5310-00-150-3658
Shouldered And Recessed Washer
5310001503658 001503658 650039-2
A washer, round in shape, having a centrally located hole. One bearing surface is flat, the other surface is in the form of a raised shoulder (boss) having a flat bearing surface. Either or both of the bearing surfaces must be broken by a counterbore, countersink, or similar shaped recess. The thickness of the shoulder (boss) must not exceed 25 percent of the shoulder (boss) diameter. For items having a shoulder (boss) of greater thickness, use BEARING, SLEEVE; BUSHING, SLEEVE; or SPACER, SLEEVE. Excludes INSULATOR, WASHER and thrust type washers. View more Shouldered And Recessed Washer
May 2023
3
Marketplace 5310-00-150-3658
Request a Quotation from participating marketplace vendors
Related Documents 5310-00-150-3658 4+ Documents (More...)
5310-00-150-3658 2+ Documents ( More... ) https//www.nsnlookup.com /fsg-53/fsc-5310/us 5310-00-150-3658
Shouldered And Recessed Washer 5310001503658 650039-2 A washer, round in shape, having a centrally located
Shouldered And Recessed Washer 5310001503658 www.nsnlookup.com /fsg-53/fsc-5310/us 5310-00-271-
7703 6625005627703 005627703 WASHER,SPRING TENSION https//www.nsnlookup.com /fsg-53/fsc-5310/us 5310-00-150-3658
Restrictions 5310-00-150-3658
5310-00-150-3658 is a Shouldered And Recessed Washer that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. The precious metals content of this item is unknown.
Import and Export 5310-00-150-3658
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5310-00-150-3658
- National Security Agency (DGX1)
- Effective Date:
- 1 Jan 2014
- US Navy (N9BZ)
- Effective Date:
- 1 Mar 2014
- Supplementary Collaborators:
- HDKEHX
- Greece (ZU01)
- Effective Date:
- 1 Mar 2008
Approved Sources 5310-00-150-3658
- Part Number
- Manufacturer
- Status
- 650039-2
- Manufacturer
- 96214 - Raytheon Company (Active)
- Primary Buy
- Primary Buy
Datasheet 5310-00-150-3658
- Characteristic
- Specifications
- FIIG
- Specifications
- A022B0
- Hole Diameter [AAUB]
- 0.144 Inches Nominal
- Material Thickness [ABPX]
- 0.040 Inches Minimum And 0.045 Inches Maximum
- Material [MATT]
- Steel Comp 303 Overall
- Outside Diameter [ABKV]
- 0.562 Inches Nominal
- Material Document And Classification [MDCL]
- Astm A582 Assn Std Single Material Response Overall
- Recess Angle [CSTM]
- 100.0 Degrees Nominal
- Recess Diameter [ABMD]
- 0.280 Inches Nominal
- Shoulder Height [ABMG]
- 0.025 Inches Minimum And 0.030 Inches Maximum
- Shoulder Diameter [AAVH]
- 0.240 Inches Nominal
- Special Features [FEAT]
- Shoulder Has Two Flat Paralell Surfaces
- Style Designator [STYL]
- Shouldered And Recessed
DLA Procurement Analysis 5310-00-150-3658
Management Data 5310-00-150-3658
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
Similar Supply Items to 5310-00-150-3658
Freight Information 5310-00-150-3658
5310-00-150-3658 has freight characteristics managed by the Southwestern Power Administration.It has a National Motor Freight Classification (NMFC) of 194160. A Sub NMFC of X. It has a NMFC Description of WASHER OR GASKETS, IRON OR STEEL,. 5310-00-150-3658 is rated as class 50 when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 55210 which rates the freight between FCL and LCL. 5310-00-150-3658 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 713 for ocean manifesting and military sealift. 5310-00-150-3658 is not classified as a special type of cargo when transported by water. 5310-00-150-3658 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Contracting Technical Data File (CTDF) 5310-00-150-3658 February 2021
Criticality and Quality
- Critical Item Code:
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- N
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
