5310-00-550-0284
Lock Washer
5310005500284 005500284 1506 MS35336-9 0740797 NWL004-103-002 PT1506
A washer which is usually round with a centrally located hole. Its edges and two bearing surfaces are so designed that applied pressure brings into play the spring tension and/or frictional locking principle which materially resists any tendency toward turning. It may be made of one or two pieces View more Lock Washer
Managed by United States
NSN Created on 1 Jan 1963
Data Last Changed
November 2023
November 2023
NATO Update Count
60
60
NATO Data Quality
Marketplace 5310-00-550-0284
Need Help?
Request a Quotation from participating marketplace vendors
Request a Quotation from participating marketplace vendors
Related Documents 5310-00-550-0284 5+ Documents (More...)
1506 MS35336-9 0740797 NWL004-103-002 PT1506 A washer which is usually round with a centrally located
MS35336-9 WASHER,LOCK 45 HD NS Request Quotation Subscribe to View Vendor Details... 1506 WASHER,LOCK
MS35336-9 WASHER,LOCK 17 HD NS Request Quotation Subscribe to View Vendor Details... 1506 WASHER,LOCK
MS35336-9 WASHER,LOCK 45 HD NS Request Quotation Subscribe to View Vendor Details... 1506 WASHER,LOCK
MS35336-9 WASHER,LOCK 17 HD NS Request Quotation Subscribe to View Vendor Details... 1506 WASHER,LOCK
Account Upgrade 5310-01-004-5028Lock Washer5310010045028 010045028 Cancelled - Replaced by NSN 5310-00-550-0284
MS35336-9 WASHER,LOCK 45 EA NS Request Quotation Subscribe to View Vendor Details...
MS35336-9 WASHER,LOCK RQST NS Request Quotation Subscribe to View Vendor Details...
MS35336-9 WASHER,LOCK 45 EA NS Request Quotation Subscribe to View Vendor Details...
MS35336-9 WASHER,LOCK RQST NS Request Quotation Subscribe to View Vendor Details...
enable JavaScript in your web browser . 1390-99-613-8556Electric Primer Igniter1390996138556 996138556 PT1506
| RNVC: 2 | DAC: 2 25 Apr 1991 1390-99-613-8556 https//www.nsnlookup.com /fsg-53/fsc-5310/us 5310-00-550-0284
Lock Washer 5310005500284 005500284,1506 Upgrade 5310-00-550-0284Lock Washer5310005500284 005500284
| RNVC: 2 | DAC: 2 25 Apr 1991 1390-99-613-8556 https//www.nsnlookup.com /fsg-53/fsc-5310/us 5310-00-550-0284
Lock Washer 5310005500284 005500284,1506 Upgrade 5310-00-550-0284Lock Washer5310005500284 005500284
MS35336-9 WASHER,LOCK 45 EA NS Request Quotation Subscribe to View Vendor Details...
MS35336-9 WASHER,LOCK RQST NS Request Quotation Subscribe to View Vendor Details...
MS35336-9 WASHER,LOCK 17 EA NS Request Quotation Updated Every Day 5310-00-194-9207 RQST Updated Every
MS35336-9 WASHER,LOCK RQST NS Request Quotation Subscribe to View Vendor Details...
MS35336-9 WASHER,LOCK 17 EA NS Request Quotation Updated Every Day 5310-00-194-9207 RQST Updated Every
MS35336-9 WASHER,LOCK 45 EA NS Request Quotation Subscribe to View Vendor Details...
MS35336-9 WASHER,LOCK RQST NS Request Quotation Subscribe to View Vendor Details...
MS35336-9 WASHER,LOCK 17 EA NS Request Quotation Updated Every Day 5310-00-209-1364 RQST Updated Every
MS35336-9 WASHER,LOCK RQST NS Request Quotation Subscribe to View Vendor Details...
MS35336-9 WASHER,LOCK 17 EA NS Request Quotation Updated Every Day 5310-00-209-1364 RQST Updated Every
Restrictions 5310-00-550-0284
5310-00-550-0284 is a Lock Washer that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. The precious metals content of this item is unknown.
Import and Export 5310-00-550-0284
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5310-00-550-0284
- US Army (A919)
- Effective Date:
- 1 Apr 2006
- Former MOE Rule:
- A187
- Supplementary Receivers:
- AJCTCLBFBDAZ
- US Air Force (FXGI)
- Effective Date:
- 1 Apr 2006
- Former MOE Rule:
- FXKZ
- US Marine Corps (MC47)
- Effective Date:
- 1 Apr 2006
- Former MOE Rule:
- MC10
- US Navy (N9BZ)
- Effective Date:
- 1 Apr 2006
- Former MOE Rule:
- N9ZD
- Supplementary Collaborators:
- GTKEHXHD
- Austria (WB01)
- Effective Date:
- 1 Feb 2005
- Poland (WP01)
- Effective Date:
- 1 Jul 2011
- Brazil (YA01)
- Effective Date:
- 1 Sep 2000
- Spain (YB01)
- Effective Date:
- 1 Apr 1991
- Singapore (YJ01)
- Effective Date:
- 1 Apr 1991
- Morocco (YP01)
- Effective Date:
- 1 Nov 2008
- Australia (ZA01)
- Effective Date:
- 1 Apr 1991
- Canada (ZC01)
- Effective Date:
- 1 Apr 1991
- New Zealand (ZE01)
- Effective Date:
- 1 Apr 1991
- France (ZF01)
- Effective Date:
- 1 Apr 1991
- Germany (ZG01)
- Effective Date:
- 1 Apr 1991
- Republic of Korea (ZH01)
- Effective Date:
- 1 Apr 1991
- United Kingdom (ZK01)
- Effective Date:
- 1 Apr 1991
- Netherlands (ZN01)
- Effective Date:
- 1 Apr 1991
- Portugal (ZP01)
- Effective Date:
- 1 Feb 2013
- Italy (ZR01)
- Effective Date:
- 1 Jul 1997
- Denmark (ZS01)
- Effective Date:
- 1 Jun 2002
- Greece (ZU01)
- Effective Date:
- 1 Apr 1991
- Turkey (ZW01)
- Effective Date:
- 1 Nov 2005
- NATO Maintenance and Supply Agency (ZX01)
- Effective Date:
- 1 Aug 2004
Approved Sources 5310-00-550-0284
- Part Number
- Manufacturer
- Status
- MS35336-9
- Manufacturer
- 96906 - Military Standards (Active)
- Definitive Standard
- Definitive Standard
- 0740797
- S3002 - General Dynamics European, (Active)
- Secondary Buy
- Secondary Buy
- NWL004-103-002
- 0ZW31 - Measurement Specialties Inc (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- PT1506
- 78189 - Itw Shakeproof Automotive Products (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
- 5310005500284
- A00AM - E.C.A Etablissement Central Des (Active)
- NATO Reference
- NATO Reference
- 1506
- D9182 - Zf Industrieantriebe Witten Gmbh (Active)
- Advisory Reference
- Advisory Reference
Datasheet 5310-00-550-0284
- Characteristic
- Specifications
- FIIG
- Specifications
- A022B0
- Countersink Angle [CRSQ]
- 80.0 Degrees Minimum And 82.0 Degrees Maximum
- Hardness Rating [CQFM]
- 40.0 Rockwell C Minimum And 50.0 Rockwell C Maximum
- Hole Diameter [AAUB]
- 0.140 Inches Minimum And 0.150 Inches Maximum
- Material Thickness [ABPX]
- 0.017 Inches Minimum And 0.021 Inches Maximum
- Material [MATT]
- Steel Comp 1050 Overall Or Steel Comp 1551 Overall Or Steel Comp 1552 Overall Or Steel Comp 1053 Overall Or Steel Comp 1055 Overall Or Steel Comp 1059 Overall Or Steel Comp 1060 Overall Or Steel Comp 1561 Overall Or Steel Comp 1064 Overall
- Nondefinitive Spec/Std Data [ZZZT]
- 4 Type And 1 Style And A Grade And 1 Composition
- Outside Diameter [ABKV]
- 0.289 Inches Nominal
- Material Document And Classification [MDCL]
- 66 Fed Std All Material Responses Overall
- Style Designator [STYL]
- Countersink External Teeth
- Surface Treatment Document And Classification [STDC]
- Qq-P-416,Ty 2,Cl 3 Fed Spec Single Treatment Response Overall
- Surface Treatment [SFTT]
- Cadmium Overall
Weapon Systems (WSDC) 5310-00-550-0284
DLA Procurement Analysis 5310-00-550-0284
- Last Stock Position:
- 333100 In Stock
- DLA Administrative Lead Time:
- Subscribe
- DLA Production Lead Time:
- Subscribe
Management Data 5310-00-550-0284
- Effective Date
- Organization
- Unit of Issue
- Unit Price
- Qty Unit Pack
- Unit of Issue
- Oct 2022
- US Marine Corps (DM)
- HD
- Subscribe
- 1
- HD
- Oct 2021
- Defense Logistics Agency (DS)
- HD
- Subscribe
- 1
- HD
- Oct 2020
- Defense Logistics Agency (DS)
- HD
- Subscribe
- 1
- HD
- Oct 2019
- Department of the Air Force (DF)
- HD
- Subscribe
- 1
- HD
- MOE
- USC
- Code
- Statement
- Order of Use
- Jump To Code
- Qty Per Assy
- UOM
- Technical Document
- Quantative Expression
- Code
- US Marine Corps (DM)
- M
- 0
- Reversal Of Phrase Code Z 5310-00-013-8589
- 0
- US Marine Corps (DM)
- M
- 0
- Reversal Of Phrase Code Z 5310-00-209-1364
- 0
Army
- Materiel Category and Inventory Manager:
- T
- Industrial Supplies (DLA/GSA Items)
- Appropriation and Budget Activity:
- 2
- Stock Fund Secondary Items
- Management Inventory Segment:
- 2
- Non-Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify items, which are not reparable.
- Weapons System / End Item / Homogeneous Group:
- CC
- Other Aircraft Categories
Multi-Application Aviation Spares
- Accounting Requirements:
- X
- Expendable item.An item of Army property coded with an ARC of X in the AMDF. Expendable items require no formal accountability after issue from a stock record account.Commercial and fabricated items similar to items coded X in the AMDF are considered expendable items.
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
Marine Corps
- Stores Account:
- 1
- Stock Fund Account Item
- Combat Essentiality:
- 5
- Critical Repair Part to a Combat Essential End Item
- Echelon Management:
- B2
- Operational Test:
- No Special Procedures
Similar Supply Items to 5310-00-550-0284
Freight Information 5310-00-550-0284
5310-00-550-0284 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 194160. A Sub NMFC of X. It has a NMFC Description of WASHER OR GASKETS, IRON OR STEEL,. 5310-00-550-0284 is rated as class 50 when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 55210 which rates the freight between FCL and LCL. 5310-00-550-0284 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 713 for ocean manifesting and military sealift. 5310-00-550-0284 is not classified as a special type of cargo when transported by water. 5310-00-550-0284 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 5310-00-550-0284
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- Bare Metal Item
- 2lb or less, one dimension 2" or less, other dimensions less than 24"
- Above 110G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- --
- --
- --
- Physical Protection
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- No Requirement
- No Requirement
- Not Applicable
- Any Suitable Container
- No special marking
- No Requirement
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- --
Contracting Technical Data File (CTDF) 5310-00-550-0284 February 2021
Criticality and Quality
- Critical Item Code:
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- F
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- N
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
