5310-00-167-0683
Lock Washer
5310001670683 001670683 AN935-1216L
A washer which is usually round with a centrally located hole. Its edges and two bearing surfaces are so designed that applied pressure brings into play the spring tension and/or frictional locking principle which materially resists any tendency toward turning. It may be made of one or two pieces View more Lock Washer
May 2023
19
Marketplace 5310-00-167-0683
Request a Quotation from participating marketplace vendors
Related Documents 5310-00-167-0683 5+ Documents (More...)
Photo 1/3 5310-00-167-0683 Photo 2/3 NSN 5310-00-167-0683 (Identification) 3/3 - - - 1.
AN935-1216L WASHER,LOCK 1 EA NS Request Quotation Updated Every Day 5310-00-167-0683 RQST NE Updated
Restrictions 5310-00-167-0683
5310-00-167-0683 is a Lock Washer that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. The precious metals content of this item is unknown.
End Users 5310-00-167-0683
- Brazil (YA01)
- Effective Date:
- 1 Jan 2011
- New Zealand (ZE01)
- Effective Date:
- 1 Apr 1991
- Turkey (ZW01)
- Effective Date:
- 1 Nov 2005
Approved Sources 5310-00-167-0683
- Part Number
- Manufacturer
- Status
- AN935-1216L
- Manufacturer
- 88044 - Aeronautical Standards Group (Active)
- Definitive Standard
- Definitive Standard
Datasheet 5310-00-167-0683
- Characteristic
- Specifications
- FIIG
- Specifications
- A022B0
- Hardness Rating [CQFM]
- 45.0 Rockwell C Minimum And 53.0 Rockwell C Maximum
- Hole Diameter [AAUB]
- 0.763 Inches Minimum And 0.791 Inches Maximum
- Material Thickness [ABPX]
- 0.153 Inches Minimum And 0.163 Inches Maximum
- Outside Diameter [ABKV]
- 1.277 Inches Maximum
- Style Designator [STYL]
- Split Helical-Right Hand
- Surface Treatment [SFTT]
- Cadmium Overall
Similar Supply Items to 5310-00-167-0683
Freight Information 5310-00-167-0683
5310-00-167-0683 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 194160. A Sub NMFC of X. It has a NMFC Description of WASHER OR GASKETS, IRON OR STEEL,. 5310-00-167-0683 is rated as class 50 when transported by Less-Than Truckload (LTL) freight. 5310-00-167-0683 is rated as class 50 when transported by Less-Than Carload (LCL) rail or ocean freight. It has a Uniform Freight Classification (UFC) number of 55210 which rates the freight between FCL and LCL. 5310-00-167-0683 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 713 for ocean manifesting and military sealift. 5310-00-167-0683 is not classified as a special type of cargo when transported by water. 5310-00-167-0683 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
