5310-00-557-9362
Hexagon Extended Washer Plain Nut
5310005579362 005579362 203-2889623PC32 203-3PC32
A nut having 6 flat sides and an integral washer which extends beyond the flats or periphery. View more Hexagon Extended Washer Plain Nut
May 2023
5
Marketplace 5310-00-557-9362
Request a Quotation from participating marketplace vendors
Related Documents 5310-00-557-9362 3+ Documents (More...)
BUY NE FedMall Updated Every Day 5310-00-557-9362 RQST NE Updated Every Day 5310-00-557-9362 RQST
Updated Every Day 5310-00-557-9362 RQST NE Related Documents 5310-00-557-9362 1+ Documents ( More...
Restrictions 5310-00-557-9362
5310-00-557-9362 is a Hexagon Extended Washer Plain Nut that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. The precious metals content of this item is unknown.
Import and Export 5310-00-557-9362
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5310-00-557-9362
- US Navy (N9BZ)
- Effective Date:
- 1 Mar 2006
- Former MOE Rule:
- N9ZD
- Supplementary Collaborators:
- HD
Approved Sources 5310-00-557-9362
- Part Number
- Manufacturer
- Status
- 203-2889623PC32
- Manufacturer
- 80064 - Naval Ship Systems Command (Active)
- Primary Buy
- Primary Buy
- 203-3PC32
- 16640 - Defoe Shipbuilding Co (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 5310-00-557-9362
- Characteristic
- Specifications
- FIIG
- Specifications
- A021A0
- Material [MATT]
- Steel Overall
- Nominal Thread Size [CQJX]
- 2.500 Inches
- Nut Style [ACTA]
- Hexagon
- Material Document And Classification [MDCL]
- Astm A27 Assn Std Single Material Response Overall
- Overall Height [ABKW]
- 1.375 Inches Nominal
- Washer Outside Diameter [AAVX]
- 5.000 Inches Nominal
- Washer Thickness [ADEM]
- 0.312 Inches Nominal
- Width Across Flats [ASDB]
- 3.875 Inches Nominal
- Thread Class [AAJD]
- 3B
- Thread Direction [AAJF]
- Right-Hand
- Thread Quantity Per Inch [CMLP]
- 12
- Thread Series [BZRR]
- Un
DLA Procurement Analysis 5310-00-557-9362
Management Data 5310-00-557-9362
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
Similar Supply Items to 5310-00-557-9362
Freight Information 5310-00-557-9362
5310-00-557-9362 has freight characteristics managed by the Southwestern Power Administration.It has a National Motor Freight Classification (NMFC) of 093486. A Sub NMFC of Z. It has a NMFC Description of BOLTS,NUTS OR SCREWS, NOI (SUB 3). 5310-00-557-9362 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 48950 which rates the freight between FCL and LCL. 5310-00-557-9362 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 573 for ocean manifesting and military sealift. 5310-00-557-9362 is not classified as a special type of cargo when transported by water. 5310-00-557-9362 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 5310-00-557-9362
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- Bare Metal Item
- 2lb or less, one dimension 2" or less, other dimensions less than 24"
- Above 110G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- --
- --
- --
- Physical Protection
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- No Requirement
- No Requirement
- Not Applicable
- Any Suitable Container
- No special marking
- No Requirement
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- --
Contracting Technical Data File (CTDF) 5310-00-557-9362 February 2021
Criticality and Quality
- Critical Item Code:
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- R
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
