5310-00-527-4799
Round Plain Nut
5310005274799 005274799 272912
A nut, circular in shape, which may have wrenching facilities such as flats, holes, protrusions, slots or splines in or on the periphery or in the face opposite the bearing surface. For items having a thickness (or height) exceeding two times the outside diameter, use POST, ELECTRICAL-MECHANICAL EQUIPMENT. See also NUT (1), PLAIN, KNURLED. (When height or thickness and/or outside diameter is designated as a tolerance dimension, the maximum dimension will be used to determine compliance.) View more Round Plain Nut
November 2023
10
Marketplace 5310-00-527-4799
Request a Quotation from participating marketplace vendors
Related Documents 5310-00-527-4799 5+ Documents (More...)
Details... 272912 NUT 114 EA NS Request Quotation Subscribe to View Vendor Details... 272912 NUT,PLAIN
Request Quotation Updated Every Day 5310-00-527-4799 RQST NE Updated Every Day 5310-00-527-4799 RQST
Round Plain Nut 5310005274799 005274799 for $1 a day Upgrade your Account Upgrade 5310-00-527-4799Round
Plain Nut5310005274799 005274799 272912 Details... 272912 NUT 114 EA NS Request Quotation Subscribe
Restrictions 5310-00-527-4799
5310-00-527-4799 is a Round Plain Nut that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item contains Silver.
Import and Export 5310-00-527-4799
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5310-00-527-4799
- US Air Force (FXGI)
- Effective Date:
- 1 Jun 2005
- Former MOE Rule:
- FXKZ
- US Navy (N9BZ)
- Effective Date:
- 1 Dec 2013
- Supplementary Collaborators:
- GG
- Canada (ZC01)
- Effective Date:
- 1 Apr 1991
- France (ZF01)
- Effective Date:
- 1 Apr 1991
Approved Sources 5310-00-527-4799
- Part Number
- Manufacturer
- Status
- 272912
- Manufacturer
- 77445 - Rtx Corporation (Active)
- Primary Buy
- Primary Buy
- 272912
- 11449 - Turbo Power & Marine System Inc (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 5310-00-527-4799
- Characteristic
- Specifications
- FIIG
- Specifications
- A021A0
- Drive Point Depth [ABQU]
- 0.120 Inches Nominal
- Drive Point Quantity [ADBM]
- 16
- Drive Point Width [ADBH]
- 0.365 Nominal Mils And 0.385 Nominal Centimeters
- Countersink Angle [CRSQ]
- 88.0 Degrees Minimum Nut And 92.0 Degrees Maximum Nut
- Hardness Rating [CQFM]
- 32.0 Rockwell C Minimum And 38.0 Rockwell C Maximum
- Material [MATT]
- Steel Comp 8740 Overall
- Nominal Thread Size [CQJX]
- 4.700 Inches
- Nut Diameter [ACTD]
- 6.050 Inches Minimum And 6.070 Inches Maximum
- Nut Style [ACTA]
- Round
- Nut Thickness [ADBG]
- 0.589 Inches Nominal
- Material Document And Classification [MDCL]
- Asm 6324 Assn Std Single Material Response Overall Or Asm 6323 Assn Std Single Material Response Overall
- Precious Material [PRMT]
- Silver
- Surface Treatment Document And Classification [STDC]
- Ams 2412 Assn Std Single Treatment Response Overall
- Surface Treatment [SFTT]
- Silver Overall
- Thread Direction [AAJF]
- Right-Hand
- Thread Quantity Per Inch [CMLP]
- 16
- Thread Pitch Diameters [AAJE]
- +4.6594/+4.6660 Inches
- Thread Series [BZRR]
- Uns
Weapon Systems (WSDC) 5310-00-527-4799
DLA Procurement Analysis 5310-00-527-4799
- Last Stock Position:
- 125 In Stock
- DLA Administrative Lead Time:
- Subscribe
- DLA Production Lead Time:
- Subscribe
Management Data 5310-00-527-4799
Air Force
- Fund:
- SF
- Stock fund applicable to items managed for the Air Force by the respective Inventory Control Point
- Budget:
- 9
- 57X4921.070 - General Support DIV - Air Force decentralized managed expense items (ERRC XB3, XF3) with a unit cost of less than $250,000 that are requisitioned/procured at base (retail) level from DLA, GSA, Army, Navy, Depot Maintenance Service, Air Force Industrial Fund (AFMC), local manufacture and commercial vendors
- Aggregation Code:
- SX
- SICA RESIDUAL MMAC-OC-ALC
- Price Validation Code:
- N
- The current standard price in Catalog Management Data (CMD) has not analyzed or coded for LP/LM.
The price has not been analyzed or reviewed for accuracy.
ZOP or Standard price challenges are permissible but must be supported with adequate justification. However, if coded for Local Purchase (LP) or Fabrication/Manufacture as indicated with an (LM) Acquisition Advice Code of “L” or “F”, then it must be evaluated locally where purchased or fabricated.
- Expendability
Recoverability
Repairability: - N
- Expendable. Condemn at User. Stock Fund (except Munitions).
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
Similar Supply Items to 5310-00-527-4799
Freight Information 5310-00-527-4799
5310-00-527-4799 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 093486. A Sub NMFC of Z. It has a NMFC Description of BOLTS,NUTS OR SCREWS, NOI (SUB 3). 5310-00-527-4799 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 48950 which rates the freight between FCL and LCL. 5310-00-527-4799 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 573 for ocean manifesting and military sealift. 5310-00-527-4799 is not classified as a special type of cargo when transported by water. 5310-00-527-4799 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 5310-00-527-4799
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- Bare Metal Item
- 2lb or less, one dimension 2" or less, other dimensions less than 24"
- Above 110G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- --
- --
- --
- Physical Protection
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- No Requirement
- No Requirement
- Not Applicable
- Any Suitable Container
- No special marking
- No Requirement
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- --
Procurement History 5310-00-527-4799 10 Records
- Contract
- Date
- CAGE
- Quantity
- Net Price
- Std Price
- CAGE
- SPE4A518F702C
- 23 May 2018
- Subscribe
- 40
- Subscribe
- Subscribe
- Subscribe
- SPE4A518F193RP00001
- 07 Feb 2018
- Subscribe
- 41
- Subscribe
- Subscribe
- Subscribe
- SPETA618P0391
- 28 Dec 2017
- Subscribe
- 13
- Subscribe
- Subscribe
- Subscribe
- SPE4A517P7037
- 23 May 2017
- Subscribe
- 11
- Subscribe
- Subscribe
- Subscribe
- SPE4A517P6938
- 19 May 2017
- Subscribe
- 5
- Subscribe
- Subscribe
- Subscribe
- SPE4A514V3293P00002
- 14 Aug 2014
- Subscribe
- 32
- Subscribe
- Subscribe
- Subscribe
- SPE4A514M3547
- 12 Feb 2014
- Subscribe
- 7
- Subscribe
- Subscribe
- Subscribe
- SPE4A514M0650
- 23 Oct 2013
- Subscribe
- 5
- Subscribe
- Subscribe
- Subscribe
- SPE4A513M7921
- 26 Aug 2013
- Subscribe
- 2
- Subscribe
- Subscribe
- Subscribe
- SPE4A513M7625
- 15 Aug 2013
- Subscribe
- 1
- Subscribe
- Subscribe
- Subscribe
Contracting Technical Data File (CTDF) 5310-00-527-4799 October 2021
Criticality and Quality
- Critical Item Code:
- X
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- F
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- N
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
