239
- Subscribe
- Subscribe
- Subscribe
Contracting Technical Data File (CTDF) 5310-00-567-5341 February 2021
Criticality and Quality
- Critical Item Code:
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- F
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
