5310-00-395-1569
Key Washer
5310003951569 003951569 A76786
A washer of nonresilient material usually having two parallel bearing surfaces. The outside and/or inside edges have one or more protuberances. The ends and/or edges may be prebent at any angle or the protuberances may be prebent at any angle to the bearing surfaces. The keys or lugs may be fitted into keyways in adjacent material or they may be bent over after application to hold or lock one or more items in place. Excludes thrust type washer. View more Key Washer
May 2023
5
Marketplace 5310-00-395-1569
Request a Quotation from participating marketplace vendors
Related Documents 5310-00-395-1569 5+ Documents (More...)
BUY NE FedMall Updated Every Day 5310-00-395-1569 RQST NE Updated Every Day 5310-00-395-1569 RQST
Updated Every Day 5310-00-395-1569 RQST NE Related Documents 5310-00-395-1569 2+ Documents ( More...
www.nsnlookup.com /fsg-59/fsc-5962/uk 5962-99-799-4064 https//www.nsnlookup.com /fsg-53/fsc-5310/us 5310-00-395-1569
Key Washer 5310003951569 003951569,A76786 Restrictions Approved Sources Datasheet Management https
Restrictions 5310-00-395-1569
5310-00-395-1569 is a Key Washer that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. The precious metals content of this item is unknown.
Import and Export 5310-00-395-1569
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5310-00-395-1569
- National Security Agency (DGX1)
- Effective Date:
- 1 Jan 2014
- US Navy (N9BZ)
- Effective Date:
- 1 Mar 2014
- Supplementary Collaborators:
- HDKEHX
- Spain (YB01)
- Effective Date:
- 1 Apr 1991
Approved Sources 5310-00-395-1569
- Part Number
- Manufacturer
- Status
- A76786
- Manufacturer
- 58275 - Sasco Inc Canadian Div (Obsolete)
- Original Design
- Original Design
Datasheet 5310-00-395-1569
- Characteristic
- Specifications
- FIIG
- Specifications
- A022B0
- Distance From Centerline To Inside Of Prebent Key [ABLS]
- 0.485 Inches Nominal
- Angle Between External Keys [CSFW]
- 30.0 Degrees Nominal
- External Key Quantity [ABMQ]
- 3
- External Prebent Key Angle [CSKN]
- 15.0 Degrees Nominal
- External Prebent Key Length [ABKY]
- 0.125 Inches Nominal
- External Prebent Key Width [ABLF]
- 0.156 Inches Nominal
- External Tapered Key Width [ABLD]
- 0.375 Inches Nominal
- Hole Diameter [AAUB]
- 0.387 Inches Minimum And 0.393 Inches Maximum
- Material Thickness [ABPX]
- 0.054 Inches Nominal
- Outside Diameter [ABKV]
- 0.625 Inches Nominal
- Material [MATT]
- Steel Corrosion Resisting Overall
- Material Document And Classification [MDCL]
- A508,Fscm 58275 Mfr Ref Single Material Response Overall
- Overall Distance Including Keys [ABLX]
- 0.781 Inches Nominal
- Split Key Length [ABMM]
- 0.015 Inches Nominal
- Style Designator [STYL]
- Key
DLA Procurement Analysis 5310-00-395-1569
Management Data 5310-00-395-1569
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
Similar Supply Items to 5310-00-395-1569
Freight Information 5310-00-395-1569
5310-00-395-1569 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 194160. A Sub NMFC of X. It has a NMFC Description of WASHER OR GASKETS, IRON OR STEEL,. 5310-00-395-1569 is rated as class 50 when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 55210 which rates the freight between FCL and LCL. 5310-00-395-1569 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 713 for ocean manifesting and military sealift. 5310-00-395-1569 is not classified as a special type of cargo when transported by water. 5310-00-395-1569 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 5310-00-395-1569
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- Bare Metal Item
- 2lb or less, one dimension 2" or less, other dimensions less than 24"
- Above 110G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- --
- --
- --
- Physical Protection
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- No Requirement
- No Requirement
- Not Applicable
- Any Suitable Container
- No special marking
- No Requirement
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- --
Contracting Technical Data File (CTDF) 5310-00-395-1569 February 2021
Criticality and Quality
- Critical Item Code:
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- N
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
