5310-00-080-6004

Flat Washer

5310000806004 000806004 FF-W-92 02833 4398 9438083 526-1516 B4525-307-41 5118-140-38 5593213 32102 LS1091391-14 SK-6005-3 LS1091391-15 00715 9419234 W03-001859 408452N ITEM 2 7G32102 12387279-14 453 103341 122-53T1661 ITEM 37 812A5C4 12A5C4 15001-9 4B4278

A washer having a centrally located hole with a solid or laminated cross-section and two flat parallel bearing surfaces. The hole must be 75 percent or less than the largest dimension and the bearing surface finish is greater than 32 microinch (0.8 micrometer). The thickness cannot exceed 25 percent of the largest outside dimension. When the largest outside dimension is less than 1/4 inch or 6mm, the thickness must be 0.006 inches (0.15mm) or greater and for items 1/4 inch (6mm) or larger, the thickness must be 0.016 inches (0.4mm) or greater. The maximum tolerance is applied to dimensions and used as a determining factor. Items with separable lamination use SHIM. For items fabricated from ceramic or electrically rated materials by specification or industry standards use INSULATOR (1), WASHER. Excludes DISK, VALVE, graphite impregnated and lubricated items. View more Flat Washer

Managed by United States

NSN Created on 1 Jan 1963

Data Last Changed
January 2024

NATO Update Count
119

NATO Data Quality

5310-00-080-6004 WASHER,FLAT 5310000806004 000806004 1/1 — 5310-00-080-6004 Photo 1/1

Marketplace 5310-00-080-6004

Need Help?
Request a Quotation from participating marketplace vendors

FinditParts

S602 Tramec Sloan S60-2 - 1/8" Compression Sleeve STK NE $0.31 Distributor Buy Now

Global Test Supply

453 Dremel 453 Chainsaw Sharpening/Grinding Stones, 0.31", 2-pack STK NE $4.74 Distributor Buy Now

Subscribe to View Vendor Details...

MS27183-14 WASHER,FLAT 16 HD NS

453 WASHER,FLAT 1 HD NS

Subscribe to View Vendor Details...

453 WASHER,FLAT 34 HD NS

Subscribe to View Vendor Details...

NAS1070-616 WASHER,FLAT 82 HD NS

Subscribe to View Vendor Details...

MS27183-14 WASHER,FLAT 125 HD NS

Subscribe to View Vendor Details...

S602 WASHER,FLAT 270 HD NS

MS27183-14 WASHER,FLAT 509 HD NS

FFW92 WASHER,FLAT 15 HD NS

32102 WASHER,FLAT 12 HD NS

S WASHER,FLAT 552 HD NS

Subscribe to View Vendor Details...

020035 WASHER,FLAT 1 HD TO

Subscribe to View Vendor Details...

WASHER38FLAT WASHER,FLAT RQST NS

Subscribe to View Vendor Details...

MS27183-14 WASHER,FLAT RQST NS

Subscribe to View Vendor Details...

S WASHER,FLAT 1 HD NS

MS27183-14 WASHER,FLAT 100 HD NS

Subscribe to View Vendor Details...

5310-00-080-6004 WASHER, FLAT 9725 HD NS

Subscribe to View Vendor Details...

453 WASHER,FLAT RQST NS

5310-00-080-6004 RQST NE

Updated Every Day

5310-00-080-6004 RQST

Updated Every Day

5310-00-080-6004 RQST NE

Restrictions 5310-00-080-6004

5310-00-080-6004 is a Flat Washer that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.

Import and Export 5310-00-080-6004

Schedule B: Subscribe to View Schedule B
HTS Code: Subscribe to View HTS Code

End Users 5310-00-080-6004

US Army (A919)
Effective Date:: 1 Apr 2006
Former MOE Rule:: A187
Supplementary Receivers:: AJCTCLBFBDAZAM; AMC 1 AMSC G IMC Z IMCACTY CD

US Coast Guard (C918)
Effective Date:: 1 Apr 2006
Former MOE Rule:: C004; AMC 1 AMSC G

US Air Force (FXGI)
Effective Date:: 1 Apr 2006
Former MOE Rule:: FXKZ; AMC 1 AMSC G IMC Z IMCACTY SX

NASA (G280)
Effective Date:: 1 Apr 1991; AMC 0 AMSC 0 AAC C

NASA (G810)
Effective Date:: 1 Apr 1991; AMC 0 AMSC 0 AAC L

NASA (G860)
Effective Date:: 1 Apr 1991; AMC 0 AMSC 0 AAC C

US Marine Corps (MC47)
Effective Date:: 1 Apr 2006
Former MOE Rule:: MC10; AMC 1 AMSC G IMC Z IMCACTY PA

US Navy (N9BZ)
Effective Date:: 1 Apr 2006
Former MOE Rule:: NIZD
Supplementary Collaborators:: GEKEJNJGJFHXHDGT; AMC 1 AMSC G IMC Z IMCACTY GH

Austria (WB01)
Effective Date:: 1 Feb 2005

Finland (WF01)
Effective Date:: 1 Feb 2008

Lithuania (WI01)
Effective Date:: 1 Jul 2000

Slovenia (WL01)
Effective Date:: 1 Nov 2008

Poland (WP01)
Effective Date:: 1 May 2005

MOE Rule:: X002
Effective Date:: 1 Apr 1991

Brazil (YA01)
Effective Date:: 1 Dec 1999

Spain (YB01)
Effective Date:: 1 Apr 1991

Columbia (YC01)
Effective Date:: 1 Jul 2015

Singapore (YJ01)
Effective Date:: 1 Apr 1991

Kuwait (YK01)
Effective Date:: 1 Jan 2015

Morocco (YP01)
Effective Date:: 1 Nov 2008

Saudi Arabia (YS01)
Effective Date:: 1 Feb 2015

Malaysia (YW01)
Effective Date:: 1 Apr 1991

Thailand (YY01)
Effective Date:: 1 Feb 2015

Australia (ZA01)
Effective Date:: 1 Apr 1991

Belgium (ZB01)
Effective Date:: 1 Apr 1991

Canada (ZC01)
Effective Date:: 1 Apr 1991

New Zealand (ZE01)
Effective Date:: 1 Apr 1991

France (ZF01)
Effective Date:: 1 Apr 1991

Germany (ZG01)
Effective Date:: 1 Apr 1991

Republic of Korea (ZH01)
Effective Date:: 1 Apr 1991

United Kingdom (ZK01)
Effective Date:: 1 Apr 1991

Philippines (ZM01)
Effective Date:: 1 Feb 2015

Netherlands (ZN01)
Effective Date:: 1 Apr 1991

Portugal (ZP01)
Effective Date:: 1 Apr 1991

Italy (ZR01)
Effective Date:: 1 Apr 1991

Denmark (ZS01)
Effective Date:: 1 Apr 1991

Norway (ZT01)
Effective Date:: 1 Apr 1991

Greece (ZU01)
Effective Date:: 1 Apr 1991

Turkey (ZW01)
Effective Date:: 1 Aug 1993

NATO Maintenance and Supply Agency (ZX01)
Effective Date:: 1 Apr 1991

Approved Sources 5310-00-080-6004

Part Number
Manufacturer
Status
MS27183-14: 96906 - Military Standards (Active); Definitive Standard; RNCC 2 RNVC 2 DAC E
FF-W-92: 81348 - Federal Specifications Promulgated (Active); Incomplete Standard; RNCC 4 RNVC 1 DAC 4
02833: 77640 - Zf Active Safety And Electronics Us (Active); Incomplete Secondary Reference; RNCC 5 RNVC 1 DAC 5
4398: 23834 - Elliott Machine Works Inc (Active); Incomplete Secondary Reference; RNCC 5 RNVC 1 DAC 5
9438083: 7X677 - General Motors Llc (Active); Incomplete Secondary Reference; RNCC 5 RNVC 1 DAC 1
526-1516: 44940 - Cummins Power Generation Inc. (Active); Incomplete Secondary Reference; RNCC 5 RNVC 1 DAC 6
B4525-307-41: 60532 - Trane U.S. Inc. (Active); Incomplete Secondary Reference; RNCC 5 RNVC 1 DAC 1
5118-140-38: 80372 - Marine Corps (Active); Incomplete Secondary Reference; RNCC 5 RNVC 1 DAC 5
5118-140-38: 79466 - Aesys Technologies, L.L.C. (Active); Incomplete Secondary Reference; RNCC 5 RNVC 1 DAC 5
5593213: 34623 - Am General Llc (Active); Incomplete Secondary Reference; RNCC 5 RNVC 1 DAC 5
32102: 94431 - Garrison Manufacturing Inc (Active); Incomplete Secondary Reference; RNCC 5 RNVC 1 DAC 5
MS27183-14: 03670 - Tyco Fire Products Lp (Active); Incomplete Secondary Reference; RNCC 5 RNVC 1 DAC 6
LS1091391-14: 01417 - General Dynamics Land Systems Inc. (Active); Incomplete Secondary Reference; RNCC 5 RNVC 1 DAC 4
SK-6005-3: 0EAK3 - Gse Management Co (Active); Incomplete Secondary Reference; RNCC 5 RNVC 1 DAC 5
LS1091391-15: 01417 - General Dynamics Land Systems Inc. (Active); Incomplete Secondary Reference; RNCC 5 RNVC 1 DAC D
00715: 1BZD4 - Tru-Hitch, Inc. (Active); Incomplete Secondary Reference; RNCC 5 RNVC 1 DAC 5
MS27183-14: 6R888 - J. T. D. Stamping Co Inc (Active); Incomplete Secondary Reference; RNCC 5 RNVC 1 DAC 6
9419234: 7X677 - General Motors Llc (Active); Incomplete Secondary Reference; RNCC 5 RNVC 1 DAC 5
W03-001859: 88219 - Stryten Energy Llc (Active); Incomplete Secondary Reference; RNCC 5 RNVC 1 DAC 5
408452N ITEM 2: 03670 - Tyco Fire Products Lp (Active); Incomplete Secondary Reference; RNCC 5 RNVC 1 DAC C
7G32102: 23382 - Fwd Seagrave Holdings Lp (Active); Incomplete Secondary Reference; RNCC 5 RNVC 1 DAC 5
12387279-14: 19207 - U S Army Tank Automotive Command (Active); Incomplete Secondary Reference; RNCC 5 RNVC 1 DAC 5
0707807: S3002 - General Dynamics European, (Active); Secondary Buy; RNCC 5 RNVC 2 DAC 3
MS27183-14: A9271 - Goriziane Group Spa (Active); Secondary Buy; RNCC 5 RNVC 2 DAC 5
MS27183-14: 0158B - Psa Peugeot-Citroen Espana, Sa (Active); Secondary Buy; RNCC 5 RNVC 2 DAC 3
K376: 00198 - Pratt & Whitney Canada Corp (Active); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 2
70026-14: 95097 - Little Giant Crane And Shovel Inc (Obsolete); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 5
62.81.017: 0124B - Sapa Operaciones Sl (Active); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 3
11500256: 7X677 - General Motors Llc (Active); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 5
D21059-16: 07860 - Bogue Electric Manufacturing Co (Replaced); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 1
1229F1514: 78500 - Meritor Heavy Vehicle Systems, Llc (Active); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 5
020035: 99832 - Scott Huber Essick A Co Of Figgie (Obsolete); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 5
SK-6005-3: 92916 - Blacher Bros Inc (Active); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 5
120394: 7X677 - General Motors Llc (Active); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 5
9438083: 11862 - General Motors Corp Chevrolet Motor (Obsolete); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 1
9419234: 11862 - General Motors Corp Chevrolet Motor (Obsolete); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 5
9438084: 11862 - General Motors Corp Chevrolet Motor (Obsolete); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 5
362AX1: 45152 - Oshkosh Corp (Active); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 5
MS15795-214: 96906 - Military Standards (Active); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 4
10082380: A486G - Nimikkeistokeskus Ncb Finland (Active); NATO Reference; RNCC 6 RNVC 9 DAC 9
5310005626553: A00AM - E.C.A Etablissement Central Des (Active); NATO Reference; RNCC 6 RNVC 9 DAC 9
5310-080-6004: A00AM - E.C.A Etablissement Central Des (Active); NATO Reference; RNCC 6 RNVC 9 DAC 9
5310PL0567398: 9009H - Jednolity Indeks Materialowy - (Active); NATO Reference; RNCC 6 RNVC 9 DAC 9
5310000806004: A00AM - E.C.A Etablissement Central Des (Active); NATO Reference; RNCC 6 RNVC 9 DAC 9
410060135: S5652 - Rafael (Replaced); NATO Reproduction; RNCC 8 RNVC 2 DAC 1
453: 30874 - International Business Machines (Active); Advisory Reference; RNCC C RNVC 1 DAC 4
103341: 92679 - Navistar Intl Corp (Active); Advisory Reference; RNCC C RNVC 1 DAC 5
122-53T1661 ITEM 37: 53711 - Naval Sea Systems Command (Active); Advisory Reference; RNCC C RNVC 1 DAC 5
812A5C4: D2167 - Thomson Consumerelectronics Sales (Active); Advisory Reference; RNCC C RNVC 1 DAC 6
12A5C4: D9182 - Zf Industrieantriebe Witten Gmbh (Active); Advisory Reference; RNCC C RNVC 1 DAC 6
15001-9: D9182 - Zf Industrieantriebe Witten Gmbh (Active); Advisory Reference; RNCC C RNVC 1 DAC 6
4B4278: D9182 - Zf Industrieantriebe Witten Gmbh (Active); Advisory Reference; RNCC C RNVC 1 DAC 6
3631V007: D9182 - Zf Industrieantriebe Witten Gmbh (Active); Advisory Reference; RNCC C RNVC 1 DAC 6
S602: D9182 - Zf Industrieantriebe Witten Gmbh (Active); Advisory Reference; RNCC C RNVC 1 DAC 6
120394: D9182 - Zf Industrieantriebe Witten Gmbh (Active); Advisory Reference; RNCC C RNVC 1 DAC 6
X14141: D9182 - Zf Industrieantriebe Witten Gmbh (Active); Advisory Reference; RNCC C RNVC 1 DAC 6
12A5C4: 33968 - Clark Equipment Co (Active); Advisory Reference; RNCC C RNVC 1 DAC 6
MS27183-14: 03950 - Naval Inventory Control Point (Active); Advisory Reference; RNCC C RNVC 1 DAC C
W221NAAN037SN038NNCG1: 80204 - American National Standards (Active); Advisory Reference; RNCC C RNVC 1 DAC E
MS-27183-14: D9182 - Zf Industrieantriebe Witten Gmbh (Active); Advisory Reference; RNCC C RNVC 1 DAC 6
362AX1: 75Q65 - Oshkosh Defense Llc (Active); Advisory Reference; RNCC C RNVC 1 DAC 5
122-5377661 ITEM 37: 53711 - Naval Sea Systems Command (Active); Advisory Reference; RNCC C RNVC 1 DAC 5
1176J92-19: D9182 - Zf Industrieantriebe Witten Gmbh (Active); Advisory Reference; RNCC C RNVC 1 DAC 6
103341: D9182 - Zf Industrieantriebe Witten Gmbh (Active); Advisory Reference; RNCC C RNVC 1 DAC 6
W206P: 93236 - Dresser-Rand Co Worthington (Replaced); Advisory Reference; RNCC C RNVC 1 DAC 9
LS1091391: 01417 - General Dynamics Land Systems Inc. (Active); Informational Drawing; RNCC D RNVC 9 DAC 2
664423: 89749 - Clark Material Handling Company (Active); Transferred; RNCC E RNVC 8 DAC 5
3212395: 30874 - International Business Machines (Active); Transferred; RNCC E RNVC 8 DAC 5
3212395: 0B6S1 - International Business Machines Corp (Active); Transferred; RNCC E RNVC 8 DAC 5

Datasheet 5310-00-080-6004

Characteristic
Specifications
FIIG: A022B0
Center Hole Shape Style [ABMX]: Round
Cross-Sectional Shape Style [AAGR]: Rectangular
Hole Diameter [AAUB]: 0.401 Inches Minimum And 0.421 Inches Maximum
End Item Identification [AGAV]: Mrap-Rg-33 Armored Utility Vehicle (Auv); Mrap Buffalo Mk2a2; Mrap - M-Atv With Cs13 Pop And Sne; Medium Mine Protected Vehicle - Mmpv
Material [MATT]: Steel Comp 1008 Or Steel Comp 1009 Or Steel Comp 1010 Or Steel Comp 1011 Or Steel Comp 1012 Or Steel Comp 1013 Or Steel Comp 1015 Or Steel Comp 1016 Or Steel Comp 1017 Or Steel Comp 1018 Or Steel Comp 1019 Or Steel Comp 1020 Overall
Material Document And Classification [MDCL]: Astm A109 Assn Std All Material Responses Overall
Overall Diameter [ADAV]: 0.805 Inches Minimum And 0.827 Inches Maximum
Peripheral Shape Style [ABMW]: Round
Surface Treatment Document And Classification [STDC]: Qq-P-416,Ty 2,Cl 3 Fed Spec Single Treatment Response Overall
Surface Treatment [SFTT]: Cadmium And Chromate Overall
Thickness [ABNM]: 0.051 Inches Minimum And 0.080 Inches Maximum

Weapon Systems (WSDC) 5310-00-080-6004

Subscribe
View WSDC

Subscribe to View Weapon System Codes...

Subscribe
View Data

DLA Procurement Analysis 5310-00-080-6004

Last Stock Position:: 1807600 In Stock
DLA Administrative Lead Time:: Subscribe
DLA Production Lead Time:: Subscribe

Subscribe to View DLA Inventory and Forecast...

Management Data 5310-00-080-6004

Subscribe
View Prices

Effective Date: Organization; Unit of Issue; Unit Price; Qty Unit Pack
Oct 2022: Department of the Navy (DN); HD; Subscribe; 1
Oct 2021: Defense Logistics Agency (DS); HD; Subscribe; 1
Oct 2020: Department of the Air Force (DF); HD; Subscribe; 1
Oct 2019: Department of the Air Force (DF); HD; Subscribe; 1

MOE: USC; Code; Statement; Order of Use; Jump To Code; Qty Per Assy; UOM; Technical Document; Quantative Expression
US Marine Corps (DM): M; 0; Reversal Of Phrase Code Z 5310-00-562-6553
US Marine Corps (DM): M; 0; Reversal Of Phrase Code Z 5310-01-210-1587

Army

Materiel Category and Inventory Manager:

T: Industrial Supplies (DLA/GSA Items)

Appropriation and Budget Activity:

2: Stock Fund Secondary Items

Management Inventory Segment:

2: Non-Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify items, which are not reparable.

Weapons System / End Item / Homogeneous Group:

00: DLA/GSA Material
DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item

Accounting Requirements:

X: Expendable item.An item of Army property coded with an ARC of X in the AMDF. Expendable items require no formal accountability after issue from a stock record account.Commercial and fabricated items similar to items coded X in the AMDF are considered expendable items.

Navy

Cognizance:

9B: Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg

Special Material Content:

9: Non-Hazardous or Non-Sensitive Item

Marine Corps

Stores Account:

1: Stock Fund Account Item

Combat Essentiality:

5: Critical Repair Part to a Combat Essential End Item

Echelon Management:

B2

Material Identification:

B: Consumable Repair Parts

Operational Test:

: No Special Procedures

Similar Supply Items to 5310-00-080-6004

Freight Information 5310-00-080-6004

5310-00-080-6004 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 194160. A Sub NMFC of X. It has a NMFC Description of WASHER OR GASKETS, IRON OR STEEL,. 5310-00-080-6004 is rated as class 50 when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 55210 which rates the freight between FCL and LCL. 5310-00-080-6004 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 576 for ocean manifesting and military sealift. 5310-00-080-6004 is not classified as a special type of cargo when transported by water. 5310-00-080-6004 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.

Packaging Data 5310-00-080-6004

Responsible Activity
Packaging Data Source: Primary Inventory Control Activity (PICA); --

Item Pack Level (Unpackaged)

Item Size
Item Weight
Characteristics
Weight/Dimensions Category
Fragility
Item Preservation: --; --; Plated/Coated Item; 2lb or less, one dimension 2" or less, other dimensions less than 24"; Above 110G; No Requirement

Unit Pack Level (Packaged)

Quantity per Pack
Unit Size
Unit Weight
Unit Cube
Preservation Method
Cleaning/Drying: 1; --; --; --; Physical Protection; Any Suitable Process

Preservation Material
Wrapping Material
Cushioning/Dunnage
Cushioning Thickness
Container
Special Marking: No Requirement; No Requirement; No Requirement; Not Applicable; UU-B-36, Bags, Paper Grocers; No special marking

Intermediate Pack Level

Quantity of Unit Packs
Container: PPP-B-566, PPP-B-676, or ASTM-D5118, Folding, Setup or Fiberboard Box

Procurement History 5310-00-080-6004 2 Records

Subscribe
View Prices

Contract: Date; CAGE; Quantity; Net Price; Std Price
SPE5EN18F0999: 31 Dec 2017; Subscribe; 11116; Subscribe; Subscribe
SPE5EN18F0698P00001: 03 Dec 2017; Subscribe; 8995; Subscribe; Subscribe

Contracting Technical Data File (CTDF) 5310-00-080-6004 February 2021

Criticality and Quality

Critical Item Code:: X
Flight Safety:
Life Support:
Certified Samples:
Serialization:
First Article Test (FAT):
Certificate of Quality Compliance:
Production Lot Testing:
Special Testing:
Qualified Products List (QPL):

Commercial Properties

Government Furnished Material:
Government Furnished Tooling:
Government Furnished Property:
Price Evaluation Code:
Diminshing Manufacturing Sources:
Warranty:
Commerical Off The Shelf (COTS):
End Item Application:
Auctioning Candidate:
Source of Procurement:
Contract Option:

Restrictions

Boeing Rights Guard:
Export Controlled:
Controlled Technical Data Package (TDP):
Restricted Technical Data Package (TDP):
Contains Classified Material
Weapons System Indicator Code (WSIC):: F

Packaging Requirements

Packaging Determination Table:
Packaging Review Code:: N
Special Packaging Instruction Number (SPIN):
Special Packaging Instruction Number Revision:
Special Packaging Instruction Number Date:
Pallet Reference Number Required:

Subscribe
View CTDF

Subscribe to View CTDF Details...

Marketplace 5310-00-080-6004

Related Documents 5310-00-080-6004 5+ Documents (More...)

Restrictions 5310-00-080-6004

Import and Export 5310-00-080-6004

End Users 5310-00-080-6004

Approved Sources 5310-00-080-6004

Datasheet 5310-00-080-6004

Weapon Systems (WSDC) 5310-00-080-6004

DLA Procurement Analysis 5310-00-080-6004

Management Data 5310-00-080-6004

Army

Navy

Marine Corps

Similar Supply Items to 5310-00-080-6004

Freight Information 5310-00-080-6004

Packaging Data 5310-00-080-6004

Item Pack Level (Unpackaged)

Unit Pack Level (Packaged)

Intermediate Pack Level

Procurement History 5310-00-080-6004 2 Records

Contracting Technical Data File (CTDF) 5310-00-080-6004 February 2021

Criticality and Quality

Commercial Properties

Restrictions

Packaging Requirements
