5310-00-404-3183
Concave Washer
5310004043183 004043183 F4367-08 GB500A08A 74049-08 K52300-08 952963-1 F4367-8
A washer which is round with a centrally located hole. One bearing surface is smooth, flat, and unbroken, the other bearing surface is smooth, unbroken, and is recessed to form a curved or spherical contour. See also WASHER (1), CONVEX. Excludes WASHER (1), RECESSED and BEARING, WASHER, THRUST. View more Concave Washer
May 2023
9
Marketplace 5310-00-404-3183
Request a Quotation from participating marketplace vendors
Related Documents 5310-00-404-3183 4+ Documents (More...)
/fsg-53/fsc-5310/us
F4367-8 WASHER,CONCAVE 9045 EA NS Request Quotation FedMall Updated Every 15 Minutes 5310-00-404-3183
BUY NE FedMall Updated Every Day 5310-00-404-3183 RQST NE Updated Every Day 5310-00-404-3183 RQST Updated
https//www.nsnlookup.com /fsg-53/fsc-5310/us 5310-00-404-3183 Concave Washer 5310004043183 004043183
-08 GB500A08A 74049-08 K52300-08 952963-1 F4367-8 A washer which is round with a centrally located hole
Concave Washer 5310004043183 004043183 Upgrade 5310-00-404-3183Concave Washer5310004043183 004043183
F4367-08 GB500A08A 74049-08 K52300-08 952963 RNVC 9 DAC 2 F4367-8 72962 - Harvard Industries Inc (Replaced
Concave Washer 5310004043183 004043183 for $1 a day Upgrade your Account Upgrade 5310-00-404-3183Concave
Washer5310004043183 004043183 F4367-08 Documents 5310-00-404-3183 1+ Documents ( More... ) https//www.nsnlookup.com
Restrictions 5310-00-404-3183
5310-00-404-3183 is a Concave Washer that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. The precious metals content of this item is unknown.
Import and Export 5310-00-404-3183
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5310-00-404-3183
- US Air Force (FXGI)
- Effective Date:
- 1 Jun 2005
- Former MOE Rule:
- FXKZ
- US Navy (N9BZ)
- Effective Date:
- 1 Jun 2005
- Former MOE Rule:
- N9ZD
- Supplementary Collaborators:
- GTKEHD
Approved Sources 5310-00-404-3183
- Part Number
- Manufacturer
- Status
- GB500A08A
- Manufacturer
- 26512 - Northrop Grumman Systems Corporation (Active)
- Primary Buy
- Primary Buy
- F4367-08
- 091L2 - Across Technologies Inc (Active)
- Secondary Buy
- Secondary Buy
- GB500A08A
- 019L2 - Esna, Llc (Active)
- Secondary Buy
- Secondary Buy
- 74049-08
- 56878 - Sps Technologies, Llc (Active)
- Secondary Buy
- Secondary Buy
- K52300-08
- 15653 - Howmet Global Fastening Systems Inc (Active)
- Secondary Buy
- Secondary Buy
- F4367-8
- 22599 - Amerace Corp (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
- F4367-8
- 72962 - Harvard Industries Inc (Replaced)
- Canceled/Obsolete
- Canceled/Obsolete
- 952963-1
- 06481 - Northrop Grumman Systems Corporation (Active)
- Vendor Drawing
- Vendor Drawing
- GB500A08A
- 95296 - Pacific Lumber Co The (Active)
- Vendor Drawing
- Vendor Drawing
Datasheet 5310-00-404-3183
- Characteristic
- Specifications
- FIIG
- Specifications
- A022B0
- End Item Identification [AGAV]
- W/S:F4n Aircraft, Aircraft, Prowler Ea-6B; Aircraft, Intruder A-6E; Aircraft, Hawkeye E-2C; Aircraft, Viking S-3B; Aircraft, Tomcat F-14
- Heat Treatment [HEAT]
- Quenched And Tempered
- Hole Diameter [AAUB]
- 0.214 Inches Nominal
- Material Thickness [ABPX]
- 0.060 Inches Nominal
- Material [MATT]
- Steel Overall
- Outside Diameter [ABKV]
- 0.305 Inches Minimum And 0.315 Inches Maximum
- Radius [ABGG]
- 0.174 Inches Nominal
- Style Designator [STYL]
- Concave
- Surface Treatment Document And Classification [STDC]
- Qq-P-416,Ty 2,Cl 3 Fed Spec Single Treatment Response Overall
- Surface Treatment [SFTT]
- Cadmium Overall And Chromate Overall
Weapon Systems (WSDC) 5310-00-404-3183
DLA Procurement Analysis 5310-00-404-3183
- Last Stock Position:
- 1898 In Stock
- DLA Administrative Lead Time:
- Subscribe
- DLA Production Lead Time:
- Subscribe
Management Data 5310-00-404-3183
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
Similar Supply Items to 5310-00-404-3183
Freight Information 5310-00-404-3183
5310-00-404-3183 has freight characteristics managed by the Southwestern Power Administration.It has a National Motor Freight Classification (NMFC) of 194160. A Sub NMFC of X. It has a NMFC Description of WASHER OR GASKETS, IRON OR STEEL,. 5310-00-404-3183 is rated as class 50 when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 55210 which rates the freight between FCL and LCL. 5310-00-404-3183 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 713 for ocean manifesting and military sealift. 5310-00-404-3183 is not classified as a special type of cargo when transported by water. 5310-00-404-3183 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 5310-00-404-3183
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- Bare Metal Item
- 2lb or less, one dimension 2" or less, other dimensions less than 24"
- Above 110G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- --
- --
- --
- Physical Protection
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- No Requirement
- No Requirement
- Not Applicable
- Any Suitable Container
- No special marking
- No Requirement
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- --
Contracting Technical Data File (CTDF) 5310-00-404-3183 February 2021
Criticality and Quality
- Critical Item Code:
- X
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- F
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
