5310-00-274-4658
Hexagon Plain Nut
5310002744658 002744658 1DD414 PC5150087 5150087
A nut, flat on top and bottom having 6 flat sides. For items which have internal tapered or straight (parallel) pipe threads, specific electrical conduit size designation, and which when installed, provide a method of tightening to lock the connection, see LOCKNUT, ELECTRICAL CONDUIT. See also LOCKNUT, TUBE FITTING. For items having a thickness (or height) exceeding two times the width across the flats, use POST, ELECTRICAL-MECHANICAL EQUIPMENT. (When height or thickness and/or width across the flats is designated as a tolerance dimension, the maximum dimension will be used to determine compliance.) View more Hexagon Plain Nut
Managed by United States
NSN Created on 1 Jan 1961
Data Last Changed
March 2025
March 2025
NATO Update Count
48
48
NATO Data Quality
Marketplace 5310-00-274-4658
Need Help?
Request a Quotation from participating marketplace vendors
Request a Quotation from participating marketplace vendors
Related Documents 5310-00-274-4658 3+ Documents (More...)
1DD414 PC5150087 5150087 A nut, flat on top and bottom having 6 flat sides.
RQST NE Updated Every Day 5310-00-274-4658 RQST NE Updated Every Day 5310-00-274-4658 RQST Updated Every
Day 5310-00-274-4658 RQST NE Related Documents 5310-00-274-4658 3+ Documents ( More... ) https//www.nsnlookup.com
RQST NE Updated Every Day 5310-00-274-4658 RQST NE Updated Every Day 5310-00-274-4658 RQST Updated Every
Day 5310-00-274-4658 RQST NE Related Documents 5310-00-274-4658 3+ Documents ( More... ) https//www.nsnlookup.com
ADPEC : 2815-21-004-9570 is a Hexagon Plain Nut https//www.nsnlookup.com /fsg-53/fsc-5310/us 5310-00-274-4658
Hexagon Plain Nut 5310002744658 002744658 Documents 5310-00-274-4658 2+ Documents ( More... ) https
Hexagon Plain Nut 5310002744658 002744658 Documents 5310-00-274-4658 2+ Documents ( More... ) https
vendors Request Updated Every Day 5310-01-207-7244 https//www.nsnlookup.com /fsg-53/fsc-5310/us 5310-00-274-4658
Hexagon Plain Nut 5310002744658 002744658 5310-00-274-4658 2+ Documents ( More... ) https https
AssyUOMTechnical DocumentQuantative ExpressionDefense Logistics Agency (DS)IZDiscontinued-Use 5310-00-274-4658
Hexagon Plain Nut 5310002744658 002744658 5310-00-274-4658 2+ Documents ( More... ) https https
AssyUOMTechnical DocumentQuantative ExpressionDefense Logistics Agency (DS)IZDiscontinued-Use 5310-00-274-4658
Restrictions 5310-00-274-4658
5310-00-274-4658 is a Hexagon Plain Nut that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
Import and Export 5310-00-274-4658
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5310-00-274-4658
- US Army (A919)
- Effective Date:
- 1 Apr 2006
- Former MOE Rule:
- A187
- Supplementary Receivers:
- AZCLBFBD
- US Coast Guard (C918)
- Effective Date:
- 1 Apr 2006
- Former MOE Rule:
- C004
- US Air Force (FXGI)
- Effective Date:
- 1 Apr 2006
- Former MOE Rule:
- FXKZ
- US Marine Corps (MC47)
- Effective Date:
- 1 Apr 2006
- Former MOE Rule:
- MC10
- US Navy (N9BZ)
- Effective Date:
- 1 Apr 2006
- Former MOE Rule:
- NIZD
- Supplementary Collaborators:
- GTKEHD
- Austria (WB01)
- Effective Date:
- 1 Feb 2005
- Lithuania (WI01)
- Effective Date:
- 1 Feb 2001
- Brazil (YA01)
- Effective Date:
- 1 Dec 2001
- Spain (YB01)
- Effective Date:
- 1 Apr 1991
- Singapore (YJ01)
- Effective Date:
- 1 Apr 1991
- Malaysia (YW01)
- Effective Date:
- 1 Jan 1998
- Australia (ZA01)
- Effective Date:
- 1 Apr 1991
- Belgium (ZB01)
- Effective Date:
- 1 Apr 1991
- Canada (ZC01)
- Effective Date:
- 1 Apr 1991
- New Zealand (ZE01)
- Effective Date:
- 1 Apr 1991
- France (ZF01)
- Effective Date:
- 1 Apr 1991
- Germany (ZG01)
- Effective Date:
- 1 Apr 1991
- Republic of Korea (ZH01)
- Effective Date:
- 1 Apr 1991
- Netherlands (ZN01)
- Effective Date:
- 1 Apr 1991
- Portugal (ZP01)
- Effective Date:
- 1 Apr 1991
- Italy (ZR01)
- Effective Date:
- 1 Apr 1991
- Denmark (ZS01)
- Effective Date:
- 1 Apr 1991
- Norway (ZT01)
- Effective Date:
- 1 Dec 1993
- Greece (ZU01)
- Effective Date:
- 1 Apr 1991
- Turkey (ZW01)
- Effective Date:
- 1 Aug 1993
- NATO Maintenance and Supply Agency (ZX01)
- Effective Date:
- 1 Sep 2004
Approved Sources 5310-00-274-4658
- Part Number
- Manufacturer
- Status
- 5150087
- Manufacturer
- 7X677 - General Motors Llc (Active)
- Primary Buy
- Primary Buy
- 5150087
- 72582 - Rolls-Royce Solutions America Inc (Active)
- Primary Buy
- Primary Buy
- 5150087
- ZV845 - Penske Australia Pty Ltd (Active)
- Secondary Buy
- Secondary Buy
- PC5150087
- C7432 - Power Components (Deutschland) Gmbh (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
- 5150087
- 92392 - Allis-Chalmers Corp (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
- 5150087
- F0742 - Delphi France Sas (Replaced)
- Canceled/Obsolete
- Canceled/Obsolete
- 5150087
- 97907 - Terex Corp (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
- 5150087
- 24617 - General Motors Corp (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- 5310002744658
- A00AM - E.C.A Etablissement Central Des (Active)
- NATO Reference
- NATO Reference
- 1DD414
- 45152 - Oshkosh Corp (Active)
- Advisory Reference
- Advisory Reference
Datasheet 5310-00-274-4658
- Characteristic
- Specifications
- FIIG
- Specifications
- A021A0
- Bearing Surface Finish [CSXL]
- 125.0 Microinches
- Bearing Surface Type [CRTM]
- Washer Faced
- Countersink Angle [CRSQ]
- 90.0 Degrees Nominal Nut
- Hardness Rating [CQFM]
- 28.0 Rockwell C Minimum And 33.0 Rockwell C Maximum
- Material Document And Classification [MDCL]
- Sae Assn Std Single Material Response Overall
- Material [MATT]
- Steel Comp 1141 Overall
- Nominal Thread Size [CQJX]
- 1.125 Inches
- Nut Height [ADEA]
- 0.428 Inches Minimum And 0.448 Inches Maximum
- Nut Style [ACTA]
- Hexagon
- Thread Series [BZRR]
- Unef
- Thread Quantity Per Inch [CMLP]
- 18
- Width Across Flats [ASDB]
- 1.490 Inches Minimum And 1.510 Inches Maximum
- Thread Class [AAJD]
- 2B
- Thread Direction [AAJF]
- Right-Hand
Weapon Systems (WSDC) 5310-00-274-4658
DLA Procurement Analysis 5310-00-274-4658
- Last Stock Position:
- 989 In Stock
- DLA Administrative Lead Time:
- Subscribe
- DLA Production Lead Time:
- Subscribe
Management Data 5310-00-274-4658
- Effective Date
- Organization
- Unit of Issue
- Unit Price
- Qty Unit Pack
- Unit of Issue
- Oct 2022
- Department of the Navy (DN)
- EA
- Subscribe
- 5
- EA
- Mar 2022
- Department of the Air Force (DF)
- EA
- Subscribe
- 5
- EA
- Oct 2021
- US Marine Corps (DM)
- EA
- Subscribe
- 5
- EA
- Oct 2020
- Defense Logistics Agency (DS)
- EA
- Subscribe
- 5
- EA
- Oct 2019
- Department of the Air Force (DF)
- EA
- Subscribe
- 5
- EA
- MOE
- USC
- Code
- Statement
- Order of Use
- Jump To Code
- Qty Per Assy
- UOM
- Technical Document
- Quantative Expression
- Code
- US Marine Corps (DM)
- M
- 4
- Reversal Of Phrase Code A 5310-00-273-7781
- 4
- US Marine Corps (DM)
- M
- 4
- Reversal Of Phrase Code A 5310-00-367-7240
- 4
- US Marine Corps (DM)
- M
- 4
- Reversal Of Phrase Code A 5310-00-514-9512
- 4
Army
- Materiel Category and Inventory Manager:
- T
- Industrial Supplies (DLA/GSA Items)
- Appropriation and Budget Activity:
- 2
- Stock Fund Secondary Items
- Management Inventory Segment:
- 2
- Non-Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify items, which are not reparable.
- Weapons System / End Item / Homogeneous Group:
- 00
- DLA/GSA Material
DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item
- Accounting Requirements:
- X
- Expendable item.An item of Army property coded with an ARC of X in the AMDF. Expendable items require no formal accountability after issue from a stock record account.Commercial and fabricated items similar to items coded X in the AMDF are considered expendable items.
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
Marine Corps
- Stores Account:
- 1
- Stock Fund Account Item
- Combat Essentiality:
- 5
- Critical Repair Part to a Combat Essential End Item
- Echelon Management:
- B2
- Material Identification:
- B
- Consumable Repair Parts
- Operational Test:
- No Special Procedures
Similar Supply Items to 5310-00-274-4658
Freight Information 5310-00-274-4658
5310-00-274-4658 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 093486. A Sub NMFC of Z. It has a NMFC Description of BOLTS,NUTS OR SCREWS, NOI (SUB 3). 5310-00-274-4658 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 48950 which rates the freight between FCL and LCL. 5310-00-274-4658 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 573 for ocean manifesting and military sealift. 5310-00-274-4658 is not classified as a special type of cargo when transported by water. 5310-00-274-4658 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 5310-00-274-4658
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
- Storage Environment
- Unheated General Purpose
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- 1.6" H x 1.5" W x 0.4" L
- --
- Bare Metal Item
- 2lb or less, one dimension 2" or less, other dimensions less than 24"
- Above 110G
- Special Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 5
- 2.2" H x 2.0" W x 0.7" L
- --
- --
- Physical Protection
- Any Suitable Process
- 2.2" H x 2.0" W x 0.7" L
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- No Requirement
- No Requirement
- Not Applicable
- Any Suitable Container
- No special marking
- No Requirement
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- --
Procurement History 5310-00-274-4658 9 Records
- Contract
- Date
- CAGE
- Quantity
- Net Price
- Std Price
- CAGE
- SPE4A623V461K
- 15 Aug 2023
- Subscribe
- 420
- Subscribe
- Subscribe
- Subscribe
- SPE4A623V170H
- 24 Apr 2023
- Subscribe
- 130
- Subscribe
- Subscribe
- Subscribe
- SPE4A623V070M
- 22 Mar 2023
- Subscribe
- 418
- Subscribe
- Subscribe
- Subscribe
- SPE5E818V9729
- 06 Sep 2018
- Subscribe
- 151
- Subscribe
- Subscribe
- Subscribe
- SPE5E818V9431
- 29 Aug 2018
- Subscribe
- 332
- Subscribe
- Subscribe
- Subscribe
- SPM7LX08D902841NM
- 12 May 2014
- Subscribe
- 10
- Subscribe
- Subscribe
- Subscribe
- SPM7LX08D902840JP
- 27 Nov 2013
- Subscribe
- 1
- Subscribe
- Subscribe
- Subscribe
- SPM7LX08D902839QC
- 15 Aug 2013
- Subscribe
- 7
- Subscribe
- Subscribe
- Subscribe
- SPM7LX08D902838BG
- 22 Feb 2013
- Subscribe
- 3000
- Subscribe
- Subscribe
- Subscribe
Contracting Technical Data File (CTDF) 5310-00-274-4658 February 2021
Criticality and Quality
- Critical Item Code:
- X
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- F
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- N
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
