5310-00-133-3671
Double Hexagon Extended Washer Self-Locking Nut
5310001333671 001333671 BH00935-14 5310-OH58-001 EB9025-14
A nut having 12 drive points, 24 sides, and an integral washer which extends beyond the points or periphery. An integral feature is incorporated for locking on the threads of a mating member. View more Double Hexagon Extended Washer Self-Locking Nut
May 2023
27
Marketplace 5310-00-133-3671
Request a Quotation from participating marketplace vendors
Updated Every Day Updated Every Day
Updated Every Day Related Documents 5310-00-133-3671 4+ Documents (More...)
Photo 1/2 NSN 5310-00-133-3671 (Identification) 2/2 - - 1.
United States (US) 4. 5310-00-133-3671 Marketplace Restrictions Approved Sources Datasheet Management
Restrictions 5310-00-133-3671
5310-00-133-3671 is a Double Hexagon Extended Washer Self-Locking Nut that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. The precious metals content of this item is unknown.
Import and Export 5310-00-133-3671
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5310-00-133-3671
- US Army (A919)
- Effective Date:
- 1 Jun 2005
- Former MOE Rule:
- A187
- Supplementary Receivers:
- CT
- US Navy (N9BZ)
- Effective Date:
- 1 Jun 2005
- Former MOE Rule:
- N9ZD
- Supplementary Collaborators:
- GT
- Austria (WB01)
- Effective Date:
- 1 Feb 2005
- Slovenia (WL01)
- Effective Date:
- 1 Mar 2006
- Bulgaria (WU01)
- Effective Date:
- 1 Oct 2002
- Brazil (YA01)
- Effective Date:
- 1 Dec 1999
- Spain (YB01)
- Effective Date:
- 1 Apr 1991
- Columbia (YC01)
- Effective Date:
- 1 Jul 2015
- Australia (ZA01)
- Effective Date:
- 1 Apr 1991
- Canada (ZC01)
- Effective Date:
- 1 Apr 1991
- Republic of Korea (ZH01)
- Effective Date:
- 1 Apr 1991
- Italy (ZR01)
- Effective Date:
- 1 Nov 2003
- Greece (ZU01)
- Effective Date:
- 1 Apr 1991
- Turkey (ZW01)
- Effective Date:
- 1 Jul 2003
- NATO Maintenance and Supply Agency (ZX01)
- Effective Date:
- 1 Feb 2013
Approved Sources 5310-00-133-3671
- Part Number
- Manufacturer
- Status
- 5310-OH58-001
- Manufacturer
- 81996 - Us Army Aviation And Missile Command (Active)
- Source Control
- Source Control
- BH00935-14
- 27238 - Bristol Industries, Llc (Active)
- Primary Buy
- Primary Buy
- 5310-OH58-001
- 56878 - Sps Technologies, Llc (Active)
- Primary Buy
- Primary Buy
- EB9025-14
- 56878 - Sps Technologies, Llc (Active)
- Secondary Buy
- Secondary Buy
- 5310-OH58-001
- 27238 - Bristol Industries, Llc (Active)
- Secondary Buy
- Secondary Buy
- BH00935-14
- 97499 - Bell Textron Inc (Active)
- Secondary Buy
- Secondary Buy
- EB9025-14
- 97499 - Bell Textron Inc (Active)
- Secondary Buy
- Secondary Buy
- 5310-OH58-001
- 97499 - Bell Textron Inc (Active)
- Secondary Buy
- Secondary Buy
- EB9025-14
- 72962 - Harvard Industries Inc (Replaced)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 5310-00-133-3671
- Characteristic
- Specifications
- FIIG
- Specifications
- A021A0
- Material [MATT]
- Plastic Polyamide Locking Insert
- Nominal Thread Size [CQJX]
- 0.875 Inches
- Nut Style [ACTA]
- Double Hexagon
- Locking Feature [AAUM]
- Prevailing Torque With Nonmetallic Insert
- Material Document And Classification [MDCL]
- Aisi Assn Std Single Material Response Overall
- Overall Height [ABKW]
- 0.953 Inches Nominal
- Special Features [FEAT]
- Color Black
- Washer Outside Diameter [AAVX]
- 1.307 Inches Minimum And 1.317 Inches Maximum
- Washer Thickness [ADEM]
- 0.290 Inches Nominal
- Width Across Flats [ASDB]
- 1.050 Inches Minimum And 1.067 Inches Maximum
- Surface Treatment Document And Classification [STDC]
- Qq-P-416,Ty 2,Cl 3 Fed Spec Single Treatment Response Overall
- Surface Treatment [SFTT]
- Cadmium Overall
- Temp Rating [AZKQ]
- 250.0 Deg Fahrenheit Nominal
- Thread Class [AAJD]
- 3B
- Thread Direction [AAJF]
- Right-Hand
- Thread Series [BZRR]
- Unjf
- Thread Quantity Per Inch [CMLP]
- 14
Weapon Systems (WSDC) 5310-00-133-3671
DLA Procurement Analysis 5310-00-133-3671
- Last Stock Position:
- 181 In Stock
- DLA Administrative Lead Time:
- Subscribe
- DLA Production Lead Time:
- Subscribe
Management Data 5310-00-133-3671
Army
- Materiel Category and Inventory Manager:
- T
- Industrial Supplies (DLA/GSA Items)
- Appropriation and Budget Activity:
- 2
- Stock Fund Secondary Items
- Management Inventory Segment:
- 2
- Non-Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify items, which are not reparable.
- Weapons System / End Item / Homogeneous Group:
- 00
- DLA/GSA Material
DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item
- Accounting Requirements:
- X
- Expendable item.An item of Army property coded with an ARC of X in the AMDF. Expendable items require no formal accountability after issue from a stock record account.Commercial and fabricated items similar to items coded X in the AMDF are considered expendable items.
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
Similar Supply Items to 5310-00-133-3671
Freight Information 5310-00-133-3671
5310-00-133-3671 has freight characteristics managed by the Southwestern Power Administration.It has a National Motor Freight Classification (NMFC) of 093486. A Sub NMFC of Z. It has a NMFC Description of BOLTS,NUTS OR SCREWS, NOI (SUB 3). 5310-00-133-3671 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 48950 which rates the freight between FCL and LCL. 5310-00-133-3671 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 573 for ocean manifesting and military sealift. 5310-00-133-3671 is not classified as a special type of cargo when transported by water. 5310-00-133-3671 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 5310-00-133-3671
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- Bare Metal Item
- 2lb or less, one dimension 2" or less, other dimensions less than 24"
- Above 110G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- --
- --
- --
- Physical Protection
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- No Requirement
- No Requirement
- Not Applicable
- Any Suitable Container
- No special marking
- No Requirement
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- --
Procurement History 5310-00-133-3671 1 Records
Contracting Technical Data File (CTDF) 5310-00-133-3671 February 2021
Criticality and Quality
- Critical Item Code:
- X
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- T
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- Y
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
