5310-00-149-9126
Flat Washer
5310001499126 001499126 124-4322603 PC 127 MS20002-10 850853-00 NAS143-10 10082395 5310PL0150702
A washer having a centrally located hole with a solid or laminated cross-section and two flat parallel bearing surfaces. The hole must be 75 percent or less than the largest dimension and the bearing surface finish is greater than 32 microinch (0.8 micrometer). The thickness cannot exceed 25 percent of the largest outside dimension. When the largest outside dimension is less than 1/4 inch or 6mm, the thickness must be 0.006 inches (0.15mm) or greater and for items 1/4 inch (6mm) or larger, the thickness must be 0.016 inches (0.4mm) or greater. The maximum tolerance is applied to dimensions and used as a determining factor. Items with separable lamination use SHIM. For items fabricated from ceramic or electrically rated materials by specification or industry standards use INSULATOR (1), WASHER. Excludes DISK, VALVE, graphite impregnated and lubricated items. View more Flat Washer
Managed by United States
NSN Created on 1 Jan 1963
Data Last Changed
November 2023
November 2023
NATO Update Count
59
59
NATO Data Quality
Marketplace 5310-00-149-9126
Need Help?
Request a Quotation from participating marketplace vendors
Request a Quotation from participating marketplace vendors
Related Documents 5310-00-149-9126 3+ Documents (More...)
124-4322603 PC 127 MS20002-10 850853-00 NAS143-10 10082395 5310PL0150702 A washer having a centrally
(Identification) 1/3 NSN 5310-00-149-9126 (Identification) 2/3 NSN 5310-00-149-9126 (Identification
MS20002-10 WASHER,FLAT 3267 HD NS Request Quotation Subscribe to View Vendor Details... 5310-00-149-9126
(Identification) 1/3 NSN 5310-00-149-9126 (Identification) 2/3 NSN 5310-00-149-9126 (Identification
MS20002-10 WASHER,FLAT 3267 HD NS Request Quotation Subscribe to View Vendor Details... 5310-00-149-9126
JavaScript in your web browser . 5310-99-464-2105Flat Washer5310994642105 994642105 A7A/2000/172 MS20002-10
Flat Washer 5310001499126 001499126 MS20002-10 WASHER,FLAT 2 HD NS Request Quotation Subscribe
MS20002-10 WASHER,FLAT 55 HD NS Request Quotation Subscribe to View Vendor Details...
Flat Washer 5310001499126 001499126 MS20002-10 WASHER,FLAT 2 HD NS Request Quotation Subscribe
MS20002-10 WASHER,FLAT 55 HD NS Request Quotation Subscribe to View Vendor Details...
Restrictions 5365-00-215-5080 DEMIL: A | DEMILI https//www.nsnlookup.com /fsg-53/fsc-5310/us 5310-00-149-9126
Flat Washer 5310001499126 001499126 Account Upgrade 5310-00-149-9126Flat Washer5310001499126 001499126
124-4322603 PC 127 MS20002-10 850853 RNVC 2 DAC E MS20002-10 10630 - Anillo Industries Inc (Active)
Flat Washer 5310001499126 001499126 Account Upgrade 5310-00-149-9126Flat Washer5310001499126 001499126
124-4322603 PC 127 MS20002-10 850853 RNVC 2 DAC E MS20002-10 10630 - Anillo Industries Inc (Active)
Restrictions 5310-00-149-9126
5310-00-149-9126 is a Flat Washer that is an aviation critical safety item or flight safety critical aircraft part. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. The precious metals content of this item is unknown.
Import and Export 5310-00-149-9126
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5310-00-149-9126
- US Army (A919)
- Effective Date:
- 1 Apr 2006
- Former MOE Rule:
- A187
- Supplementary Receivers:
- AZCTCLBFBD
- US Coast Guard (C918)
- Effective Date:
- 1 Apr 2006
- Former MOE Rule:
- C004
- Supplementary Receivers:
- XH
- US Air Force (FXGI)
- Effective Date:
- 1 Apr 2006
- Former MOE Rule:
- FXKZ
- NASA (G860)
- Effective Date:
- 1 Apr 1991
- US Marine Corps (MC47)
- Effective Date:
- 1 Apr 2006
- Former MOE Rule:
- MC10
- US Navy (N9BZ)
- Effective Date:
- 1 Apr 2006
- Former MOE Rule:
- NIZD
- Supplementary Collaborators:
- GTKEJFJBHD
- Finland (WF01)
- Effective Date:
- 1 Feb 2008
- Lithuania (WI01)
- Effective Date:
- 1 Feb 2001
- Poland (WP01)
- Effective Date:
- 1 Aug 2005
- Romania (WR01)
- Effective Date:
- 1 Feb 2012
- Bulgaria (WU01)
- Effective Date:
- 1 Feb 2008
- MOE Rule:
- X002
- Effective Date:
- 1 Aug 2012
- Brazil (YA01)
- Effective Date:
- 1 Dec 1999
- Spain (YB01)
- Effective Date:
- 1 Apr 1991
- Columbia (YC01)
- Effective Date:
- 1 Jul 2015
- Israel (YD01)
- Effective Date:
- 1 Apr 1991
- Singapore (YJ01)
- Effective Date:
- 1 Apr 1991
- Kuwait (YK01)
- Effective Date:
- 1 Feb 2015
- Morocco (YP01)
- Effective Date:
- 1 Nov 2008
- Malaysia (YW01)
- Effective Date:
- 1 Apr 1991
- Australia (ZA01)
- Effective Date:
- 1 Apr 1991
- Belgium (ZB01)
- Effective Date:
- 1 Apr 1991
- Canada (ZC01)
- Effective Date:
- 1 Apr 1991
- New Zealand (ZE01)
- Effective Date:
- 1 Apr 1991
- France (ZF01)
- Effective Date:
- 1 Apr 1991
- Germany (ZG01)
- Effective Date:
- 1 Apr 1991
- Republic of Korea (ZH01)
- Effective Date:
- 1 Apr 1991
- United Kingdom (ZK01)
- Effective Date:
- 1 Apr 1991
- Philippines (ZM01)
- Effective Date:
- 1 Feb 2015
- Netherlands (ZN01)
- Effective Date:
- 1 Apr 1991
- Portugal (ZP01)
- Effective Date:
- 1 Apr 1991
- Italy (ZR01)
- Effective Date:
- 1 Apr 1991
- Denmark (ZS01)
- Effective Date:
- 1 Apr 1991
- Norway (ZT01)
- Effective Date:
- 1 Apr 1991
- Greece (ZU01)
- Effective Date:
- 1 Apr 1991
- Turkey (ZW01)
- Effective Date:
- 1 Aug 1993
- NATO Maintenance and Supply Agency (ZX01)
- Effective Date:
- 1 Apr 1991
Approved Sources 5310-00-149-9126
- Part Number
- Manufacturer
- Status
- MS20002-10
- Manufacturer
- 80205 - National Aerospace Standards (Active)
- Primary Buy
- Primary Buy
- MS20002-10
- 78286 - Sikorsky Aircraft Corporation (Active)
- Secondary Buy
- Secondary Buy
- MS20002-10
- 10630 - Anillo Industries Llc (Active)
- Secondary Buy
- Secondary Buy
- 850853-00
- 32345 - Defense Reduction Agency (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- MS20002-10
- 96906 - Military Standards (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- MS20002-10
- 0P012 - H. V. Mody, Inc. (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
- NAS143-10
- 7EK50 - Textron Aviation Inc (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- NAS143-10
- 80205 - National Aerospace Standards (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- NAS143-10
- 70898 - Beechcraft Corporation (Replaced)
- Canceled/Obsolete
- Canceled/Obsolete
- 10082395
- A486G - Nimikkeistokeskus Ncb Finland (Active)
- NATO Reference
- NATO Reference
- 5310PL0150702
- 9009H - Jednolity Indeks Materialowy - (Active)
- NATO Reference
- NATO Reference
- 5310001499126
- A00AM - E.C.A Etablissement Central Des (Active)
- NATO Reference
- NATO Reference
- 124-4322603 PC 127
- 53711 - Naval Sea Systems Command (Active)
- Advisory Reference
- Advisory Reference
Datasheet 5310-00-149-9126
- Characteristic
- Specifications
- FIIG
- Specifications
- A022B0
- Center Hole Shape Style [ABMX]
- Round
- Cross-Sectional Shape Style [AAGR]
- Rectangular
- Hardness Rating [CQFM]
- 25.0 Rockwell C Minimum And 32.0 Rockwell C Maximum
- Hole Diameter [AAUB]
- 0.631 Inches Minimum And 0.643 Inches Maximum
- Material [MATT]
- Steel Comp 1330 Overall Or Steel Comp 4130 Overall
- Overall Diameter [ADAV]
- 1.052 Inches Minimum And 1.072 Inches Maximum
- Minimum Tensile Strength [CQBC]
- 125000 Pounds Per Square Inch
- Material Document And Classification [MDCL]
- 66 Fed Std All Material Responses Overall
- Peripheral Shape Style [ABMW]
- Round
- Surface Treatment Document And Classification [STDC]
- Qq-P-416,Ty 2,Cl 3 Fed Spec Single Treatment Response Overall
- Surface Treatment [SFTT]
- Cadmium Overall
- Thickness [ABNM]
- 0.052 Inches Minimum And 0.072 Inches Maximum
Weapon Systems (WSDC) 5310-00-149-9126
DLA Procurement Analysis 5310-00-149-9126
- Last Stock Position:
- 505200 In Stock
- DLA Administrative Lead Time:
- Subscribe
- DLA Production Lead Time:
- Subscribe
Management Data 5310-00-149-9126
- Effective Date
- Organization
- Unit of Issue
- Unit Price
- Qty Unit Pack
- Unit of Issue
- Oct 2022
- Department of the Army (DA)
- HD
- Subscribe
- 1
- HD
- Oct 2021
- Defense Logistics Agency (DS)
- HD
- Subscribe
- 1
- HD
- Oct 2020
- Defense Logistics Agency (DS)
- HD
- Subscribe
- 1
- HD
- Mar 2020
- Department of the Air Force (DF)
- HD
- Subscribe
- 1
- HD
- Oct 2019
- Department of the Army (DA)
- HD
- Subscribe
- 1
- HD
Army
- Materiel Category and Inventory Manager:
- T
- Industrial Supplies (DLA/GSA Items)
- Appropriation and Budget Activity:
- 2
- Stock Fund Secondary Items
- Management Inventory Segment:
- 2
- Non-Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify items, which are not reparable.
- Weapons System / End Item / Homogeneous Group:
- CC
- Other Aircraft Categories
Multi-Application Aviation Spares
- Accounting Requirements:
- X
- Expendable item.An item of Army property coded with an ARC of X in the AMDF. Expendable items require no formal accountability after issue from a stock record account.Commercial and fabricated items similar to items coded X in the AMDF are considered expendable items.
Air Force
- Fund:
- SF
- Stock fund applicable to items managed for the Air Force by the respective Inventory Control Point
- Budget:
- 9
- 57X4921.070 - General Support DIV - Air Force decentralized managed expense items (ERRC XB3, XF3) with a unit cost of less than $250,000 that are requisitioned/procured at base (retail) level from DLA, GSA, Army, Navy, Depot Maintenance Service, Air Force Industrial Fund (AFMC), local manufacture and commercial vendors
- Aggregation Code:
- GC
- UH/60A BLACKHAWK
- Price Validation Code:
- V
- The current standard price has been validated.
The item has been analyzed in conjunction with the Zero Overpricing Program and is in the accepted price range.
The item was procured under open competition and under the competitive arena the price is considered fair and reasonable.
ZOP or Standard price challenges are permissible but must be supported by adequate justification.
- Expendability
Recoverability
Repairability: - N
- Expendable. Condemn at User. Stock Fund (except Munitions).
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
Marine Corps
- Stores Account:
- 1
- Stock Fund Account Item
- Combat Essentiality:
- 2
- Non-Critical Repair Part
- Echelon Management:
- B2
- Material Identification:
- K
- Reserved
- Operational Test:
- No Special Procedures
NATO Stock Numbers Related to 5310-00-149-9126
5310-12-312-3034 5310-99-466-2925 5310-99-213-6153 5310-12-180-7225 5310-27-021-1379 5310-12-186-8041 5310-32-086-1984 5310-99-139-5962 5310-12-378-1384 5310-12-330-7955 5310-14-575-5813 5310-12-373-6997 5310-12-336-6867 5310-99-151-5142 5310-99-668-2023 5310-27-011-2394 5310-66-158-2482 5310-37-518-5100
Freight Information 5310-00-149-9126
5310-00-149-9126 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 194160. A Sub NMFC of X. It has a NMFC Description of WASHER OR GASKETS, IRON OR STEEL,. 5310-00-149-9126 is rated as class 50 when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 55210 which rates the freight between FCL and LCL. 5310-00-149-9126 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 713 for ocean manifesting and military sealift. 5310-00-149-9126 is not classified as a special type of cargo when transported by water. 5310-00-149-9126 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 5310-00-149-9126
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- Plated/Coated Item
- 2lb or less, one dimension 2" or less, other dimensions less than 24"
- Above 110G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- --
- --
- --
- Physical Protection
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- No Requirement
- No Requirement
- Not Applicable
- PPP-B-566, PPP-B-676, or ASTM-D5118, Folding, Setup or Fiberboard Box
- No special marking
- No Requirement
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- PPP-B-566, PPP-B-676, or ASTM-D5118, Folding, Setup or Fiberboard Box
Procurement History 5310-00-149-9126 1 Records
Contracting Technical Data File (CTDF) 5310-00-149-9126 February 2021
Criticality and Quality
- Critical Item Code:
- X
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- F
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- Y
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
