5310-00-406-7739
Clinch Self-Locking Nut
5310004067739 004067739 508566-3 56LN056C
A nut having a sleeve portion on its under side, which can be crimped or clinched to hold the item in place when inserted in a hole. An integral feature is incorporated for locking. View more Clinch Self-Locking Nut
May 2023
12
Marketplace 5310-00-406-7739
Request a Quotation from participating marketplace vendors
Related Documents 5310-00-406-7739 3+ Documents (More...)
Photo 1/2 NSN 5310-00-406-7739 (Identification) 2/2 - - 1.
Every Day 5310-00-406-7739 RQST NE Updated Every Day 5310-00-406-7739 RQST Updated Every Day 5310-00
Clinch Self-Locking Nut 5310004067739 a day Upgrade your Account Upgrade 5310-00-406-7739Clinch
Self-Locking Nut5310004067739 004067739 508566 56LN056C NUT,SELF-LOCKING,CLINCH 2300 EA NS Request Quotation
Restrictions 5310-00-406-7739
5310-00-406-7739 is a Clinch Self-Locking Nut that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. The precious metals content of this item is unknown.
Import and Export 5310-00-406-7739
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5310-00-406-7739
- US Air Force (FXGI)
- Effective Date:
- 1 Mar 2006
- Former MOE Rule:
- FXKZ
- Canada (ZC01)
- Effective Date:
- 1 Apr 1991
- Turkey (ZW01)
- Effective Date:
- 1 Nov 2005
Approved Sources 5310-00-406-7739
- Part Number
- Manufacturer
- Status
- 508566-3
- Manufacturer
- 31550 - L3harris Technologies, Inc. (Active)
- Primary Buy
- Primary Buy
- 56LN056C
- 86577 - Precision Metal Products Co (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 5310-00-406-7739
- Characteristic
- Specifications
- FIIG
- Specifications
- A021A0
- Countersink Angle [CRSQ]
- 90.0 Degrees Nominal Nut
- Material [MATT]
- Steel Overall
- Nominal Thread Size [CQJX]
- 0.138 Inches
- Nut Height [ADEA]
- 0.175 Inches Minimum And 0.183 Inches Maximum
- Nut Style [ACTA]
- Clinch
- Locking Feature [AAUM]
- Prevailing Torque All Metal Design
- Lubrication [ABAJ]
- Dry Film Lubricant
- Pilot Length [AAVM]
- 0.052 Inches Minimum And 0.056 Inches Maximum
- Pilot Diameter [AAVL]
- 0.259 Inches Minimum And 0.263 Inches Maximum
- Width Across Flats [ASDB]
- 0.296 Inches Minimum And 0.328 Inches Maximum
- Surface Treatment Document And Classification [STDC]
- Qq-P-416,Ty 2,Cl 3 Fed Spec Single Treatment Response Overall
- Surface Treatment [SFTT]
- Cadmium Overall
- Thread Direction [AAJF]
- Right-Hand
- Thread Class [AAJD]
- 3B
- Thread Quantity Per Inch [CMLP]
- 32
- Thread Series [BZRR]
- Unc
Weapon Systems (WSDC) 5310-00-406-7739
DLA Procurement Analysis 5310-00-406-7739
Management Data 5310-00-406-7739
Similar Supply Items to 5310-00-406-7739
Freight Information 5310-00-406-7739
5310-00-406-7739 has freight characteristics managed by the Southwestern Power Administration.It has a National Motor Freight Classification (NMFC) of 093486. A Sub NMFC of Z. It has a NMFC Description of BOLTS,NUTS OR SCREWS, NOI (SUB 3). 5310-00-406-7739 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 48950 which rates the freight between FCL and LCL. 5310-00-406-7739 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 573 for ocean manifesting and military sealift. 5310-00-406-7739 is not classified as a special type of cargo when transported by water. 5310-00-406-7739 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 5310-00-406-7739
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- Bare Metal Item
- 2lb or less, one dimension 2" or less, other dimensions less than 24"
- Above 110G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- --
- --
- --
- Physical Protection
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- No Requirement
- No Requirement
- Not Applicable
- Any Suitable Container
- No special marking
- No Requirement
