5310-00-461-2764
Flat Washer
5310004612764 004612764 MES78A 5310PL0717763
A washer having a centrally located hole with a solid or laminated cross-section and two flat parallel bearing surfaces. The hole must be 75 percent or less than the largest dimension and the bearing surface finish is greater than 32 microinch (0.8 micrometer). The thickness cannot exceed 25 percent of the largest outside dimension. When the largest outside dimension is less than 1/4 inch or 6mm, the thickness must be 0.006 inches (0.15mm) or greater and for items 1/4 inch (6mm) or larger, the thickness must be 0.016 inches (0.4mm) or greater. The maximum tolerance is applied to dimensions and used as a determining factor. Items with separable lamination use SHIM. For items fabricated from ceramic or electrically rated materials by specification or industry standards use INSULATOR (1), WASHER. Excludes DISK, VALVE, graphite impregnated and lubricated items. View more Flat Washer
May 2023
17
Marketplace 5310-00-461-2764
Request a Quotation from participating marketplace vendors
Related Documents 5310-00-461-2764 5+ Documents (More...)
Photo 1/4 NSN 5310-00-461-2764 (Identification) 2/4 NSN 5310-00-461-2764 (Identification) 3/4 NSN
,FLAT 100 EA NS Request Quotation Updated Every Day 5310-00-461-2764 RQST NE Updated Every Day 5310-00
Restrictions 5310-00-461-2764
5310-00-461-2764 is a Flat Washer that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. The precious metals content of this item is unknown.
Import and Export 5310-00-461-2764
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5310-00-461-2764
- New Zealand (ZE01)
- Effective Date:
- 1 Apr 1991
- Turkey (ZW01)
- Effective Date:
- 1 Jun 2006
Approved Sources 5310-00-461-2764
- Part Number
- Manufacturer
- Status
- MES78A
- Manufacturer
- 24975 - Prestolite Electric Inc (Active)
- Primary Buy
- Primary Buy
- MES78A
- 68505 - Prestolite Electric Inc (Replaced)
- Canceled/Obsolete
- Canceled/Obsolete
- 5310PL0717763
- 9009H - Jednolity Indeks Materialowy - (Active)
- NATO Reference
- NATO Reference
Datasheet 5310-00-461-2764
- Characteristic
- Specifications
- FIIG
- Specifications
- A022B0
- Center Hole Shape Style [ABMX]
- Round
- Cross-Sectional Shape Style [AAGR]
- Rectangular
- Hole Diameter [AAUB]
- 0.500 Inches Nominal
- Material [MATT]
- Steel Overall
- Overall Diameter [ADAV]
- 0.875 Inches Nominal
- Peripheral Shape Style [ABMW]
- Round
- Thickness [ABNM]
- 0.032 Inches Nominal
Similar Supply Items to 5310-00-461-2764
Freight Information 5310-00-461-2764
5310-00-461-2764 has freight characteristics managed by the Southwestern Power Administration.It has a National Motor Freight Classification (NMFC) of 194160. A Sub NMFC of X. It has a NMFC Description of WASHER OR GASKETS, IRON OR STEEL,. 5310-00-461-2764 is rated as class 50 when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 55210 which rates the freight between FCL and LCL. 5310-00-461-2764 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 713 for ocean manifesting and military sealift. 5310-00-461-2764 is not classified as a special type of cargo when transported by water. 5310-00-461-2764 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
