5310-00-498-2889
Push On Nut
5310004982889 004982889 C17373-012-24D
An item formed from sheet spring material into varying flat, concave, curved, or nutlike design. It has an aperture with an elliptical-shaped hole or suitable lugs or prongs designed to retain threaded or unthreaded stud like projecting memebers. When pushed on, it grips by imbedding into the material of the projecting memebers, and does not mate with a thread helix. See also RING, RETAINING. View more Push On Nut
May 2023
6
Marketplace 5310-00-498-2889
Request a Quotation from participating marketplace vendors
Related Documents 5310-00-498-2889 5+ Documents (More...)
BUY NE FedMall Updated Every Day 5310-00-498-2889 RQST NE Updated Every Day 5310-00-498-2889 RQST
Updated Every Day 5310-00-498-2889 RQST NE Related Documents 5310-00-498-2889 3+ Documents ( More...
vendors Request Updated Every Day 5310-00-613-4286 https//www.nsnlookup.com /fsg-53/fsc-5310/us 5310-00-498-2889
Push On Nut 5310004982889 004982889 for $1 a day Upgrade your Account Upgrade 5310-00-498-2889Push
Restrictions 5310-00-498-2889
5310-00-498-2889 is a Push On Nut that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
End Users 5310-00-498-2889
- US Navy (N9BZ)
- Effective Date:
- 1 Mar 2014
- Supplementary Collaborators:
- HX
- United States of America (ZZ)
Approved Sources 5310-00-498-2889
- Part Number
- Manufacturer
- Status
- C17373-012-24D
- Manufacturer
- 78553 - Tinnerman Palnut Engineered (Obsolete)
- Original Design
- Original Design
- C17373-012-24D
- 84992 - Industrial Fasteners Corp (Active)
- Secondary Buy
- Secondary Buy
- C17373-012-24D
- 1L906 - Arden Fasteners Inc (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 5310-00-498-2889
- Characteristic
- Specifications
- FIIG
- Specifications
- A021A0
- Material Thickness [ABPX]
- 0.012 Inches Nominal
- Material [MATT]
- Steel Overall
- Mating Member Diameter Accommodated [ACSZ]
- 0.312 Inches Nominal
- Nut Length [ACVN]
- 0.630 Inches Nominal
- Nut Width [ADED]
- 0.500 Inches Nominal
- Nut Style [ACTA]
- Push On
- Part Name Assigned By Controlling Agency [CXCY]
- Navy Special Project
- Surface Treatment [SFTT]
- Cadmium And Dichromate Overall
DLA Procurement Analysis 5310-00-498-2889
Management Data 5310-00-498-2889
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
Similar Supply Items to 5310-00-498-2889
Freight Information 5310-00-498-2889
5310-00-498-2889 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 093486. A Sub NMFC of Z. It has a NMFC Description of BOLTS,NUTS OR SCREWS, NOI (SUB 3). 5310-00-498-2889 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 48950 which rates the freight between FCL and LCL. 5310-00-498-2889 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 573 for ocean manifesting and military sealift. 5310-00-498-2889 is not classified as a special type of cargo when transported by water. 5310-00-498-2889 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Contracting Technical Data File (CTDF) 5310-00-498-2889 February 2021
Criticality and Quality
- Critical Item Code:
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- N
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- Y
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
