5310-00-282-9121
Hexagon Castellated Plain Nut
5310002829121 002829121 AC35B416-2 AN7502-20 111S11
A nut having 6 flat sides, flat on the bottom and having a slotted cylindrical or dome shaped upper portion. It is designed to provide positive locking when used with a solid or split (cotter) pin. Excludes NUT (1), PLAIN, SLOTTED, HEXAGON. View more Hexagon Castellated Plain Nut
May 2023
21
Marketplace 5310-00-282-9121
Request a Quotation from participating marketplace vendors
Related Documents 5310-00-282-9121 5+ Documents (More...)
Photo 1/3 5310-00-282-9121 Photo 2/3 NSN 5310-00-282-9121 (Identification) 3/3 - - - 1.
AN7502-20 NUT,PLAIN,CASTELLATED,HEXAGON 32 EA NS Request Quotation Updated Every Day 5310-00-282-9121
United States (US) 4. 5310-00-262-5514 Marketplace Restrictions Approved Sources Datasheet Management AN7502-20
Hexagon Castellated Plain Nut 5310002829121 Documents 5310-00-282-9121 1+ Documents ( More... )
Restrictions 5310-00-282-9121
5310-00-282-9121 is a Hexagon Castellated Plain Nut that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. The precious metals content of this item is unknown.
Import and Export 5310-00-282-9121
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5310-00-282-9121
- Spain (YB01)
- Effective Date:
- 1 Apr 1991
- Columbia (YC01)
- Effective Date:
- 1 Jul 2015
- New Zealand (ZE01)
- Effective Date:
- 1 Apr 1991
- France (ZF01)
- Effective Date:
- 1 Apr 1991
- Republic of Korea (ZH01)
- Effective Date:
- 1 Apr 1991
- Portugal (ZP01)
- Effective Date:
- 1 Apr 1991
- Greece (ZU01)
- Effective Date:
- 1 Apr 1991
- Turkey (ZW01)
- Effective Date:
- 1 Nov 1998
Approved Sources 5310-00-282-9121
- Part Number
- Manufacturer
- Status
- AN7502-20
- Manufacturer
- 88044 - Aeronautical Standards Group (Active)
- Definitive Standard
- Definitive Standard
- AC35B416-2
- 80049 - Department Of The Air Force (Active)
- Incomplete Secondary Reference
- Incomplete Secondary Reference
- 111S11
- 06840 - Bendix Corp The (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
- 111S11
- 14892 - Bendix Corp The Brake And Steering (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 5310-00-282-9121
- Characteristic
- Specifications
- FIIG
- Specifications
- A021A0
- Bearing Surface Type [CRTM]
- Chamfered Or Washer Faced
- Material Document And Classification [MDCL]
- Qq-S-633-Canc Fed Spec Single Material Response Overall
- Material [MATT]
- Steel Overall
- Nominal Thread Size [CQJX]
- 1.250 Inches
- Nut Height [ADEA]
- 0.562 Inches Nominal
- Nut Style [ACTA]
- Castellated, Hexagon
- Width Across Flats [ASDB]
- 1.500 Inches Nominal
- Surface Treatment [SFTT]
- Cadmium Overall Or Zinc Overall
- Thread Direction [AAJF]
- Right-Hand
- Thread Class [AAJD]
- 3B
- Thread Quantity Per Inch [CMLP]
- 16
- Thread Series [BZRR]
- Un
Similar Supply Items to 5310-00-282-9121
Freight Information 5310-00-282-9121
5310-00-282-9121 has freight characteristics.. 5310-00-282-9121 has a variance between NMFC and UFC when transported by rail and the description should be consulted.
