5310-00-122-8001
Round Plain Nut
5310001228001 001228001 30491
A nut, circular in shape, which may have wrenching facilities such as flats, holes, protrusions, slots or splines in or on the periphery or in the face opposite the bearing surface. For items having a thickness (or height) exceeding two times the outside diameter, use POST, ELECTRICAL-MECHANICAL EQUIPMENT. See also NUT (1), PLAIN, KNURLED. (When height or thickness and/or outside diameter is designated as a tolerance dimension, the maximum dimension will be used to determine compliance.) View more Round Plain Nut
May 2023
10
Marketplace 5310-00-122-8001
Request a Quotation from participating marketplace vendors
Related Documents 5310-00-122-8001 5+ Documents (More...)
Quotation Updated Every Day 5310-00-122-8001 RQST NE Updated Every Day 5310-00-122-8001 RQST Updated
Every Day 5310-00-122-8001 RQST NE Related Documents 5310-00-122-8001 5+ Documents ( More... ) https
Round Plain Nut 5310001228001 001228001,30491 NUT,PLAIN,ROUND 1 EA NS Request Quotation Subscribe
to View Vendor Details... 30491 NUT,PLAIN,ROUND 34 EA NS Request Quotation Subscribe to View Vendor
-5950/us 5950- https//www.nsnlookup.com /fsg-53/fsc-5310/us 5310-00-122-8001 Round Plain Nut 5310001228001
001228001,30491 NUT,PLAIN,ROUND 1 EA NS Request Quotation Subscribe to View Vendor Details... 30491
Restrictions 5310-00-122-8001
5310-00-122-8001 is a Round Plain Nut that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. The precious metals content of this item is unknown.
Import and Export 5310-00-122-8001
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5310-00-122-8001
- Portugal (ZP01)
- Effective Date:
- 1 Apr 1991
- Greece (ZU01)
- Effective Date:
- 1 Apr 1991
Approved Sources 5310-00-122-8001
- Part Number
- Manufacturer
- Status
- 30491
- Manufacturer
- 77294 - Piper Industrial Manufacturing (Active)
- Primary Buy
- Primary Buy
Datasheet 5310-00-122-8001
- Characteristic
- Specifications
- FIIG
- Specifications
- A021A0
- Drilled Hole Diameter [AGGP]
- 0.156 Inches Nominal
- Drive Point Depth [ABQU]
- 0.094 Inches Nominal
- Drive Point Diameter [AFGF]
- 0.156 Inches Nominal
- Drive Point Quantity [ADBM]
- 6
- Counterbore Diameter [AAWY]
- 1.250 Inches Nominal Nut
- Hole Configuration Style [CRHC]
- Configuration F
- Hole Type And Quantity [ALET]
- 6 Drilled
- Material [MATT]
- Steel Overall
- Nominal Thread Size [CQJX]
- 1.250 Inches
- Nut Counterbore Depth [ADFK]
- 0.437 Inches Nominal Nut
- Nut Diameter [ACTD]
- 1.438 Inches Nominal
- Nut Style [ACTA]
- Round
- Nut Thickness [ADBG]
- 0.875 Inches Nominal
- Surface Treatment [SFTT]
- Phosphate Overall
- Thread Class [AAJD]
- 3B
- Thread Direction [AAJF]
- Right-Hand
- Thread Series [BZRR]
- Unf
- Thread Quantity Per Inch [CMLP]
- 12
Similar Supply Items to 5310-00-122-8001
Freight Information 5310-00-122-8001
5310-00-122-8001 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 093486. A Sub NMFC of Z. It has a NMFC Description of BOLTS,NUTS OR SCREWS, NOI (SUB 3). 5310-00-122-8001 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. 5310-00-122-8001 is rated as class 50 when transported by Less-Than Carload (LCL) rail or ocean freight. It has a Uniform Freight Classification (UFC) number of 48950 which rates the freight between FCL and LCL. 5310-00-122-8001 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 573 for ocean manifesting and military sealift. 5310-00-122-8001 is not classified as a special type of cargo when transported by water. 5310-00-122-8001 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
